Page 1: Gps Receiver
CanMore Bluetooth GPS Receiver GT-750F User Manual Version 1.0... -
Page 3: Table Of Contents
TABLE OF CONTENTS 1.Product Introduction ......................5 1.1 Overview................................5 1.2 Features ................................5 1.3 Technology Specification............................6 1.3.1 Physical Dimension…………………………………………………………………………………………………………… 1.3.2 Product Notification…………………………………………………………………………………………………………… 1.3.3 Electrical Characteristics…………..…………………………………………………………………………………………..6 1.3.4 Performance……….……………………………………………………………………………………………………………..7 1.3.4.1 GPS……….…………………………………………………………………………………………………………… 1.3.4.2 Bluetooth...…………………………………………………………………………………………………………… 1.3.4.3 Battery….……………………………………………………………………………………………………………… 1.4 Application ................................2. Before Start........................8 2.1 Check the Package Content..........................2.2 Power Switch …………………………………………………………………………………….......... - Page 4 2.4.3. Bluetooth Status LED (blue) ........................11 2.4.4. GPS Status LED (Green)...........................11 2.4.5. Battery Status LED (Red/Yellow)......................12 2.5. Getting Started..............................12 2.5.1. STEP 1:Charge the Battery........................2.5.2. STEP 2:Turn on Receiver and Wait for GPS Fix…………………………………………………………………..12 2.5.3. STP3:Connect to Bluetooth-Enabled Devices……………………………………………………………………..13 2.5.4.
-
Page 5: Product Introduction
The GT-750F is a single board of Bluetooth-GPS receiver for customers who require easy system integration and minimal development risk. The GT-750F is optimized for good performance and low cost. Its 44 parallel channels and Venus520 search bins provide short start-up time and fast signal acquisition. Having fast time-to-first-fix and high sensitivity, the GT-750F offers good navigation performance even in urban canyons. -
Page 6: Technology Specification
Cold start < 40 seconds at –135dBm Hot start < 1sec under open sky 5m CEP accuracy SBAS (WAAS, EGNOS) support Bluetooth version 2.0 compliant Compatible with Bluetooth devices with Serial Port Profile (SPP) Charger circuitry and battery socket for N3650 Li-ion battery More than 13 hours of operation Dimension:73x44x21 mm 1.3 Technology Specification... -
Page 7: Performance
ackup power: 3V For battery socket Li-ION rechargeable battery (1000 mA) 1.3.4 Performance 1.3.4.1 GPS Receiver Type 44 parallel channel, L1 C/A code Accuracy Position 5m CEP Velocity 0.1m/sec Startup Time < 1sec hot start < 40sec cold start Signal Reacquisition Sensitivity -145dBm acquisition -158dBm tracking... -
Page 8: Battery
PDAand Cellular Phone Navigation Navigation and positioning Automotive Vehicle Tracking Personal Positioning Sporting and Recreation 2.Before Start 2.1 Check the Package Content Before you start using GT-750F, please check out if your package includes the following tems. If any item isdamaged or... -
Page 9: Power Switch
GT-750F Bluetooth GPS receiver CarCharger User manual CD AC Adapter(optional) 2.2 Power Switch :Push the power switch is on/off Power switch On/Off... -
Page 10: Led Display
2.3 LED Display Battery and charger status Bluetooth status GPS status... -
Page 11: Hardware Features
Yellow LED indicate slow power Red LED indicates power is in charging Flashing quickly(every onec for 2 second)-Position is fixed. Flashing slowly(every onec for 3 second)-device is on but position is not fixed. Flashing quickly(every onec for 2 second)-Position is fixed. Flashing slowly(every onec for 3 second)-device is on but position is not fixed. -
Page 12: Battery Status Led (Red/Yellow)
2.5.1. STEP1:Charge the Battery Before you use GT-750F, the battery must be charged for at least 2 hours. Plug car charger into power jack and cigar-lighter separately when is in charging, the Red LED will be lighted up. When the battery is fully charged, the Red LED will be turned off. -
Page 13: Stp3:Connect To Bluetooth-Enabled Devices
From your Bluetooth-enabled handheld device, execute Bluetooth application software to search GT-750F and then connect it to your device. If the connection between your device and GT-750F is successful, the Blue LED Flashing slowly(every onec for 3 second)-Bluetooth are transmiting data. -
Page 14: Bluetooth Connection
Plug adapter connector into handheld device connector and plug car charger into cigar-lighter. 3. Bluetooth Connection The pass word is “0000” Please follow below instructions step by step: 3.1 Turn on the Device Turn the power switch on. The Bluetooth Status LEDs(Blue LED) and GPS Status LED (Orange LED) will immediately light up. -
Page 15: Browse Services
3.3Browse Services: Double click the device with which you want to establish SPP connection to browse its service Connect to SPP Slave Select SPP slave Click “Next” Click “Finish” Finish Bluetooth Manager Setup Tap and Hold “Rikaline: SPP slave” Click “Connect” Finish Bluetooth setup... -
Page 16: Application
Application: Now you can use any Navigation system through Bluetooth SPP Profile. - Page 17 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. This device must accept any interference received, including interference that maycause undesired operation. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment.
