IMPORTANT NOTE: Before you enter any new calibration values, always click the
―Reset‖ button, otherwise the new values get added to the old ones. Before you enter any
new values, the bar at the very top of the screen should read: XY: 0.00 deg / XZ: 0.00 deg.
Next, take down the Front Centre ‗L' shaped component, and measure its
deviation. Put the exact value into the Z box. If it deviates to the right side, the
value to be put into the Z box will be a positive value. If the deviates to the left,
the value to put into the Z box will be a negative value.
Finally, measure the height of Front Center component, which should be
40 mm if it is not scaled. Enter the exact measured value into the ―H‖ box of the
―Calibrate‖ dialogue box.
Click ―OK‖ to record all these values and exit the calibration window.

6.3 Cleaning the nozzle

After a lot of printing, the nozzle may be covered with a layer of oxidized ABS.
When the printer is printing, this oxidized ABS may melt on the nozzle, and may
create discolored spots the model. To avoid this you need to regularly clean the
nozzle.
Firstly, preheat the nozzle in order to melt the oxidized ABS. Use the ―Extrude‖
button on the ―Maintain‖ dialogue box, then lower the platform to the bottom.
Lastly, use some heat-resistant material, like 100 percent cotton cloth or soft
paper. A pair of tweezers will also be required. Then clip paper or some other
heat-resistant things with tweezers to clean up the nozzle.
