CHAPTER 1 – Introduction
- Hardware Monitor: Winbond W83781D
- IrDA: One 1x6 Pin-header
- Keyboard connector: PS/2 keyboard connector
- Mouse connector: PS/2 Mouse connector
- VGA Connector: C&T 69000 Controller, 15 pin D-type VGA
Connector
- LCD: C&T 69000 Controller, 41pin VESA Connector (for OEM)
- LAN: Intel 82559 LAN controller, RJ-45 connector
- SSD: DIP socket supports DiskOnChip flash disks (2MB~144MB)
- RTC: battery backup by Lithium Battery (CR2032)
Specification
Nominal Voltage
Nominal Capacity
Nominal Weight
1.2 Mechanical & Environmental
- POWER CONSUMPTION
(Pentium III 700MHz)
+5VDC @6.50A Max.
+12VDC @250mA Max.
+3.3VDC @4.00A Max.
(Celeron 566MHz)
+5VDC @4.50A Max.
+12VDC @250mA Max.
+3.3VDC @3.50A Max.
- OPTERATING TEMPERATURE: 0 ~ 60ºC.
- STORAGE TEMPPERATURE: - 40 ~ 80ºC.
- HUMIDITY: 10% to 90%
2
The coin type Lithium battery specification is shown in table
CR2032
3V
220mAh
3.1g
PC-686 (CPCI)-LV User's Manual
