Terminal Mode Commands
ADAP Command
2 and 4 Watt SSPA Response
Stored Faults
LNB Command
Stored Faults Response
AGC Command
Stored Faults Response
Common Equipment Command
Stored Faults Response
7.9

Burst Control Mode

Burst Control Mode Command
Response
Status
Response:
.
<add/HSF_#'cr' Where yyy = ON or OFF, xxx = OK or FLT, BV1 = bias voltage
>add/HSF_#'cr' #1, PROG = inter processor communications, # = stored fault
RF_yyy'cr' location (0 to 9)
HPA_xxx'cr'
BV1_xxx'cr'
+9.75V_xxx'cr'
-5V_xxx'cr'
PROG_xxx'cr''lf']
<add/LSF_#'cr' Where xxx = OK or FLT, # = stored fault location (0 to 9)
>add/LSF_#'cr'
LNA_xxx'cr''lf]'
<add/ASF_#'cr' Where xxx = OK or FLT, # = stored fault location (0 to 9), EIP =
>add/ASF_#'cr' excessive input power, IIP = insufficient input power, LOOP =
EIP_xxx'cr' loop converge
IIP_xxx'cr'
LOOP_xxx'cr''lf']
<add/CSF_#'cr' Where xxx = OK or FLT, # = stored fault location (0 to 9), TXS =
>add/CSF_#'cr' transmit redundancy switch, RXS = receive redundancy switch, IF
M&C_xxx'cr' = IF redundancy switch, RFLC = redundancy fault line cable
-7V_xxx'cr'
+7V_xxx'cr'
+12V_xxx'cr'
+17V_xxx'cr'
SFLT_#'cr ''lf']
<add/BCM_xxx'cr' where: xxx = (ON/OFF), default is OFF.
>add/BCM_xxx'cr''lf']
This command enters a special burst signal operation mode, when
<add/BCM_'cr' Uplink AGC is disabled. The detected loss of an IF input carrier
>add/BCM_xxx'cr''lf'] will cause the uplink to turn its RF OFF. When the IF carrier is re-
applied, the RF will be turned ON
7–10
Revision 2
MN/KST2000L.IOM
