Installation

3
Ensuring the correct installation is the
customer's responsibility.
Location.
The dryer should be located in a well
•
ventilated room, away from heat sources
such as gas, oil or coal fired appliances.
Position the dryer on a flat, even,
•
uncarpeted floor.
Ensure that the rear wall of the dryer
•
does not touch any protrusions such as
taps, sockets and pipes.
Ensure that an electrical supply point is
•
within easy reach of the power cord.
Levelling.
The dryer must be levelled to ensure
•
vibration-free operation
Level the dryer by turning the adjustable
•
feet either in or out.
Never remove the adjustable feet.
•
Draining accumulated water
The dryer is equipped with a condenser
unit. Water accumulates in the water tank
during the drying process. This water
should be drained after each drying cycle.
This may be done manually by removing
and emptying the water tank or water may
be drained automatically through the drain
hose supplied.
Connecting the water drain hose
Remove one end of the hose attached to
•
the dryer as shown
Connect the drain hose supplied with the
•
dryer to the vacated pipe fitting as
shown.
The other end of the hose should be
•
attached to a dedicated drain or basin the
maximum height of which should not
exceed 80 cm.
Secure all hose ends as a loose end could
•
flood your home.
Do not bend, twist or kink the drain hose.
•
Electrical connection.
The dryer must be plugged into a
•
dedicated
socket.
Do not use a double adaptor.
•
The manufacturer and seller do not accept
•
responsibility for any damage due to
incorrect electrical connection.
If the power cord needs replacing, use
•
only a genuine type 'X' cord available from
the nearest Defy Service Centre. The
power cord must only be replaced by an
authorised service agent to avoid an
electrical hazard.
Page 5
230V. 16A. earthed wall
