For DCBD(30/50/80)KC-10/39 Series Dryers
The dryer must not be stored or installed where it will be exposed to water and/or weather.
WARNING: For your safety the infor-
mation in this manual must be fol-
lowed to minimize the risk of fire or
explosion or to prevent property dam-
age, personal injury or loss of life.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other
appliance.
– WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Clear the room, building or area of all
occupants.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the
fire department.
– Installation and service must be performed by a
qualified installer, service agency, or the gas
supplier.
Post the following "For Your Safety" caution in a
prominent location:
FOR YOUR SAFETY
Do not store or use gasoline or other flammable
vapors or liquids in the vicinity of this or any other
appliance.
It is important that you read this Manual and retain it
for future reference. For service or replacement parts,
contact
the
distributor
manufacturer.
OPERATOR'S MANUAL
in
your
area
or
Dexter Laundry, Inc.
2211 West Grimes Avenue
Fairfield, Iowa 52556 USA
AVERTISSEMENT. Assurez-vouz de
bien suivre les instructions données
dans cette notice pour réduire au
minimum le risque d'incendie ou
d'explosion
dommage matérial, toute blessure
ou la mort.
Ne pas entreposer ni utiliser d'essence ni d'autres
vapeurs ou liquides inflammables dans le voisinage
de cet appareil ou de tout autre appareil.
– QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE
GAZ:
• Ne pas tenter d'allumer d'appareil.
• Ne touchez à aucun interrupteur. Ne pas
vous servir des téléphones se trouvant dans
le bâtiment où vous vous trouvez.
• Évacuez la pièce, le bâtiment ou la zone.
• Appelez immédiatement votre fournisseour
de gaz depuis un voisin. Suivez les
instructions du fournisseur.
• Si vous ne pouvez rejoindre le fournisseur
de gaz, appelez le service des incendies.
– L'installation et l'entretien doivent être assurés par
un installateur ou un service d'entretien qualifié
ou par le fournisseur de gaz.
Ne pas enteposer ni utiliser d'essence ni d'autres
vapeurs ou liquides inflammables dans le voisinage
de cet appareil ou de tout autre appareil.
You, the purchaser, must post in a prominent
location instructions to be followed in the event the
the
user smells gas. Consult your local gas supplier
for procedure to be followed if the odor of gas is
present.
ou
pour
éviter
POUR VOTRE SÉCURITÉ
8514-208-001C
May 2012
tout

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DCBD 30 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dexter Laundry DCBD 30 Series

  • Page 1 Consult your local gas supplier manufacturer. for procedure to be followed if the odor of gas is present. Dexter Laundry, Inc. 2211 West Grimes Avenue Fairfield, Iowa 52556 USA...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS PAGE NO. DRYER DIMENSIONS (Figure 1)............3 DRYER CAPACITIES................6 UNCRATING..................6 DRYER INSTALLATION................ 6 DRYER EXHAUST SYSTEM (Figure 2)............ 10 DRYER SHUTDOWN................10 OPERATING INSTRUCTIONS..............11 SERVICING AND TROUBLESHOOTING DRYER........16 PREVENTATIVE MAINTENANCE............17 WARNINGS ABOUT USE AND OPERATION It is ABSOLUTELY ESSENTIAL that the dryer be grounded to a known earth (zero) ground.
  • Page 3: Dryer Dimensions (Figure 1)

    DRYER DIMENSIONS- FIGURE 1A - - 3...
  • Page 4 DRYER DIMENSIONS- FIGURE 1B - - 4...
  • Page 5 DRYER DIMENSIONS- FIGURE 1C - - 5...
  • Page 6: Dryer Capacities

    DRYER CAPACITIES Dryer Model Dry Weight Capacity DCBD30 30 lb (13.6 kg) DCBD50 50 lb (22.7 kg) DCBD80 80 lb (36.3 kg) INSTALLATION AND OPERATING INSTRUCTIONS COMMERCIAL DRYER UNCRATING Tools required: 3/4” hex socket and ratchet driver, knife, channel-lock wrench that opens to 1 3/8". 1.
  • Page 7 VERTICAL CLEARANCE DIMENSIONS – ALL DCBD(30/50/80) 3. MAKE-UP AIR. Adequate make-up air must be supplied to replace air exhausted by dryers on all types of installations. Provide a minimum air opening to the outside for each dryer as follows: Dryer Model Make-up Air Volume/Time Make-up Air Opening Area (minimum) DCBD30KC-10...
  • Page 8 flame present in clothes dryers. The decomposition products are highly corrosive and will cause damage to the dryer(s), ducts and clothes loads. 4. ELECTRICAL REQUIREMENTS. The electrical power requirements necessary to operate the unit satisfactorily are listed on the serial plate located on the back panel of each dryer. The electrical connection should be made to the terminal block in the rear control box assembly on the rear of the unit, using a wire size adequate to handle the amperage and voltage listed on the serial plate, but never smaller than No.12 AWG wire.
  • Page 9 CAUTION: The dryer and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psig. The dryer must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psig.
  • Page 10: Dryer Exhaust System (Figure 2)

    7. DRYER IGNITION (SOLID STATE IGNITION). The solid-state ignition system lights the main burner gas by spark. The gas is ignited and burns only when the gas-valve relay (in the electronic controller) calls for heat. The procedure for first-time starting of a dryer is as follows: A.
  • Page 11: Operating Instructions

    OPERATING INSTRUCTIONS 1. Deposit coins or tokens to satisfy vend price display of idle dryer. Each deposit decreases vend price until display changes to show time purchased. LOW light illuminates. 2. Select drying cycle. Other cycle selections may be made now or later by pressing the appropriate key (button).
  • Page 12: Description Of Controls

    DESCRIPTION OF CONTROLS Credit for coins or tokens inserted, dryer time, and temperature are controlled by an electronic controller. The large digital display shows vend price of an idle dryer, time purchased after coins or tokens are deposited, temperature, and program information. The three red indicator lights show the drying temperature selected.
  • Page 13: Programming Instructions

    PROGRAMMING INSTRUCTIONS: (To switch to program mode.) 1. Unlock the upper service door and raise it until it can be held in place by the pivoting wire support. 2. Open the loading door and leave open. 3. Push the Program Button found between the service panel and the board.
  • Page 14 ORDER OF PROGRAMMING STEPS: CYCLE LIGHTS DISPLAY PROGRAMMING STEP DESCRIPTION OPTIONS/RANGE OF LIMITS HOUR METER Displays the hours of the "timer" operation. May be reset to zero HIGH, MED, __ __ LEFT MONEY AUDIT Number of pulses from the left acceptor (dual coin models). May be reset to zero.
  • Page 15 CHANGING PROGRAM DATA Put the dryer in PROGRAM mode as instructed on page 13. The dryer remains in the PROGRAM mode until one of these actions occur: • The Program Button is actuated again. • The eighteenth step is completed and the "Start" button is pushed following the eighteenth step.
  • Page 16: Servicing And Troubleshooting Dryer

    If any of the following symptoms occur on this dryer, check the suggested remedies listed below. If all probable causes have been eliminated and the symptom still exists, contact your local Dexter agent for further troubleshooting assistance. See contact information in Preventative Maintenance section. Parts & Service Manuals from Dexter are also available for further troubleshooting assistance.
  • Page 17: Preventative Maintenance

    9822-026-001 9822-031-002 For service and parts information, contact your local Dexter agent. To find your local Dexter agent, use the Distributor Locator at the website shown below. If a Dexter agent is not available, contact Dexter Laundry, Inc. directly as listed below:...
