ACTi KCM-7911 Installation Manual
Outdoor hemispheric mounting on a vertical pole using the tilted mount
Hide thumbs
Also See for KCM-7911:
- Hardware user manual (19 pages) ,
- Hardware manual (32 pages) ,
- Installation manual (34 pages)
Subscribe to Our Youtube Channel
Related Manuals for ACTi KCM-7911
Summary of Contents for ACTi KCM-7911
- Page 1 Outdoor Hemispheric Mounting on a Vertical Pole Using the Tilted Mount Installation Guide For Models: KCM-7911 2013/12/03...
-
Page 2: Table Of Contents
Step 6: Close the Cover ................19 Step 7: Access the Camera Live View ............ 19 Appendices ............... 20 Connecting a Power Adaptor (Optional) ..........20 Connecting DI/DO Devices (Optional) ............ 22 Connecting Audio In / Out Devices (Optional) ........25 Safety Information ............26 www.acti.com... -
Page 3: Mounting Solutions
Installation Using Flexible Conduit: This installation uses the supplied conduit gland and a 3/8” flexible conduit (not supplied). This is the recommended solution if other input / output devices or an external power adaptor will be connected to the camera. www.acti.com... -
Page 4: Installation Procedures Using Naked Cable
Step 1: Attach the Pole Mount Kit 1. Using a screwdriver, turn the screw head of the wire strap counter-clockwise continuously until the two ends are detached. 2. Insert the wire strap through the strap holes of the pole mount. www.acti.com... - Page 5 The wire straps can hold between 134 ~ 228 mm (5.28 ~ 9 in.) pole diameter. 5. Continuously turn the screw head clockwise to adjust the wire strap until it snugly fits the pole. Do the same to the other wire strap. www.acti.com...
-
Page 6: Step 2: Attach The Tilted Mount
Step 3: Prepare for Waterproof Installation 1. Remove the cap covering the bottom hole of the camera, and attach the cap to the side hole to close it. The network cable will pass through the bottom hole. www.acti.com... - Page 7 Sealing Insert Clamping (with Washer) with Claw 3. Insert the clamping nut into the Ethernet cable of the camera side. 4. Insert the sealing insert with claw. 5. Attach the cable gland body to the hole of the camera. www.acti.com...
-
Page 8: Step 4: Open The Camera Cover
Step 4: Open the Camera Cover 1. Loosen the three (3) screws using the supplied hex wrench. 2. Lift to open the cover. NOTE: Do not abruptly lift the cover; it is attached to the camera body with a spring wire. www.acti.com... -
Page 9: Step 5: Connect The Cable(S)
2. Insert the sealing insert with claw into the cable gland body and then attach the clamping nut to complete the cable solution. NOTE: Make sure the clamping nut is tightly attached to the cable gland body. www.acti.com... -
Page 10: Step 6: Install The Camera To The Tilted Mount
3. Attach the camera to the tilted mount using the three (3) screws supplied in the Tilted Mount package. Rubber Ring NOTE: Make sure the tilted mount screws have rubber rings. If the screws you received do not have rubber rings, please contact your local sales agents or our Customer Help Desk (CHD) for support. www.acti.com... -
Page 11: Step 7: Close The Cover
Step 7: Close the Cover Tighten the three (3) screws to secure the cover. Step 8: Access the Camera Live View For information on how to access the camera Live View, download the camera Hardware Manual from the website (http://www.acti.com). www.acti.com... -
Page 12: Installation Procedures Using Flex Conduit
Step 1: Attach the Pole Mount Kit 1. Using a screwdriver, turn the screw head of the wire strap counter-clockwise continuously until the two ends are detached. 2. Insert the wire strap through the strap holes of the pole mount. www.acti.com... - Page 13 The wire straps can hold between 134 ~ 228 mm (5.28 ~ 9 in.) pole diameter. 5. Continuously turn the screw head clockwise to adjust the wire strap until it snugly fits the pole. Do the same to the other wire strap. www.acti.com...
-
Page 14: Step 2: Attach The Tilted Mount
1. Remove the cap covering the bottom hole of the camera, and attach the cap to the side hole to close it. The network cable will pass through the bottom hole. 2. Loosen the three (3) screws using the supplied hex wrench. www.acti.com... -
Page 15: Step 4: Prepare For Waterproof Installation
2. Pull the Ethernet cable and other cables (if any) through the flex conduit. NOTE: To connect an external power adaptor, audio in/out, or digital input/output (DI/DO) devices, insert the cables without connectors through the flex conduit together with the Ethernet cable at this point. www.acti.com... - Page 16 3. From the network side, route the flex conduit to pass through the pole mount and tilted mount. 4. Insert the clamping nut through the flex conduit. 5. Insert the sealing rubber and attach it at the end of the flex conduit. 6. Attach the conduit gland body to the hole of the camera. www.acti.com...
- Page 17 DI/DO devices, connect the terminal blocks at this point and connect them to the corresponding connectors of the camera (see Appendices on page 20 for more information). 12V Power Connector Digital Input / Output (DI/DO) Connector Audio Input / Output Connector www.acti.com...
- Page 18 NOTE: Make sure the clamping nut is tightly attached to the conduit gland body. 11. Align the camera to the tilted mount as the flex conduit is pushed through the cable hole of the tilted mount and pole mount. www.acti.com...
-
Page 19: Step 5: Install The Camera To The Tilted Mount
Step 6: Close the Cover Tighten the three (3) screws to secure the cover. Step 7: Access the Camera Live View For information on how to access the camera Live View, download the camera Hardware Manual from the website (http://www.acti.com). www.acti.com... -
Page 20: Appendices
1. Loosen the screws of the 12V and GND pins of the power terminal block. 2. Take note that a standard power adaptor cable has two (2) different wires: Connects to GND Pin White stripe: Connects to 12V Pin www.acti.com... - Page 21 4. Tighten the screws of the 12V pin and the GND pins to secure the wire connection. 5. Set the prepared power adaptor for connection later. Below is an example of a power adaptor with an attached terminal block. NOTE: The power adaptor is not bundled in the package. www.acti.com...
-
Page 22: Connecting Di/Do Devices (Optional)
Connect the wires of the first input device to GND Digital Input 1 (Pin 1) and DI1 (Pin 3). (DI1) Connect the wires of the second input device to GND Digital Input 2 (Pin 5) and DI2 (Pin 7). (DI2) www.acti.com... - Page 23 In this case, wire connection to Pins 1 to 4. Use the GND and DI1 pins to connect a DI device and use the 12V and DO1 pins to connect a DO device. See wiring scheme below: Consequently, to connect a second DI or DO device, wire the connection to Pins 5 to 8. www.acti.com...
- Page 24 The illustration below is a graphic example of connecting a relay to a high voltage DO device. 110V-220V AC External Power Source Relay (DO1 Device) Camera Illuminator NOTE: For more information on DI/DO connections, please refer to the Knowledge Base article All about Digital Input and Digital Output downloadable from the link below (http://www.acti.com/kb/detail.asp?KB_ID=KB20091230001). www.acti.com...
-
Page 25: Connecting Audio In / Out Devices (Optional)
Press and hold the orange tab as you insert the wire through the pin slot, then release the orange tab to secure the wire. NOTE: For more information about AUDIO in connections, please refer to the Knowledge Base article How to Use Audio-in of ACTi Cameras, downloadable from the link below (http://www.acti.com/support/KnowledgeBase/outside/detail.asp?KB_ID=KB20100114003). www.acti.com... -
Page 26: Safety Information
Do not use attachments not recommended by the video product manufacturer as they may cause hazards. Do not use accessories not recommended by the manufacturer Only install this device in a dry place protected from weather Servicing Do not attempt to service this video product yourself. Refer all servicing to qualified service personnel. www.acti.com... - Page 27 Safety Check Upon completion of any service or repairs to this video product, ask the service technician to perform safety checks to determine if the video product is in proper operating condition. www.acti.com...
