For DDAD30HC-59 Series Dryers
The dryer must not be stored or installed where it will be exposed to water and/or weather and is
suitable for use in room temperatures between 5C and 45C.
WARNING: For your safety the information in this manual must be followed to
minimize the risk of fire or explosion or to prevent property damage, personal
injury or death.
-Do not store or use gasoline or other flammable vapours and liquids in the vicinity of
this or any other appliance.
-WHAT TO DO IF YOU SMELL GAS
-Do not try to light any appliance.
-Do not touch any electrical switch: do not use any telephone in your building.
-Clear the room, building or area of all occupants.
-Immediately call your gas supplier from a neighbor's telephone. Follow the
gas supplier's instructions.
-If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or
the gas supplier.
You, the purchaser, must post in a prominent location instructions to be followed in the event the user smells
gas. Consult your local gas supplier for procedure to be followed if the odour of gas is present.
"For Your Safety"
Post the following
Do not store or use gasoline or other flammable vapours or liquids in the vicinity of this or any other appliance.
THIS MACHINE IS FOR DRYING ONLY FABRICS CLEANED IN WATER.
avoid possibility of fire, including spontaneous combustion, do not dry oiled floor mops, items
containing foam rubber or similarly textured rubberlike materials or any material on which you
have used a cleaning solvent or which contains flammable liquids or solids (such as petrol,
kerosene, waxes, etc.)
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance. It is important that you read this
Manual and retain it for future reference. For service or replacement parts, contact the distributor in your area or:
OPERATOR'S MANUAL
caution in a prominent location:
FOR YOUR SAFETY
FOR YOUR SAFETY
Dexter Laundry, Inc
2211 West Grimes Avenue
Fairfield, Iowa 52556
8514-201-001PR
03/01/2010
To

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DDAD30HC-59 Series Dryers and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dexter Laundry DDAD30HC-59 Series Dryers

Summary of Contents for Dexter Laundry DDAD30HC-59 Series Dryers

  • Page 1 8514-201-001PR 03/01/2010 OPERATOR'S MANUAL For DDAD30HC-59 Series Dryers The dryer must not be stored or installed where it will be exposed to water and/or weather and is suitable for use in room temperatures between 5C and 45C. WARNING: For your safety the information in this manual must be followed to minimize the risk of fire or explosion or to prevent property damage, personal injury or death.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS DRYER DIMENSIONS (Figure 1) UNCRATING INSTALLATION CLEARANCE (Figure 2) DRYER EXHAUST SYSTEM (Figure 3) DRYER SHUTDOWN TOUCH PAD LAYOUT (Figure 4) DRYER DEFAULT SETTINGS DRYER FAULT CODES TOUCH PAD DESCRIPTION OPERATING INSTRUCTIONS PROGRAMMING INSTRUCTIONS SERVICING DRYER PREVENTATIVE MAINTENANCE WARNINGS ABOUT USE AND OPERATION It is ABSOLUTELY ESSENTIAL that the dryer be connected to a good earth connection.

  • Page 3: Dryer Dimensions (Figure 1)

    Figure 1, 30# Stack Dryer Dimensions, inches (mm)

  • Page 4: Uncrating

    INSTALLATION AND OPERATING INSTRUCTIONS Note: Before installation, check that the local distribution conditions, nature of gas and pressure, and the adjustment of the appliance are compatible. UNCRATING AND PLACING DRYER Tools Required: 3/4" (19 mm) hex socket & ratchet driver, wood block 4" (100 mm) or 5" (125 mm) thick, a knife and a groove joint pliers, which will open to 1 3/8"...

  • Page 5: Installation Clearance (Figure 2)

    However 1/4 in. (6 mm) clearance should be allowed in case the dryer needs moving. C. A 10 in. (250 mm) clearance is required from top at all other points. VI. Floor This unit may be installed upon a combustible floor. Do not obstruct the flow of combustion and ventilation air.
  • Page 6 Adequate ventilation must be provided to avoid back flow of gasses from other appliances in the same room. All other gas appliances should be tested with the Dexter dryer in operation and all the windows and doors closed If in doubt, consult the appliance manufacturer(s).
  • Page 7 shall be made with a flexible hose suitable for the appliance category in accordance with national installation regulations. The size of the piping to supply the dryer should be determined by reference to national installation practice and consultation with the local gas supplier. A joint compound resistant to all fuel gases must be employed in making threaded pipe connections.
  • Page 8 CAUTION: The dryer and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of ½ psig (35 mbar). The dryer must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than ½...
  • Page 9 exhaust end of one pipe is inside the next one downstream. The addition of an exhaust pipe tends to reduce the amount of air the blower can exhaust. This does not affect the dryer operation if held within practical limits. For the most efficient operation, it is recommended that no more than 14 ft (4.25m) of straight 8 in.

  • Page 10: Dryer Exhaust System (Figure 3)

    DRYER SHUTDOWN To render the dryer inoperative, turn off the main gas shut-off valve and disconnect power to the dryer.

  • Page 12: Dryer Default Settings

    DRYER CONTROLLER FACTORY DEFAULT PROGRAM SETTINGS COOL TOTAL DRYING DOWN TIME CYCLE TIME TEMPERATURE DRYER LOAD CYCLE (MINUTES) (MINUTES) Towels, pads, heavy cotton Sheets, blended materials Cotton Synthetic materials Blended materials DRYER FAULT CODES FAULT FAULT# ACTION DESCRIPTION Dryer stops and “F1” flashes on the 4-digit display. When Shorted thermostat short circuit on sensor input is removed, “LOAd”...

  • Page 13: Touch Pad Description

    TOUCH PAD DESCRIPTION INDICATOR LIGHTS (L.E.D.s) Description Cycle (1 through 5) These L.E.D.s are on solid when a particular cycle is chosen for operation or programming. Gas Valve This L.E.D. is part of the 4-digit numeric display and will be on solid during the drying part of a cycle when the gas valve does not need to be on.
  • Page 14 SWITCHES (Pushbuttons) - continued Description This touch pad switch allows the dryer controller to enter the temporary programming mode. Cycle This touch pad switch will stop the dryer during a dry cycle without clearing the present drying cycle if pressed once. If pressed and released twice, consecutively, the present dry cycle will be cleared.

  • Page 15: Operating Instructions

    OPERATING INSTRUCTIONS To dry a load of items, you must choose one of the five-programmed dry cycles. Each of these five dry cycles may be modified in two different ways to match your load. Please refer to the “Permanent Dryer Controller Programming”...
  • Page 16 will repeat a total of 10 times, at which time the wrinkle free cycle stops. The cylinder will not rotate again until a new dry cycle is started. During the wrinkle free cycle the gas valve will not be operated and there will be no heat applied to the load.

  • Page 17: Programming Instructions

    The temporary programming mode will allow the change of the stored dry cycle settings in the dryer controller for one complete dry cycle. After the dry cycle is complete, the default settings that existed before the temporary change are restored. The temporary dry cycle can be stopped and cleared at any time during the dry cycle operation.
  • Page 18 display. 6) Press and release the UP or DOWN arrow keys to change the drying temperature. Each press and release of the arrow keys will either increase or decrease the temperature by five degrees Fahrenheit or three degrees Celsius, depending on how your dryer controller is set up. Once either of the arrow keys is pressed, the temperature L.E.D.
  • Page 19 PROCEDURE 1) After the load has been placed in the dryer, press and release the UP or DOWN touch pad key on the dryer controller until the L.E.D. for dry cycle 1 is illuminated. 2) Press and release the CYCLE key on the dryer controller touch pad. You will see the number “35” on the dryer controller display.
  • Page 20 in the dryer controller by pressing the default settings pushbutton on the back (component) side of the dryer controller circuit board. It is labeled and located at the lower middle side of the printed circuit board, as you face the component side of the board. It must be pressed and held down for at least three seconds.
  • Page 21 flash. If you press and hold either arrow key down, you will increment (UP arrow) or decrement º º (DOWN arrow) your way through the available drying temperatures (105 Fahrenheit or 40 Celsius, º º up to 195 Fahrenheit or 91 Celsius).
  • Page 22 2) Press and release the PROG touch pad key on the dryer controller. The dryer controller display will not change. 3) Immediately, press and release the UP arrow key on the dryer controller touch pad. The controller display will change from “LOAd” to “Prog”. You have now entered the permanent programming mode.

  • Page 23: Servicing Dryer

    SERVICING THE DRYER Note: A key with the markings “6324” is provided for service access to controller by a qualified person. This key should be stored in a secure place away from the dryer. A different key is required to open the coin box, if provided. Routine Non-Technical Maintenance and Cleaning: DAILY 1.
  • Page 24 DRIVE BELT, TUMBLER 9040-073-009 LINT SCREEN FILTER 9555-057-002 For service and parts information contact your local Dexter agent. If a Dexter agent is not available, contact Dexter Laundry, Inc. directly as listed below: Mailing Address: 2211 West Grimes Avenue Phone: 1 + 641-472-5131 (USA)
