Summary of Contents for Comprehensive CDA-VP200N
-
Page 1: User Manual
USER MANUAL Models: CDA-VP200N, 1:2 High Resolution XGA DA CDA-VGA31, 1:3 High Resolution XGA DA CDA-VGA41, 1:4 High Resolution XGA DA For maximum results, use Comprehensive Brand Premium High Resolution cables and connectors. -
Page 2: Table Of Contents
Figure 5: Connecting the CDA-VGA41 to 4 Displays Tables Table 1: Features and Functions of the CDA-VP200N 1:2 High Resolution XGA DA Table 2: Features and Functions of the CDA-VGA31 1:3 High Resolution XGA DA Table 3: Features and Functions of the CDA-VGA41 1:4 High Resolution XGA DA... -
Page 3: Introduction
Introduction Congratulations on purchasing your CDA-VP200N 1:2 High Resolution XGA DA and/or CDA-VGA31 1:3 High Resolution XGA DA and/or CDA-VGA41 1:4 High Resolution XGA DA, which are ideal for: Multi monitor applications or presentation systems requiring local monitors and large screen display devices such as a projector... -
Page 4: Your High Resolution Xga Da
This section describes each High Resolution XGA DA, as follows: CDA-VP200N (see section 4.1) CDA-VGA31 (see section 4.2) CDA-VGA41 (see section 4.3) The underside of the High Resolution XGA DA is identical on the CDA-VP200N, CDA-VGA31, and CDA-VGA41 (see section 4.4). -
Page 5: Your Cda-Vp200N 1:2 High Resolution Xga Da
4.1 Your CDA-VP200N 1:2 High Resolution XGA DA Figure 1 and Table 1 define the CDA-VP200N 1:2 High Resolution XGA DA: Figure 1: CDA-VP200N 1:2 High Resolution XGA DA Table 1: Features and Functions of the CDA-VP200N 1:2 High Resolution XGA DA... -
Page 6: Your Cda-Vga31 1:3 High Resolution Xga Da
4.2 Your CDA-VGA31 1:3 High Resolution XGA DA Figure 2 and Table 2 define the CDA-VGA31 1:3 High Resolution XGA DA: Figure 2: CDA-VGA31 1:3 High Resolution XGA DA Table 2: Features and Functions of the CDA-VGA31 1:3 High Resolution XGA DA Feature Function 12V DC... -
Page 7: Your High Resolution Xga Da Underside
Table 3: Features and Functions of the CDA-VGA41 1:4 High Resolution XGA DA Feature Function 12V DC +12V DC connector for powering the unit OUTPUT 1 HD15F Connector Connect to the XGA acceptor 1 OUTPUT 2 HD15F Connector Connect to the XGA acceptor 2 INPUT HD15F Connector Connect to the XGA source OUTPUT 3 HD15F Connector... -
Page 8: Connecting Your High Resolution Xga Da
Connecting Your High Resolution XGA DA You can use the CDA-VP200N, CDA-VGA31, or the CDA-VGA41 to output the XGA signal from a laptop or a PC. To output the XGA signal from a computer graphics source to four displays, using a CDA-VGA41, as the example in Figure 5 illustrates, do the following: 1. -
Page 9: Technical Specifications
- 0.7 Vpp/75 , H & V sync, TTL level, on an HD15F connector OUTPUTS: CDA-VP200N: 2 analog red, green, blue signals - 0.7 Vpp/75 , H & V sync, TTL level, on HD15F connectors CDA-VGA31: 3 analog red, green, blue signals - 0.7 Vpp/75 , H & V sync, TTL level, on HD15F connectors CDA-VGA41: 4 analog red, green, blue signals - 0.7 Vpp/75 , H &...
