ACTi KCM-5111 User Manual

H.264 4-megapixel ip d/n poe box camera (dc 12v / poe)
Hide thumbs Also See for KCM-5111:
Table of Contents

Advertisement

Quick Links

Download this manual
KCM-5111
H.264 4-Megapixel IP D/N PoE
Box Camera
(DC 12V / PoE)
Ver. 2011/3/21

Advertisement

Table of Contents
loading

Related Manuals for ACTi KCM-5111

Summary of Contents for ACTi KCM-5111

  • Page 1 KCM-5111 H.264 4-Megapixel IP D/N PoE Box Camera (DC 12V / PoE) Ver. 2011/3/21...

  • Page 2: Table Of Contents

    KCM-5111 Hardware User’s Manual Table of Contents Precautions Introduction Package Contents ................4 Features and Benefits ............... 5 Safety Instructions ................6 Physical description ................8 Basic Connections ................10 Product Specification ..............12 Accessing Camera If you have DHCP server / router in your network: ...... 14 If you do NOT have DHCP server / router in your network: ..

  • Page 3: Precautions

    KCM-5111 Hardware User’s Manual 0. Precautions Read these instructions You should read all the safety and operating instructions before using this product. Heed all warnings You must adhere to all the warnings on the product and in the instruction manual. Failure to follow the safety instruction given may directly endanger people, cause damage to the system or to other equipment.

  • Page 4: Introduction

    KCM-5111 Hardware User’s Manual 1. Introduction Package Contents KCM-5111 Power Adaptor Product CD Terminal Blocks for Power & DI/O Accessories Warranty Card *For the mounting block, please attach it flat side to the front of camera. There are two types of mounting blocks, and this device uses the black version.

  • Page 5: Features And Benefits

    KCM-5111 Hardware User’s Manual Features and Benefits This is a cutting edge network video surveillance camera. It can capture, compress and transmit real time video in excellent quality (8 FPS 4Megapixel, 2032 x 1920). This camera is your best choice to build an intelligent IP surveillance system.

  • Page 6: Safety Instructions

    KCM-5111 Hardware User’s Manual Software Development Kit Support This IP Box Camera can be integrated or controlled by applications from third party software developers. Software developers can save considerable efforts by using our Streaming Library or ActiveX control. Safety Instructions Don’t use the power supply with other voltages...
  • Page 7 KCM-5111 Hardware User’s Manual qualified service personnel under the following conditions. 1) When the power-supply cord or plug is damaged 2) If liquid has been spilled, or objects have fallen into the video product. 3) If the video product has been directly exposed to rain or water.

  • Page 8: Physical Description

    KCM-5111 Hardware User’s Manual Physical description 1) Digital Input / Output Used in applications like motion detection, event triggering, time lapse recording, alarm notifications, etc., the I/O terminal connector provides the interface to: • 2 Transistor Outputs - For connecting external devices such as relays and LEDs.
  • Page 9 KCM-5111 Hardware User’s Manual pins to GND pins, and DO pins to 12V pins. Link pins 1/3, 2/4, 5/7,6/8. 2. Once cables are connected, push connector block into the terminal connector on camera. 3.3V FUSE 1A DC TO DC CONVERTER...
  • Page 10 KCM-5111 Hardware User’s Manual Restore to Default Power On Complete On (3s) Off (about 15s) Off (10~15s) Stay On About 20 Seconds 5) Audio Input / Output The IP device supports audio input and output with earphone jack 6) Micro SD / Micro SDHC Card...

  • Page 11: Basic Connections

    KCM-5111 Hardware User’s Manual Basic Connections Follow the procedures below to connect the IP device to the respective apparatuses. If you have a PoE(Power over Ethernet) supported switch or injector: 1) Connect your IP Box Camera to the Switch / Injector by CAT5 or CAT6 cables with RJ45 connector.

  • Page 12: Product Specification

    KCM-5111 Hardware User’s Manual Product Specification KCM-5111 • Device Device Type Box Camera Image Sensor BSI Progressive Scan CMOS 1/3.2 “ (4.5 x 3.4 mm) Sensor Size Horizontal Resolution 1561 TVL Day / Night Minimum Illumination Color: 0.1 lux at F2.0 (30 IRE, 2400°K); B/W: 0.05 lux at F2.0 (30 IRE, 2400°K)
  • Page 13 KCM-5111 Hardware User’s Manual • Alarm Video motion detection 3 regions in single view mode, 1 region each in 4 cropped Alarm Trigger VGA mode; External device through digital input Notify control center; Change camera settings; Command other devices; E-mail Alarm Response notification with snapshots;...

  • Page 14: Accessing Camera

    KCM-5111 Hardware User’s Manual 2. Accessing Camera If you have DHCP server / router in your network: Many network server / routers are able to automatically provide IP addresses through DHCP. If you are using such a network, just plug in your computer and IP Box Cam into the network and your IP device will acquire network address by itself.
  • Page 15 KCM-5111 Hardware User’s Manual Please set the settings as below.   IP address: 192.168. 0.xxx  Subnet mask: 255.255.255. (NOTE: xxx should be a number from 1 to 254 except 100, which is used by the IP device. Please also...
  • Page 16 KCM-5111 Hardware User’s Manual If you are using a single camera, this is enough to access the device. If you are using multiple devices, you need to change the current device to another unused IP address, so that when the next device is connected to the network, no two devices use the same IP.
  • Page 17 KCM-5111 Hardware User’s Manual 10. Click “Apply” 11. Please go to Maintain -> Save & Reboot, and click ”Apply”. Internet Explorer will close after a few seconds. This is normal. 12. Wait for 30 seconds, and open IE again to connect to the IP.
  • Page 18 KCM-5111 Hardware User’s Manual www.acti.com...
