XX. Unified Wire Manager (UM)
7.6.

Network page

7.6.1. Network summary
The Network Summary module provides the total number of Chelsio adapters present,
including the number of T5, T4 and T3 adapters. It also provides the total number of Network
interfaces including corporate and Chelsio interfaces and VLANs.
Figure 7.6.1 (a) – Network Summary module
7.6.2. Chelsio card page
When a Chelsio card is selected in the tree menu on the left, this page is displayed. It provides
details of the card and associated settings. It also displays any card specific statistics that the
hardware provides. The modules available on this page are as below:
Card summary
This module provides PCI, firmware and other details of the card. The card's serial number and
factory MAC address are also provided for inventory purposes.
Chelsio T5/T4 Unified Wire For Linux
Page 306
