Satellite Terminal System
Equipment Mounting
6.3

SSPA Installation

6.3.1

Feed Mount Offset Antenna

The information in this section applies to installation on typical offset antenna of sizes
1.8, 2.4, or 3.8M; with interfaces of 3.74" or 5.25". Refer to Figure 6-1 for an illustration.
6.3.1.1 Optional Feed Mount Offset Antenna Installation Kit for SSPA
Refer to Section 6.2.1.1.
6.3.1.2 SSPA Feed Mount Offset Antenna Installation Instructions
1.
2.
3.
Remove the protective cover from the antenna (OMT) and SSPA (if installed).
After removing the protective cover(s), ensure that no foreign
material or moisture enters the antenna waveguide or SSPA.
CAUTION
Install the appropriate gasket on the SSPA isolator.
a) If only one of the mounting surfaces has a groove, use the thin gasket
b) If both mounting surfaces have grooves, then use the thick gasket.
Position the SSPA on the antenna OMT and fasten using the hardware from
KT/2820 (4 each socket head screws, split washers, (8) flat washers, and nuts).
