  • Page 2 IT350-IT350W User’s Manual Product name: IT350-IT350W PTZ Network Camera Release Date: 2006/10/27 Manual Revision: 1.00 Intellisystem Technologies ©Copyright 2006. All rights reserved Intellisystem Technologies – http://www.intellisystem.it - 1 -...

  • Page 3: Before You Use This Product

    “Installation” chapter to avoid damages due to faulty assembly and installation. This also ensures the product is used properly as intended. The IT350-IT350W Network Camera is a network device and its use should be straightforward for those who have basic network knowledge. The “Troubleshooting”...
  • Page 4 IT350-IT350W User’s Manual Wired or wireless PTZ Network Camera Remote Controller Camera stand Power adapter A/V Cable Software CD Antennas (for IT350W wireless model only) Intellisystem Technologies – http://www.intellisystem.it - 0 -...

  • Page 5: Table Of Contents

    IT350-IT350W User’s Manual Table of Contents Installation ..........3 Hardware Installation .
  • Page 6 IT350-IT350W User’s Manual Camera Control ..........48 Application Setup .

  • Page 7: Installation

    IT350-IT350W User’s Manual Installation Hardware Installation Please verify that your product package contains all the accessories listed in the foregoing Package Contents. Depending on the user’s application, an Ethernet cable may be needed. The Ethernet cable should meet the specs of UTP Category 5 and not exceed 100 meters in length.
  • Page 8 IT350-IT350W User’s Manual To install in wireless LAN If the Ethernet is not available while power on, the Network Camera will search for any access point with the SSID “default”. Once any access point is found, the LED will turn green to wait for installation.

  • Page 9: Software Installation

    IT350-IT350W User’s Manual Software Installation In this manual, "User" refers to whoever has access to the IT350-IT350W Network Camera, and "Administrator" refers to the person who can configure the IT350-IT350W Network Camera and grant user access to the camera. At the end of the hardware installation, the Administrator must place the product software CD into the CD-ROM drive of the PC running in MS Windows.
  • Page 10 Network Cameras with the serial number. For the series number in the “Serial Number” field, please check the label on the bottom of the IT350-IT350W camera. The IP addresses shown in the "Current IP Address" field reflect those on the local network.
  • Page 11 IT350-IT350W User’s Manual The new UPnP function will always assign an IP address for the Network Camera. The Administrator can click on button “Link to selected device” to connect the I.E. to the camera. If the camera is not on the IP installer list, click on the “Search” button to search for the camera on the LAN.
  • Page 12 IT350-IT350W User’s Manual For more detailed usage of the Installation Wizard, please refer to the user’s manual of the Installation Wizard. Intellisystem Technologies – http://www.intellisystem.it - 8 -...

  • Page 13: Initial Access To The Network Camera

    IT350-IT350W User’s Manual Initial Access to the Network Camera Installing Plug-in For the initial access to the Network Camera in Windows, the web browser may prompt for permission to install a new plug-in for the Network Camera after a period of time of downloading.

  • Page 14: Check Network Settings

    IT350-IT350W User’s Manual Check Network Settings The Network Camera can be connected either before or immediately after software installation onto the Local Area Network. The Administrator should complete the network settings on the configuration page, including the correct subnet mask and IP address of gateway and DNS.

  • Page 15: How To Use

    IT350-IT350W User’s Manual How to Use Authentication After opening the web browser and typing in the URL of the Network Camera, a dialogue window pops up to request a username and password. The foreground is the login window and the background shows the message if authentication fails.

  • Page 16: Primary User's Capabilities

    IT350-IT350W User’s Manual Primary User’s Capabilities Main Screen with Camera View The main page layout has three parts: Configuration functions: The camera can be configured using these user interfaces. Camera View: What the camera sees. Pan/Tilt/Zoom control buttons: These buttons provide a command interface to control the aim of the camera.
  • Page 17 “Configuration” Only the Administrator can access camera configurations. The camera view The information bar down of the IT350-IT350W camera view shows the assigned caption and the current date/time. The information bar at the bottom of the IT350-IT350W camera view shows the current streaming mode and audio transmission mode.
  • Page 18 IT350-IT350W User’s Manual The pan/tilt/zoom control buttons: The direction buttons are for Left, Right, Up, Down, and Home functions. The Home button centers the camera. “Go to” Once the Administrator has determined the preset positions; the User can aim the camera using this control.

  • Page 19: Client Settings

    IT350-IT350W User’s Manual Client Settings There are four settings for the client side. Media Options - For the User to determine whether to receive video, audio or both. Protocol Options – Which allows choosing on connection protocol between client and server.
  • Page 20 IT350-IT350W User’s Manual Streaming Options – For users to select the video streaming types. Select “Streaming Video” options, the video connection will keep alive to enable you to see smooth video, while “Single JPEG” options will let you see the video in JPEG format by client periodic update the JPEG image from server according to the “Frame rate”...

  • Page 21: Administrator's Capabilities

    IT350-IT350W User’s Manual Administrator’s Capabilities Fine-tuning for Best Performance There are a few choices the Administrator is allowed to maximize the capabilities of the Network Camera. Best performance generally equates to the fastest image refresh rate with the best video quality, and at the lowest network bandwidth as possible. The six factors, “Size”, “Maximum frame rate”, “Video codec type”, “Key frame interval”, “Fix bit...
  • Page 22 IT350-IT350W User’s Manual For Best Real-time Video Images To achieve good real-time visual effect, the network bandwidth should be large enough to allow a transmission rate of greater than 20 image frames per second. If the broadband network is over 1 Mbps, set the “Fix bit rate” to 1000Kbps or 1200Kbps, or set “Fix quality”...
  • Page 23 IT350-IT350W User’s Manual Select for Motion JPEG The Network Camera with Pan/Tilt/Zoom is a camera with dual video codec, they’re MPEG4 and MJPEG. If MJPEG is selected, the camera will transmit video data in JPEG format. Therefore, it requires higher bandwidth to view smooth video. General speaking, each normal sized JPEG image would be 3k~12k bytes, depending on the selected video quality and contents.

  • Page 24: Opening Accounts For New Users

    IP address is known. It is necessary to assign a password if the IT350-IT350W Network Camera is intended to be accessed by others. Type a new word twice in the first field to enable protection. This password is used to identify the administrator.

  • Page 25: Build A Multimedia Web Attraction Site

    The IT350-IT350W Network Camera can allow ten visitors on-line simultaneously. After Installation, focus the IT350-IT350W Network Camera on any object you wish to share, and tell the visitors to type in the web browser address. Caution: You may want to maintain your visitor’s list in the security configuration page to block out unexpected...
  • Page 26 If the web space has FTP service Set the Network Camera up as an FTP client to upload the pictures. The access to the IT350-IT350W Network Camera will be independent of the number of viewers and the picture quality will remain constant.
  • Page 27 If the web space has no FTP service An auto-refresh homepage can be used to periodically poll the newest image from the IT350-IT350W Network Camera. It is most efficient if using a free web space provider as the FTP service may be limiting.
  • Page 28 IT350-IT350W User’s Manual Example of an auto-refresh web page: <html> <head> <title>IT350/IT350W Intellisystem Technologies - Example - auto refresh</title> </head> <body> <p align=left> <font size="7" face="Comic Sans MS" color="#FF0000"> MiniAVServer Demo </font> </p> <p align=left> <!-- Begin of scripts to auto refresh the image. Change the IP address in the image URL and refreshrate if necessary.

  • Page 29: Build A Security Application

    IT350-IT350W User’s Manual Build a Security Application The Administrator can combine options on the application page to perform many useful security applications. There are two trigger sources coming from attached devices, such as for motion detection. There are also two kinds of actions responding to such events, including uploading snapshots over the Internet and driving other attached devices.
  • Page 30 IT350-IT350W User’s Manual 8. Click on “New” to have a new window to monitor video, 9. Type in a name to identify the new window, 10. Use the mouse to click, hold, and drag the window corner to resize or the title bar to move, 11.

  • Page 31: Definitions In Configuration

    If the Administrator also wants to set certain options through the URL, read the reference appendix for details. <url>http://<IT350/IT350WNetworkCamera>/setup/config.html <IT350/IT350WNetworkCamera>is the domain name or original IP address of the IT350-IT350W Network Camera. <url>http://<IT350/IT350WNetworkCamera>/setup/system.vspx <IT350/IT350WNetworkCamera>is the domain name or original IP address of the IT350-IT350W Network Camera.

  • Page 32: System Parameters

    Notice the format in the related fields while doing the entry. “Automatic” Synchronize with the NTP server over the Internet whenever the IT350-IT350W Network Camera starts up. It will fail if the assigned time-server cannot be reached. “NTP server” Assign the IP address or domain name of the time-server. Leaving the text box blank connects the IT350-IT350W Network Camera to the default time-servers.

  • Page 33: User Group Administration

    IT350-IT350W User’s Manual User Group Administration “Root password” Change the Administrator’s password by typing in the new password identically in both text boxes. The typed entries will be displayed as asterisks for security purposes. After pressed , the web browser will ask the Administrator for the new password for access.

  • Page 34: Edit User

    “Edit user” Pull down the user list to find the user’s name and press to edit the user’s password and privilege. <url>http://<IT350/IT350WNetworkCamera>/setup/security.vspx <IT350/IT350WNetworkCamera>is the domain name or original IP address of the IT350-IT350W Network Camera. Edit User Type the new password, change the privilege and press to modify the account.

  • Page 35: Network Settings

    Users can run IP installer to check the IP address assigned to the IT350-IT350W Network Camera if the IP address is forgotten or using the UPnP function provided by the Network Camera (MS Windows XP provides UPnP function at My Network Place).
  • Page 36 “UDP Video channel port” This can be something other than the default port 5003 in order to work with the port opened by the firewall. <url>http://<IT350/IT350WNetworkCamera>/setup/network.vspx <IT350/IT350WNetworkCamera>is the domain name or original IP address of the IT350-IT350W Network Camera. Intellisystem Technologies – http://www.intellisystem.it...

  • Page 37: Wireless

    IT350-IT350W User’s Manual Wireless (for IT350W model only) “SSID” (Service Set Identifier), it is a name that identifies a wireless network. Access Points and wireless clients attempting to connect to a specific WLAN (Wireless Local Area Network) must use the same SSID. The default setting is default. Note: The maximum length of SSID is 32 single-byte characters and SSID can’t be any of “, <, >...
  • Page 38 Note: When 22(“), 3C(<) or 3E(>) are input in network key, the key format can’t be changed to ASCII format. <url>http://<IT350/IT350WNetworkCamera>/setup/wireless.vspx <IT350/IT350WNetworkCamera> is the domain name or original IP address of the IT350W Network Camera. Intellisystem Technologies – http://www.intellisystem.it - 34 -...

  • Page 39: Ddns & Upnp

    MS Windows XP. If the UPnP network component is installed in Windows XP, the hostname of the IT350-IT350W Network Camera will be shown with bracketed IP address in the Network neighbors. Ex: Network Camera with Pan/Tilt (xxx.xxx.xxx.96).
  • Page 40 IP address assigned to the Network Camera. “Save” Click on this button to save current settings for the DDNS service and UPnP function. <url>http://<IT350/IT350WNetworkCamera>/setup/ddnsupnp.vspx <IT350/IT350WNetworkCamera>is the domain name or original IP address of the IT350-IT350W Network Camera. Intellisystem Technologies – http://www.intellisystem.it - 36 -...

  • Page 41: Mail & Ftp

    Refer to the instructions for the external FTP server for details. The folder privilege must be open for upload. “1st FTP passive mode” The IT350-IT350W Network Camera is located inside the network protected by a firewall, data connection for FTP may be prohibited. By selecting passive mode, the FTP can bypass the rule and allow snapshot upload to Intellisystem Technologies –...
  • Page 42 IT350-IT350W User’s Manual proceed. If the passive mode is selected, the IT350-IT350W Network Camera can automatically attempt for active mode, if the external FTP server does not support passive mode. “2nd FTP server” The domain name or IP address of the backup FTP server.

  • Page 43: Video Codec Parameters

    IT350-IT350W User’s Manual Video Codec Parameters “Text on video” The text will be displayed in the black bar above the video window with a timestamp. The timestamp is captured from date and time of the Network Camera that is maintained by a built-in real-time clock.
  • Page 44 But it will cause each connection slow a few minutes when connection established. <url>http://<IT350/IT350WNetworkCamera>/setup/video.vspx <IT350/IT350WNetworkCamera>is the domain name or original IP address of the IT350-IT350W Network Camera. Intellisystem Technologies – http://www.intellisystem.it - 40 -...

  • Page 45: Image Settings

    IT350-IT350W User’s Manual Image Settings Click on “Image Settings” to pop up another window for tuning "Brightness", “Contrast”, “Hue” "Saturation" video compensation. Each field has eleven levels ranged from -5 to +5. The User may press “Preview” to fine-tune the image.
  • Page 46 IT350-IT350W User’s Manual “Auto tracking white balance” usually applied when the Network Camera is aiming outdoor. Adjusting the 9 levels of white levels can help the camera capturing video with correct colors. On the other hand, select “White balance control”...
  • Page 47 IT350-IT350W User’s Manual The picture illustrates the corresponding areas of the selecting window in the real video. “Select All” will check all the areas in the windows and “Clear All” will do vice versa. “Save” button can set the selected areas for BLC.

  • Page 48: Audio

    “Improve audio quality in low bandwidth environment” If the IT350-IT350W Network Camera works in versatile or low network bandwidth environment, the User can check this option to improving audio quality by sacrificing some real-time synchronization.
  • Page 49 IT350-IT350W User’s Manual <url>http://<IT350/IT350WNetworkCamera>/setup/audio.vspx <IT350/IT350WNetworkCamera>is the domain name or original IP address of the IT350-IT350W Network Camera. Intellisystem Technologies – http://www.intellisystem.it - 45 -...

  • Page 50: Motion Detection

    IT350-IT350W User’s Manual Motion Detection “Enable motion detection” Check this option to turn on motion detection. Click on this button to add a new window. At most three windows can exist simultaneously. Use the mouse to click, hold and drag the window frame to resize or the title bar to move.
  • Page 51 “Percentage” This sets the space ratio of moving objects in the monitoring window. Higher sensitivity and small percentage will allow easier motion detection. <url>http://<IT350/IT350WNetworkCamera>/setup/motion.vspx <IT350/IT350WNetworkCamera>is the domain name or original IP address of the IT350-IT350W Network Camera. Intellisystem Technologies – http://www.intellisystem.it...

  • Page 52: Camera Control

    “Set as home” Click on the button will command the IT350-IT350W Network Camera to set the current aiming position as Home position. That is: when user click on the Intellisystem Technologies –...
  • Page 53 1. The stop time of each preset location during auto patrol of the IT350-IT350W Network Camera. 2. The stay time at the most left and the most right positions when the IT350-IT350W Network Camera is doing auto panning. “Enable IR control” Checking this box allows the Administrator to enable the IR controller to move the aim of the camera.
  • Page 54 IT350-IT350W User’s Manual <url>http://<IT350/IT350WNetworkCamera>/setup/camctrl.vspx <IT350/IT350WNetworkCamera>is the domain name or original IP address of the IT350-IT350W Network Camera. Intellisystem Technologies – http://www.intellisystem.it - 50 -...

  • Page 55: Application Setup

    IT350-IT350W User’s Manual Application Setup Weekly Schedule “Sun” ~ “Sat” Select the days of the week to perform the following operations. “Snapshots begin at” Set the time to start operations. “Snapshots stop at” Set the time to stop operations. Setting identical begin time and stop time means 24-hour operation.

  • Page 56: Sequential Operation

    “Reset output” Select and save this option to reset the external device at the digital output to return to the original state. Sequential Operation “Snapshot interval” The IT350-IT350W Network Camera will send snapshots at the specified intervals to the external server. “Send snapshots by email” This selects the uploading method following the intervals set above.
  • Page 57 IT350-IT350W User’s Manual <url>http://<IT350/IT350WNetworkCamera>/setup/app.vspx <IT350/IT350WNetworkCamera>is the domain name or original IP address of the IT350-IT350W Network Camera. Intellisystem Technologies – http://www.intellisystem.it - 53 -...

  • Page 58: Viewing System Log

    IT350-IT350W User’s Manual Viewing System Log Click on the link on the configuration page to view the system log file. The content of the file provides useful information about configuration and connections after system boot-up. Viewing System Parameters Click on this link on the configuration page to view the entire system’s parameter set.

  • Page 59: Remote Controller

    IT350-IT350W User’s Manual Remote Controller IT350-IT350W Network Camera provides a remote controller to command the camera’s pan/tilt and other functions. The direction control part provides the function as on the main web page. The Pan/Patrol/Stop functions are also the same as on the main web page.

  • Page 60: Appendix

    Any hardware failure Other patterns Reset and Restore At the left side of the IT350-IT350W Network Camera there is a button hidden in the pinhole as shown in the picture. It is used to reset the system or restore the factory default settings.
  • Page 61 Refer to Appendix A for the procedures. Q Why can I not watch video from the IT350-IT350W Network Camera after it is authenticated? A There are many possible scenarios regarding this problem, 1.
  • Page 62 Q The image is not clear enough. A Rotate the lens to adjust the focus after the IT350-IT350W Network Camera has been installed in the proper position. The image settings and white balance can be fine tuned to achieve the best visual effect.
  • Page 63 You can check the system log to examine any abnormal activities and trace the origins. Q Why can I not access the IT350-IT350W Network Camera when I setup some options in the application? A Since the IT350-IT350W Network Camera is a "network camera", any incorrect...

  • Page 64: Cleaning The Lens

    IT350-IT350W User’s Manual B. Cleaning the Lens The Network Camera with Pan/Tilt/Zoom is a network camera with high quality lens. When it is necessary to clean the lens, please follow these instructions: Prepare cotton swabs and alcohol. Moisten the cotton swab with alcohol.

  • Page 65: Pan/Tilt/Zoom Data

    IT350-IT350W User’s Manual C. Pan/Tilt/Zoom Data unit tilt angle: 0.918 degree The tile speeds of different auto pan/tile speeds. auto tile speed 1: 1.65 degree/sec auto tile speed 2: 6.59 degree/sec auto tile speed 3: 8.24 degree/sec auto tile speed 4: 10.98 degree/sec auto tile speed 5: 16.47 degree/sec...

  • Page 66: Url Commands Of The Network Camera

    URL syntax' are written with the “Syntax:" word written in bold face followed by a box with the referred syntax as seen below. The name of the server is written as <IT350/IT350WNetworkCamera>. This is intended to be replaced with the name of the actual server. This can either be a name, e.g., "mywebcam" or "thecam.adomain.net"...

  • Page 67: General Cgi Url Syntax And Parameters

    IT350-IT350W User’s Manual Description of returned data is written with "Return:" in bold face followed by the returned data in a box. All data returned as HTTP formatted, i.e., starting with the string HTTP is line separated with a Carriage Return and Line Feed (CRLF) printed as \r\n.

  • Page 68: Set Server Parameter Values

    IT350-IT350W User’s Manual where the <parameter> should be <group>[_<name>] or <group>[.<name>] If you do not specify the any parameters, all the parameters on the server will be returned. If you specify only <group>, the parameters of related group will be returned.

  • Page 69: Available Parameters On The Server

    IT350-IT350W User’s Manual (note: this parameter must be put at begin of parameter list) <group>_<name>. value Assign <value> to the parameter <group>_<name>.. assigned return <return Redirect to the page <return page> after the parameter page> is assigned. The <return page> can be a full URL path or relative path according the the current path.
  • Page 70 IT350-IT350W User’s Manual updateinterval 0 ~ 2147483 0 to Disable automatic time adjustment, (r/w) otherwise, means seconds between NTP automatic update interval. serialnumber <mac address> 12 characters mac address without hyphen connected firmwareversion <text string shorter version firmware, including than 39 characters>...
  • Page 71 IT350-IT350W User’s Manual ipaddress <IP address> IP address of server (r/w) (restart) subnet <IP address> subnet mask (r/w) (restart) router <IP address> default gateway (r/w) (restart) dns1 <IP address> primary DNS server (r/w) dns2 <IP address> secondary DNS server (r/w) smtp1 <domain name or IP...
  • Page 72 IT350-IT350W User’s Manual ftppass2 <password password for secondary FTP server, max 15 (r/w) ftpuser2> characters ftpfolder2 <target folder on 2 upload folder in secondary FTP server, max (r/w) server> 40 characters ftppassmode2 Enable passive mode of primary FTP server (r/w)
  • Page 73 IT350-IT350W User’s Manual ASCII Key1 ~ Key4 will be represented in ASCII format keyselect 1 ~ 4 Default key number (r/w) <1> key1 <text string shorter than WEP key1 for encryption (r/w) characters> <0000000000> (depends on keyformat & keylength) key2 <text string shorter than...
  • Page 74 IT350-IT350W User’s Manual (r/w) lower quality of video normal quality of video higher quality of video highest quality of video bitrate 64000 set bit rate to 64K bps (r/w) 128000 set bit rate to 128K bps 256000 set bit rate to 256K bps...
  • Page 75 IT350-IT350W User’s Manual lowbandwidth Disable low bandwidth environment support (r/w) Improve in low bandwidth environment enableaec Disable (r/w) Group: Image NAME VALUE DESCRIPTION brightness <-5 ~ 5> Adjust brightness of image according to (r/w) mode settings. saturation <-5 ~ 5>...
  • Page 76 IT350-IT350W User’s Manual (r/w) provider 1 ~ 4 dyndns.org (dynamic) (r/w) dyndns.org (custom) tzo.com dhs.org hostname Text string shorter than Your dynamic hostname. (r/w) 63 characters. usernameemail Text string shorter than Your user or email to login ddns service (r/w) 63 characters.
  • Page 77 IT350-IT350W User’s Manual NAME VALUE DESCRIPTION mode save Only specified “mode=save” can (r/w) make the parameters changed to desired values. autoiris 0 or 1 set 1 to enable auto iris, set 0 to (r/w) disable auto iris irislevel Set iris size, set bigger value to set...

  • Page 78: Drive The Digital Output

    IT350-IT350W User’s Manual Drive the Digital Output Note: This request requires the privilege of I/O access control. Method: GET/POST Syntax: http://<IT350/IT350WNetworkCamera>/cgi-bin/setdo.cgi?do1=<state>[&do2=<state>] [&do3=<state>][&do4=<state>][&return=<return page>] Where state is H, L. H means NC (normal close) connected with COMMON and L means NO (normal open) connected with COMMON. The number of DO dependents on the server type.

  • Page 79: Capture Single Snapshot

    IT350-IT350W User’s Manual Return: HTTP/1.0 200 OK\r\n Content-Type: image/jpeg\r\n Content-Length: <length>\r\n \r\n [di1=<state>]\r\n [di2=<state>]\r\n [di3=<state>]\r\n [di4=<state>]\r\n where <state> can be H or L. Example: Query the status of digital input 1 Request: http:// <IT350/IT350WNetworkCamera>/cgi-bin/getdi.cgi?di1 Response: HTTP/1.0 200 OK\r\n Content-Type: image/jpeg\r\n...

  • Page 80: Account Management

    IT350-IT350W User’s Manual Account Management Note: This request requires administrator privilege Method: GET/POST Syntax: http://<servername>/cgi-bin/admin/editaccount.cgi? method=<value>&user=<name>[&pass=<value>][&privilege=<value>] [&privilege=<value>][…][&return=<return page>] parameter value description method Add an account to server. When using this method, “username” field is necessary. It will use default value of other fields if not specified.

  • Page 81: System Logs

    IT350-IT350W User’s Manual redirect to an empty page. System Logs Note: This request require administrator privilege Method: GET/POST Syntax: http://<servername>/cgi-bin/admin/syslog.cgi Server will return the up-to-date system log. Return: HTTP/1.0 200 OK\r\n Content-Type: text/plain\r\n Content-Length: <syslog length>\r\n \r\n <system log information>\r\n...

  • Page 82: Upload File (Firmware)

    IT350-IT350W User’s Manual Upload File (firmware) Note: This request requires administrator privilege Method: POST Syntax: http://<servername>/cgi-bin/admin/upload.cgi Post data: file=<file name>[&return=<return page>]\r\n \r\n <multipart encoded form data> Server will accept the upload file named <file name> to be stored on the flash as “flash.bin”...

  • Page 83: Recall

    IT350-IT350W User’s Manual speedzoom -5 ~ 5 Set the zoom speed speedapp -5 ~ 5 Set the auto pan/patrol speed auto Auto pan patrol Auto patrol stop Stop camera zoom wide To zoom for larger view with current speed tele...

  • Page 84: System Information

    IT350-IT350W User’s Manual URL path or relative path according to the current path. If you omit this parameter, it will redirect to an empty page. System Information Note: This request requires normal user privilege Method: GET/POST Syntax: http://<IT350/IT350WNetworkCamera>/cgi-bin/sysinfo.cgi Server will return the system information.
  • Page 85 IT350-IT350W User’s Manual Syntax: http://<IT350/IT350WNetworkCamera>/cgi-bin/admin/preset.cgi? [addpos=<value>][&delpos=<value>][&return=<return page>] parameter value description addpos <Text string less Add one preset location to preset list. than characters> delpos <Text string less Delete preset location from preset list. than characters> return <return page> Redirect to the page <return page> after the parameter is assigned.

  • Page 86: Technical Specifications

    IT350-IT350W User’s Manual E. Technical Specifications - System 10X optical zoom CPU: Trimedia PNX1300 10X digital zoom RAM: 16MB SDRAM ROM: 4MB FLASH ROM - Audio 32Kbps, 24Kbps, 8Kbps - Networking Acoustic echo cancellation Protocol Full duplex audio communication TCP/IP, HTTP, SMTP, FTP, Telnet, NTP, DNS...
  • Page 87 Intellisystem Technologies S.r.l. makes no warranty of any kind with regard to the material contained within this document, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
