- Page 1 DCY 8402 GM TUMBLE DRYER CONDENSER TECHNOLOGY...
-
Page 2: Please Read This User Manual First
Dear Customer, Thank you for prefering a Defy product. We hope that your product which has been manufactured with high quality and technology will give you the best results. We advise you to read through this manual and the other accompanying documentation carefully before using your product and keep it for future reference. -
Page 3: Important Instructions For Safety And Environment
Important instructions for safety and environment This section contains safety instructions that will help protect from risk of personal injury or property damage. Failure to follow these instructions shall void any warranty. 1.1 General safety • The dryer can be used by children at and above 8 years old and by persons whose physical, sensory or mental capabilities were not fully developed or who lack experience and knowledge provided that they are supervised or trained on the safe usage of the product and the risks... -
Page 4: Electrical Safety
Important instructions for safety and environment 1.1.1 Electrical safety Electrical safety instructions should be followed while electrical connection is made during the installation. • Connect the dryer to a grounded outlet protected by a fuse at the value specified on the type label. Have the grounding installation performed by a qualified electrician. -
Page 5: Product Safety
Important instructions for safety and environment 1.1.2 Product safety Points to be taken into consideration for fire hazard: Below specified laundry or items must not be dried in the dryer considering fire hazard. • Unwashed laundry items • Items soiled with oil, acetone, alcohol, fuel oil, kerosene, stain removers, turpentine, paraffin or paraffin removers must be washed in hot water with plenty of detergent before being dried in the dryer. - Page 6 Important instructions for safety and environment • You must provide enough ventilation in order to prevent gases exiting from devices operating with other types of fuels including the naked flame from accumulating in the room due to the back fire effect. Underwear that contains metal reinforcements should not be dried in the dryer.
-
Page 7: Mounting Over A Washing Machine
Important instructions for safety and environment 1.2 Mounting over a washing machine • A fixing device should be used between the two machines when installing the dryer above a washing machine. The fitting device must be installed by the authorized service agent. • Total weight of the washing machine and the dryer -with full load- when they are placed on top of each other reaches to approx. -
Page 8: Intended Use
Important instructions for safety and environment 1.3 Intended use • Dryer has been designed for domestic use. It is not suitable for commercial use and it must not be used out of its intended use. • Use the dryer only for drying laundry that are marked accordingly. • The manufacturer waives any responsibility arisen from incorrect usage or transportation. -
Page 9: Compliance With Rohs Directive
Important instructions for safety and environment 1.5 Compliance with the WEEE regulation and disposing of the waste product This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equipment (WEEE). This product has been manufactured with high quality parts and materials which can be reused and are suitable for recycling. -
Page 10: Technical Specifications
Important instructions for safety and environment 1.7 Technical Specifications Height (Min. / Max.) 84,6 cm / 86,6 cm* Width 59,5 cm Depth 60,9 cm Capacity (max.) 8 kg** Net weight (plastic front door usage) 38 kg Net weight (glass front door usage) 40 kg Voltage Rated power input... -
Page 11: Your Dryer
Your Dryer 2.1 Package Contents 1. Water drain hose * 2. Filter drawer spare sponge* 3. User Manual 4. Drying basket* 5. Drying basket user manual* *It can be supplied with your machine depending on its model. Dryer / User Manual 11 / 28 EN... -
Page 12: Removing The Transportation Safety Assembly
Installation 3.2 Removing the transportation Before the calling the nearest Authorized Service for the safety assembly installation of the dryer, ensure that electrical installation and water drain is appropriate referring to the user's Remove the transportation safety manual.(See 3.3 Connecting to the drain and 3.5 assembly before using the dryer for the Electrical connection) If they are not suitable, contact first time. -
Page 13: Electrical Connection
Installation 3.5 Electrical connection For specific instructions for electrical connection required during installation (see 1.1.1 Electrical Safety) 3.6 Transportation of the dryer Unplug the dryer before transporting it. Drain all water that has remained in the dryer. If direct water drain connection is made, then remove the hose connections. -
Page 14: Laundry Not Suitable For Drying In The Dryer
Preparation 4.1 Laundry suitable for drying in the dryer Always obey the instructions given on the garment tags. Dry only the laundry having a label stating that they are suitable for drying in a dryer and make sure that you select the appropriate programme. LAUNDRY DRYING SYMBOLS Drying Suitable for... -
Page 15: Correct Load Capacity
Preparation • Clean the lint filter before or after each drying Following weights are given as examples. cycle. (See 6.1 in Maintenance and cleaning) Approximate weights • Clean the condenser regularly at least once every Laundry (g)* (See 6.4 in month or after every 30 drying cycles. -
Page 16: Operating The Product
Operating the product 5.1 Control panel Program selection knob Remaining duration indicator On/Off button Start/pause button End duration button Sound warning button 5.2 Screen symbols Tank Buzzer/ Audible Anti Child-proof Filter full cancel warning Creasing lock cleaning Dryer / User Manual 16 / 28 EN... -
Page 17: Program Selection
Operating the product 5.3 Preparing the machine 5.5 Main programs Plug in the machine The main programs are given below based on fabric Place laundry inside the machine. type. Press the On/Off button. • Cotton When your machine turns on for the first time, Dry durable laundry with this program. -
Page 18: Timed Programs
Operating the product It is recommended to dry your delicates in laundry bag to prevent wrinkles and damage. When the program ends, take your laundry out of the machine immediately and hang them to prevent wrinkles. • Refresh It only performs ventilation for 10 minutes without blowing hot air. -
Page 19: Program Selection And Consumption Table
Operating the product 5.7 Program selection and consumption table Spin speed in washing Approximate amount Programs Capacity (kg) Drying time (minutes) machine (rpm) of remaining humidity Cottons / Coloreds Extra dry 1000 % 60 Cupboard dry 1000 % 60 Iron dry 1000 % 60 Shirts 15 min... -
Page 20: Warning Symbols
Operating the product 5.8 Auxiliary functions Loading door open Start/Pause led blinks when the loading door of the Sound warning cancel drying machine is open. Drying machine makes sound warnings when the program is completed. If you don’t want sound 5.10 End duration notifications, press the “Sound Notification”... -
Page 21: Starting The Program
Operating the product Canceling the end duration function 5.13 Changing the program after it is If you want to cancel the end duration setting started countdown and start the program right away: After the machine starts running, you can change Cancel the program by pressing the On/Off button. -
Page 22: Program End
Operating the product 5.14 Canceling the program If you want to cancel the program and end the drying operation for any reason after the machine starts running, press the On/Off button. As it will be extremely hot inside the machine when you cancel the program while the machine is in operation;... -
Page 23: Maintenance And Cleaning
Maintenance and cleaning Service life of product extends and frequently experienced problems will be reduced if it is cleaned at regular intervals. 6.1 Cleaning Lint Filter / Loading Door Inner Surface Lint and fiber released from the laundry to the air during the drying cycle are collected in the Lint Filter. -
Page 24: Draining The Water Tank
Maintenance and cleaning • Drain the water in the tank. Never use solvents, cleaning agents or similar substances for cleaning due to the risk of fire and explosion! • If there is lint accumulation in the funnel of the water tank, clean it under running water. •... - Page 25 Maintenance and cleaning 2. Unlock the 2 condenser locks after opening the kick 5. Place the condenser in its housing. Fasten the 2 locks plate. and make sure that they are seated securely. 6. Close the kick plate cover. 3. Pull out the condenser. 4.
-
Page 26: Troubleshooting
Troubleshooting Drying process takes too much time. Pores of the lint filter are clogged. >>> Wash the lint filter with warm water. Condenser may be clogged. >>> Clean the Condenser Remove the objects (if any) that block Ventilation grids on the front side of the machine are blocked. >>> ventilation in front of the ventilation grids. - Page 27 Troubleshooting Lint Filter Cleaning symbol is flashing. Filter housing is clogged with lints. >>> Clean the lint filter housing. A deposit has built up on the lint filter pores that may cause clogging. >>> Wash the lint filter with warm water. Condenser may be clogged.
