- Page 1 GPS Dongle 48 channels ® With Data Logger Function Hardware User’s Manual...
- Page 2 General description of what GPS is and how it works ¾ GPS (Global Positioning System) is the only system today able to show you your exact position on the Earth anytime, in any weather, anywhere. GPS satellites, 24 in all, orbit at 11,000 nautical miles above the Earth. They are continuously monitored by ground stations located worldwide.
- Page 3 1. Introduction The GPS USB Dongle Receiver is a total solution of GPS receiver with SIRF IV serial ; 48 channels all-in-view tracking technology. This GPS USB Dongle Receiver can communicate with other electronic devices by USB interface. The GPS USB Dongle Receiver is designed as an ultra low power consumption device, and high position accuracy. It will update the satellite position every second.
-
Page 4: Features And Functions
2) The GPS receiver is not in use for more than 3 months or transportation over distances further than 500 kilometers. 3) Charge Li-Polymer battery. 2. Features and Functions 1) SIRF IV serial simultaneous time-frequency search bins. Signal detection better than -163dBm 2) Cold start <... -
Page 5: Check The Package Content
Check the Package Content Before you start using, please check out if your package includes the following items. If any item is damaged or missed, please contact your reseller at once. • GPS USB Dongle receiver/Data Logger Device X 1 •... -
Page 6: Power On/Off
the Yellow LED will be turned off. Unplug car charger or AC adapter from power jack. Power ON/OFF Slid power switch to ON/OFF the power. Connect to your PC 1) Plug USB connector(1) into Laptop USB port, see Fig 1.1 Fig 1.1... - Page 7 2) Install USB driver, users can find the USB driver on the attached DVD (file name: GPS USB Dongle driver), the USB driver can be installed for Microsoft Windows, XP, Vistar , Linux and Mac system. User can easily install USB driver, the USB driver can automatically install the driver when user execute it.
-
Page 8: Led Display
LED Display Yellow LED indicates battery is in charging. Red LED Flashing 1sec. ON/1 sec. OFF indicates slow battery power. The blue light on---------device is on but position is not fixed. Flashing 1sec. ON/2 sec. OFF----------position is fixed. Flashing fast---------Data tag to set point successful GPS/Data Tag Setting Status (push for 1~2 second) Power Switch... - Page 9 It is possible unable to receive GPS signal or signal low in these places: ¾ Beside some buildings, GPS signal ¾ Inside the tunnel, GPS signal is blocked. is low or disturbed. ¾ Inside forests, or too many covers, ¾ Covers above, GPS signal are blocked.
- Page 10 Used equipment must be disposed of in compliance with current environmental protection regulations. You should return it to your reseller or dispose of it in an approved recycling centre. DECLARATION: We hereby declare that this product complies with essential requirements and other related requirements, of the 1999/5/EC R&TTE directive and particularly with article 3 sections 1a, 1b and 3.
