COLOR VIDEO CAMERA
KY-F58
CAUTION
This section of instruction manual is specially edited for serv-
ice manual with modified contents.
It is not recommended to use this section for the substitution
of the original instructions included in the merchandise.
INSTRUCTIONS
For Customer Use:
Enter below the Serial No. which
are located on the bodys.
Retain this information for future
reference.
Model No. KY-F58
Serial No.
Advertisement
Table of Contents
Related Manuals for JVC KY-F58
Summary of Contents for JVC KY-F58
- Page 1 It is not recommended to use this section for the substitution of the original instructions included in the merchandise. INSTRUCTIONS For Customer Use: Enter below the Serial No. which are located on the bodys. Retain this information for future reference. Model No. KY-F58 Serial No.
- Page 2 Information for USA This device complies with Part 15 of the FCC Rules. Changes or modifications not approved by JVC could void the user's authority to operate the equipment. INFORMATION (FOR CANNADA) RENSEIGNEMENT (POUR CANADA) •...
-
Page 3: Table Of Contents
Thank you for purchasing the JVC KY-F58 Color Video Camera. CONTENTS FEATURES ... 3 BASIC CONFIGURATION ... 3 1. INTRODUCTION PRECAUTIONS ON PROPER USE ... 4 2. CONTROLS, INDICATIONS AND CONNECTORS CAMERA CONTROL UNIT [Panel side] ... 5 CAMERA CONTROL UNIT [Rear side] ... 7 CAMERA HEAD ... -
Page 4: Introduction
• When recording an important event, be sure to try the camera first before using it in order to check that the cam- era operates properly. • JVC does not guarantee the contents of a recording if the color video camera, VCR or video cassette malfunctions during recording. -
Page 5: Controls, Indications And Connectors
MENU screen. When again pressing this button, the normal screen is re- sumed. LOCK MENU ITEM+ DATA+ BARS ITEM- DATA- CAMERA CONTROL UNIT KY-F58 FILES MENU SELECT MEMORY WHITE PAINT VIDEO LEVEL FULL AUTO PAINT [SET] set button. - Page 6 2. CONTROLS, INDICATIONS AND CONNECTORS (Cont’d) Camera Control [Panel side] (Cont’d) Set up switch This switch changes the FILE setting and the RANDOM TRGGER setting. Change the setting according to the de- sired use. SW1, 2 FILE setting Refer to "FILE SETTING" on page 15. SW3 RANDOM TRIGGER setting Refer to "Random Trigger Function"...
-
Page 7: Camera Control Unit [Rear Side]
This is the RGB/Component signal output connector. To switch between the RGB and the COMPONENT on the MENU screen. Refer to the “TOTAL SETTING SCREEN” on page 25. View from the rear of the KY-F58 (9-pin connector, female) Pin No. Signal Pin No. -
Page 8: Camera Head
2. PARTS NAMES AND FUNCTIONS (Cont’d) CAMERA CONTROL [Rear side] (Cont’d) [FLASH] Flash signal output connector (BNC) When the FREEZE item is set to the FLASH, a flash signal is output from this connector according to FREEZE input. It is recommended to be used when the unit is operated with a flash. -
Page 9: Connections
Screws Mount fastening ring Lens Note: The KY-F58 is not equipped with a lens. When a lens other than the T14x5.5MD of the 3-CCD C-mount lens is used, it may cause the KY-F58 to malfunction. When such a lens is used, the lens' height should not be more than 4 mm above the lens mount surface. -
Page 10: How To Mount The Camera Head
The maximum cable length is up to 25 m. Note: When the cable is extended to 25 m, JVC guarantees only the operation and not the performance. ● When connecting cables, match the arrow marks on each cables. Also, make sure to connect a male connector and a female connector. -
Page 11: System Application
• Connect a flash light to the FLASH connector. • Set the FREEZE MENU to “FLASH”. To output an image from the KY-F58 under the tim- ing of the image processing unit • Connect an external sync signal of the image processing unit to the VD and HD/VBS connector of this unit. -
Page 12: Basic Adjustments Before Use (Be Sure)
Yellow Cyan Green Magenta 12 Revised in August 1998 Perform the adjustments for color, contrast and luminance by OUTPUT displaying the color bar signal built into the KY-F58 on the moni- HD/VBS VIDEO tor. FREEZE MONITOR RGB/COMPONENT Connect a color video monitor to the VIDEO OUPUT termi- nal of the KY-F58. -
Page 13: White Balance Adjustment
The color of light (color temperature) is different according to the color source. When the main light source lighting an object is changed, readjust the white balance as well. 4.5.6. 3.7. 5.6. LIGHT CAMERA CONTROL UNIT KY-F58 FILES LOCK MENU ITEM+ DATA+... -
Page 14: White Shading Adjustment
Green or magenta color appears on the top or bottom of the screen, this is because the white balance is adjusted at the center of the screen but not at the top or bottom of the screen. This is caused by the characteristics of a lens and to compensate it is called white shading compensation. 2. 3.4. CAMERA CONTROL UNIT KY-F58 FILES LOCK MENU... -
Page 15: Operation
It takes 1 second to switch over the FILE. LED blinks rapidly during the FILE switching operation. Note: Do not perform other operations during the LED blinking, it may cause the KY-F58 to malfunction. The FILE setting is completed when the LED stops blinking, and lights. Changing setting values The setting value is changed for each file. - Page 16 5. OPERATION (Cont’d) FILE SETTING (Cont’d) Initial Values of Scene File A Item LENS TYPE IRIS CONTOROL SHUTTER LEVEL GAIN LEVEL ALC MAX IRIS DETECT DETECT AREA COLOR TEMP WHITE BAL SHADING MODE LEVEL < R > LEVEL < G > LEVEL <...
-
Page 17: Manual Operation
MANUAL OPERATION WHITE PAINT CAMERA CONTROL UNIT KY-F58 FILES LOCK MENU ITEM+ DATA+ BARS ITEM- DATA- RESET SELECT MEMORY TO CAMERA WHITE PAINT VIDEO LEVEL FULL AUTO PAINT PAINT (R) PAINT (B) The red and blue colors of the video signal from each output can be adjusted with the two adjust knobs PAINT(R) and PAINT (B). -
Page 18: Setting On The Menu Screen
This sets fine settings for output signals such as contour com- pensation, KNEE POINT, etc. TOTAL SETTING For setting the connection to units other than KY-F58 such as D-SUB terminal, lens control terminal, external sync, etc. Note: The data set at the TOTAL SETTING is common to all files. -
Page 19: Video Level Screen
VIDEO LEVEL SCREEN Item LENS TYPE Switch over between AUTO and MANUAL according to the lens to be used. AUTO : Set it when an automatic iris lens is used. MANUAL : Set it when a manual iris lens is used or no lens is used. IRIS Switch over between AUTO and MANUAL for iris setting when a automatic iris lens is used. -
Page 20: White Balance Screen
6. SETTING ON THE MENU SCREEN (Cont’d) VIDEO LEVEL SCREEN (Cont’d) Item DETECT It sets the detection area with the AUTO IRIS mode. Change this according to the AREA condition of use. D e t e c t i n g a r e a NORMAL D e t e c t i n g... -
Page 21: Freeze Screen
FREEZE SCREEN Item KY-F58 stores the video signal into its memory and outputs the FREEZE signal FREEZE (freeze picture) from each OUTPUT connector on the rear panel. It sets the timing of freeze or whether it is operated together with a flash light or not. - Page 22 OFF : Field is stored. (1/60 sec, [U Ver.] or 1/50 sec. [E Ver.]) ON : Frame is stored. (1/30 sec, [U Ver.] or 1/25 sec. [E Ver.]) CAPTURE It sets the storage mode to the KY-F58. The image in the odd number fields are output to the both fields. EVEN The image in the even number fields are output to the both fields.
-
Page 23: Process Screen
PROCESS SCREEN Item DETAIL It adjusts the emphasis level of the contour (DETAIL). To make the contour (DETAIL) sharp : Increase numbers. To make contour (DETAIL) soft This adjusts the pedestal level(master black) which is the standard black level MASTER when a lens cap is put on. - Page 24 6. SETTING ON THE MENU SCREEN (Cont’d) PROCESS SCREEN (Cont’d) Item GAMMA It sets the compensation of the GAMMA curve which decides the reappearance of black. ON : The compensation of the GAMMA curve is carried out. (Normal monitor is used.) OFF : The compensation of the GAMMA curve is not carried out.
-
Page 25: Total Setting Screen
SC COARSE This carries the SC COARSE adjustment when the phase for the VBS signal input from the HD.VBS connector on the rear panel of the KY-F58 is synchronized. Carry it out together with the SC FINE adjustment. SC FINE By carrying out together with the SC COARSE adjustment, it finely adjusts the sub carrier. -
Page 26: Others
7. OTHERS TECHNICAL INFORMATION Normal (Field) Mode During normal recording, the CCD’s storage time is approx. 1/60 sec. [U Ver.] or 1/50 sec. [E Ver.] in the field mode. With the odd number fields, the total electric charge of the odd number lines and even number lines of the CCD are output to the odd number line (reading two lines at a time), with the even number field, they are output to the even number line. - Page 27 TECHNICAL INFORMATION (Cont’d) Operations Principles of the Electronic Shutter (with the 1/500 sec. setting) Electric charge is stored in the CCD image sensing device only for a 1/500 sec. before the signal is read from the CCD image sensing device. At this time the electric charge stored previ- ously is discharged to another electrode.
- Page 28 1, 2, 4: Do not switch over Note: Before switching the set up switch turn the power switch to off. The mode will not change when the power is switched ON. CAMERA CONTROL UNIT KY-F58 FILES LOCK MENU ITEM+ DATA+...
-
Page 29: Specifications
