DIGITAL VIDEO CAMERA
GR-
DVL210
Please visit our Homepage on the World Wide
Web and answer our Consumer Survey
(in English only):
http://www.jvc-victor.co.jp/english/index-e.html
INSTRUCTIONS
For Customer Use:
Enter below the Model No. and Serial No. which is located on the
bottom of cabinet. Retain this information for future reference.
Model No.
Serial No.
CONTENTS
AUTOMATIC
DEMONSTRATION
GETTING STARTED
BASIC RECORDING &
PLAYBACK
BASIC RECORDING ............ 14 – 17
BASIC PLAYBACK .............. 18 – 21
ADVANCED
FEATURES
FOR RECORDING ................ 23 – 30
USING THE MENU FOR
DETAILED ADJUSTMENT ...... 31 – 36
DUBBING ......................... 37 – 38
USING THE REMOTE
CONTROL UNIT ................ 39 – 47
SYSTEM CONNECTIONS ........ 48 – 49
REFERENCES
DETAILS ................................... 51
TROUBLESHOOTING ............ 52 – 56
USER MAINTENANCE ................... 57
INDEX ............................. 58 – 62
CAUTIONS ........................ 63 – 65
TERMS .................................... 66
SPECIFICATIONS ......................... 67
LYT0724-001A
ENGLISH
5
6 – 12
13 – 21
22 – 49
50 – 69
EN
Advertisement
Chapters
Table of Contents
Troubleshooting
Related Manuals for JVC GR-DVL210
Summary of Contents for JVC GR-DVL210
-
Page 1: Digital Video Camera
DVL210 Please visit our Homepage on the World Wide Web and answer our Consumer Survey (in English only): http://www.jvc-victor.co.jp/english/index-e.html INSTRUCTIONS For Customer Use: Enter below the Model No. and Serial No. which is located on the bottom of cabinet. Retain this information for future reference. -
Page 2: Safety Precautions
However, live recording and LCD monitor/viewfinder playback are possible anywhere. Use the JVC BN-V408U/V416U/V428U battery packs and, to recharge them or to supply power to the camcorder from an AC outlet, use the provided multi-voltage AC Adapter. (An appropriate conversion adapter may be necessary to accommodate different designs of AC outlets in different countries.) -
Page 3: Important Safety Instructions
CAUTION! Connecting cables (Audio/Video, S-Video, etc.) to the camcorder and leaving the unit on top of the TV is not recommended, as tripping on the cables will cause the camcorder to fall, resulting in damage. (10) Use only with the cart,... -
Page 4: Provided Accessories
•AAA (R03) Battery x 2 (for remote control unit) •Audio/Video Cable (ø3.5 mini-plug to RCA plug) NOTE: In order to maintain optimum performance of the camcorder, provided cables may be equipped with one or more core filter. PROVIDED ACCESSORIES •Remote Control Unit RM-V715U •Lens Cap (... -
Page 5: Demonstration
LCD monitor or viewfinder. How To Attach The Lens Cap To protect the lens, attach the provided lens cap to the camcorder as shown in the illustration. NOTE: To confirm the lens cap is on correctly make sure the cap is flush to the camera. -
Page 6: Table Of Contents
GETTING STARTED GETTING STARTED CONTENTS Power ... 7 – 8 Grip Adjustment ... 9 Viewfinder Adjustment ... 9 Shoulder Strap Attachment ... 9 Tripod Mounting ... 9 Date/Time Settings ... 10 Loading/Unloading A Cassette ... 11 Recording Mode Setting ... 12... -
Page 7: Power
2 hrs. BN-V428U (optional) approx. 3 hrs. 20 min. Power This camcorder’s 2-way power supply system lets you choose the most appropriate source of power. Do not use provided power supply units with other equipment. CHARGING THE BATTERY PACK... -
Page 8: Power
AA-V15U AC Power Adapter/Charger for BN-V840U battery pack and only AA-V80U AC Power Adapter/Charger for BN-V856U battery pack. Also, by using the optional JVC VC-VBN856U DC Cord, it will be possible to connect the BN-V840U or BN-V856U battery packs to the camcorder and supply power directly to the camcorder. -
Page 9: Grip Adjustment
Confirm the strap is not twisted. Tripod Mounting CAUTION: When attaching the camera to a tripod, extend its legs to stabilize the camcorder. It is not advised to use small sized tripods. This may cause damage to the unit by falling over. -
Page 10: Date/Time Settings
35, 36). Set the Power Switch to “ the Lock Button located on the switch. The power lamp lights and the camcorder is turned on. Press the MENU/BRIGHT wheel in to access the Menu Screen. Rotate the MENU/BRIGHT wheel to select “... -
Page 11: Loading/Unloading A Cassette
If the tape does not load properly, open the cassette holder cover fully and remove the cassette. A few minutes later, insert it again. When the camcorder is suddenly moved from a cold place to a warm environment, wait a short time before opening the cassette holder cover. -
Page 12: Recording Mode Setting
It is recommended that tapes recorded in the LP mode on this camcorder be played back on this camcorder. During playback of a tape recorded on another camcorder, blocks of noise may appear or there may be momentary pauses in the sound. (cont.) -
Page 13: Playback
BASIC RECORDING & PLAYBACK BASIC RECORDING & PLAYBACK CONTENTS BASIC RECORDING ... 14 – 17 Basic Recording ... 14 Journalistic Shooting ... 15 Self-Recording ... 15 Operation Mode ... 15 Zooming ... 16 Time Code ... 17 BASIC PLAYBACK ... 18 – 21 Normal Playback ... -
Page 14: Basic Recording
(Approximate) Shooting while using the viewfinder: Close the LCD monitor. 3 min •The power lamp lights and the camcorder enters the Record-Standby mode. “PAUSE” is displayed. 2 min Press the Recording Start/Stop Button. “ (Blinking) appears while recording is in progress. -
Page 15: Journalistic Shooting
Self-Recording To turn on the camcorder, set the Power Switch to any operation mode except “OFF” while pressing down the Lock Button located on the switch. Power Switch Power lamp When the Power Switch is set to “ ”, “... -
Page 16: Zooming
Zoom in (T: Telephoto) 1 x W 10 x W 20 x W Zoom out (W: Wide angle) Zoom display 10 x W Approximate zoom ratio Power Zoom Lever BASIC RECORDING FEATURE: PURPOSE: To produce the zoom in/out effect, or an instantaneous change in image magnification. -
Page 17: Time Code
When recording is resumed, the time code starts counting up again from “00:00:00”. This means the camcorder may record the same time codes as those existing in a previously recorded scene. To prevent this, perform “Recording From The Middle of A Tape”... -
Page 18: Basic Playback
If still playback continues for more than about 3 minutes, the camcorder’s Stop mode is automatically engaged. After 5 minutes in the Stop mode, the camcorder’s power is automatically turned off. When 4/6 is pressed, the image may not pause immediately while the camcorder stabilizes the still image. Shuttle Search: Allows high-speed search in either direction. -
Page 19: Blank Search
... press 5. NOTES: In step 3, if the current position is at a blank portion the camcorder searches in the reverse direction, and if the current position is at a recorded portion the camcorder searches in the forward direction. -
Page 20: Connections
If a cable has only one core filter, the end that is closest to the filter should be connected to the camcorder. * When connecting the cables, open this cover. ** The Audio cable is not required for watching still images only. -
Page 21: Playback
The S-Video cable is optional. Be sure to use the pg. 20). YTU94146A S-Video cable. Consult the JVC Service Center described on the sheet included in the package for details on its availability. Make sure to connect the end with a core filter to the camcorder. -
Page 22: Features
ADVANCED FEATURES CONTENTS FOR RECORDING ... 23 – 30 Snapshot ... 23 Night-Alive ... 24 Program AE With Special Effects ... 24 – 25 Fade/Wipe Effects ... 26 – 27 Auto Focus/Manual Focus ... 28 Exposure Control ... 29 Iris Lock ... 29 White Balance Adjustment ... -
Page 23: For Recording
Press SNAPSHOT. If you press during Record-Standby ..“PHOTO” appears and a still image will be recorded for approx. 6 seconds, then the camcorder re-enters the Record-Standby mode. If you press during Recording ..“PHOTO” appears and a still image will be recorded for approx. -
Page 24: Night-Alive
26, 27). • “GAIN UP” in CAMERA MENU ( • “DIS” in MANUAL MENU ( During Night-Alive, it may be difficult to bring the camcorder into focus. To prevent this, use of a tripod is recommended. MENU/BRIGHT Wheel Lock Button... - Page 25 30) is initially set to but can be changed to your desired setting. When Twilight is chosen, the camcorder automatically adjusts the focus from approx. 10 m (32 ft) to infinity. From less than 10 m (32 ft), adjust the focus manually.
-
Page 26: Fade/Wipe Effects
If you start recording a new scene within 5 minutes of the end of the previous recording (without having turned the camcorder’s power off), the previous scene wipes out, revealing the new scene. pg. 24). ” while pressing down... - Page 27 Fader And Wipe Menu Menu FADER — WHITE FADER — BLACK FADER — B.W MOSAIC WIPE — CORNER WIPE — WINDOW WIPE — SLIDE WIPE — DOOR WIPE — SCROLL WIPE — SHUTTER DISSOLVE WIPE — CORNER WIPE — WINDOW WIPE —...
-
Page 28: Auto Focus/Manual Focus
FEATURE: PURPOSE: The camcorder’s Full Range AF system offers continuous shooting ability from close-up (as close as approx. 5 cm (2") to the subject) to infinity. However, correct focus may not be obtainable in the situations listed below (in these cases use manual focusing): •... -
Page 29: Exposure Control
To Return To Automatic Exposure Control ..press EXPOSURE twice or set the Power Switch to “ ”. (If EXPOSURE is pressed once, the camcorder will enter the exposure adjustment mode again.) To Brighten The Subject Quickly ..press BACKLIGHT. -
Page 30: White Balance Adjustment
If the white balance is correct, all other colors will be accurately reproduced. The white balance is usually adjusted automatically. However, more advanced camcorder operators control this function manually to achieve a more professional color/tint reproduction. Set the Power Switch to “... -
Page 31: Using The Menu For Detailed Adjustment
SYSTE D I SPL Normal Screen For Recording Menu This camcorder is equipped with an easy-to-use, on-screen menu system that simplifies many of the more detailed camcorder settings ( Set the Power Switch to “ the Lock Button located on the switch. -
Page 32: Off
•When shooting scenes with movement in various directions. •When shooting scenes with low-contrast backgrounds. Switch off this mode when recording with the camcorder on a tripod. The “ ” indicator blinks or goes out if the Stabilizer cannot be use pg. - Page 33 The tally lamp comes on to signal the start of recording. This number is necessary when connecting the camcorder to a device such as a computer using the J terminal (JLIP). The numbers range from 01 to 99. Factory setting is 06.
- Page 34 NOTES: If a tape is in the camcorder, the demonstration cannot be turned on. “DEMO MODE” remains “ON” even if the camcorder power is turned off. If “DEMO MODE” remains “ON”, some functions will not be available.
-
Page 35: For Playback Menu
(SP or LP) depending on your preference ( pg. 12). It is recommended you use “REC MODE” in the “ VIDEO” Menu when using this camcorder as a recorder during digital dubbing pg. 38). DISPLAY” SYSTEM”, which appears when ”... -
Page 36: Playback Sound
USING MENUS FOR DETAILED ADJUSTMENT PLAYBACK SOUND During playback, the camcorder detects the sound mode in which the recording was made, and plays the sound back. Select the type of sound to accompany your playback picture. According to the menu access explanation on pg. -
Page 37: Dubbing
The S-Video cable is optional. Be sure to use the YTU94146A S-Video cable. Consult the JVC Service Center described on the sheet included in the package for details on its availability. Make sure to connect the end with a core filter to the camcorder. The core filter reduces interference. -
Page 38: Dubbing To Or From A Video Unit With A Dv Connector
DV IN/OUT connector. When using a DV cable, be sure to use the optional JVC VC-VDV204U DV cable. ” while pressing down the Lock Button located on the switch. -
Page 39: Using The Remote Control Unit
USING THE REMOTE CONTROL UNIT The Full-Function Remote Control Unit can operate this camcorder from a distance as well as the basic operations (Playback, Stop, Pause, Fast-Forward and Rewind) of your VCR. It also makes additional playback functions possible. If you want to perform Random Assemble Editing ( control. - Page 40 (“ ” or “ ”) . Transmits the beam signal. Zoom in/out ( pg. 16) — — — — Functions the same as the Recording Start/Stop Button on the camcorder. — — — — — — — RM-V700U (optional) Functions With the camcorder’s Power Switch set...
-
Page 41: Playback Zoom
2) Press the Zoom Buttons (T/W) on the remote control. Make sure the remote control is pointed at the camcorder's remote sensor. Pressing T zooms in. To end zoom, press and hold W until magnification returns to normal. Or, press STOP (5) and then press PLAY (4). -
Page 42: Set Remote/Vcr Code
VCR CTL BUTTONS VCR BRAND NAME (A) (B) PHILIPS IMPORTANT Although the MBR is compatible with JVC VCRs and those of many other makers, it may not work with PANASONIC yours or may offer limited functions. NOTES: SANYO SHARP SONY... -
Page 43: Make Connections
Be sure to use the following cables: • YTU94146A S-Video cable. • YTU94154A Editing cable. Consult the JVC Service Center described on the sheet included in the package for details on its availability. Make sure to connect the end with a core filter to the camcorder. -
Page 44: Random Assemble Editing
PLAY IN/OUT CANCEL RM-V700U (optional) SELECT SCENES Point the remote control at the camcorder’s remote Random Assemble sensor. Press PLAY (4) and then press ON/OFF on Editing Menu the remote control. The Random Assemble Editing Menu appears. At the beginning of the scene, press IN/OUT on the remote control. -
Page 45: Automatic Editing To Vcr
PAUSE VCR REC STBY AUTOMATIC EDITING TO VCR Rewind the tape in the camcorder to the beginning of the scene you want to edit and press PAUSE (6). Point the remote control towards the VCR’s remote sensor and press VCR REC STBY (q6), or manually engage the VCR’s Record-Pause mode. -
Page 46: For More Accurate Editing
Record mode faster than others. Even if you begin editing Editing Menu for the camcorder and the VCR at exactly the same time, you may lose scenes you wanted, or find that you have recorded scenes you did not want. For a cleanly edited tape, confirm and adjust the timing of the camcorder against your VCR. -
Page 47: Audio Dubbing
Make sure you only edit recorded areas. If feedback or howling occurs during TV playback, move the camcorder’s microphone away from the TV, or turn down the TV’s volume. If you change from 12-bit to 16-bit in mid-recording and then use the tape for Audio Dubbing, it is not effective from the point where 16-bit recording began. -
Page 48: System Connections
DV connector-equipped capture board. When using a DV cable, be sure to use the optional JVC VC-VDV206U or VC-VDV204U DV cable depending on the type of DV connector (4 or 6 pins) on the PC, or use the DV cable provided with the capture board. -
Page 49: Connection To A Video Unit With A Dv Connector
DV connector, the image will take on an effect similar to a colored mosaic pattern or it will become black. Also refer to the instruction manuals of the connected units. When using a DV cable, be sure to use the optional JVC VC-VDV204U DV cable. pg. 38), which ” while... -
Page 50: References
REFERENCES CONTENTS DETAILS ... 51 TROUBLESHOOTING ... 52 – 56 USER MAINTENANCE ... 57 INDEX ... 58 – 62 Controls, Connectors And Indicators ... 58 – 59 Indications ... 60 – 62 CAUTIONS ... 63 – 65 TERMS ... 66 SPECIFICATIONS ... -
Page 51: Details
Be sure to use it only in well-ventilated areas. The following operation stops charging: Set the Power Switch to “ • Disconnect the AC adapter from the camcorder. • Unplug the AC adapter from the AC outlet. •... -
Page 52: Troubleshooting
If, after following the steps in the chart below, the problem still exists, please consult your nearest JVC dealer. The camcorder is a microcomputer-controlled device. External noise and interference (from a TV, a radio, etc.) might prevent it from functioning properly. In such cases, first disconnect its power supply unit (battery pack, AC Adapter, etc.) and wait a few minutes;... - Page 53 14. •Select Picture Wipe or Dissolve before beginning recording. The effects are then automatically activated pg. 26). •Do not turn off the camcorder’s power after setting Edit-In and Edit-Out points, as they will all be erased ( pg. 26). •The camcorder automati-...
- Page 54 SYMPTOM 15. The picture wipe function does not work. 16. Scene transition does not go as expected. 17. The Video Echo mode does not work. 18. Even when Slow Shutter is not selected, the image looks like it is activated. 19.
- Page 55 LCD monitor become dark. Consult your nearest JVC dealer. 26. •The light used to illuminate the LCD monitor causes it to become hot. 27. •This may occur when the surface or the edge of the LCD monitor is pressed.
-
Page 56: Troubleshooting
If the indication remains even though you repeat the above two or three times, please consult your nearest JVC dealer. 38. •To protect the battery, it is recommended to charge it in places with a temperature of 10°C to 35°C (50°F to 95°F) (... -
Page 57: User Maintenance
USER MAINTENANCE After Use Turn off the camcorder. Slide and hold OPEN/EJECT in the direction of the arrow, then pull the cassette holder cover open until it locks. The cassette holder opens automatically. Remove the cassette. Press “PUSH HERE” to close the cassette holder. -
Page 58: Index
INDEX Controls, Connectors And Indicators & 3 4 5 6 7... -
Page 59: Other Parts
& PC (DIGITAL PHOTO) Connector ... J Terminal [JLIP (Joint Level Interface Protocol)] ... Connect to a JLIP-compatible camcorder or VCR to control it from the computer using the Software. Connect the editing cable when performing Random Assemble Editing ... -
Page 60: Indications
Appears when the focus is adjusted manually. pg. 26, 27) Displays the Time Code. pg. 33) INDEX Indications & ’ monitor. 5 seconds after turning on the camcorder. pg. 16) pg. 12) pg. 14) pg. 14) pg. 23) pg. 14) pg. 33) pg. 14) pg. 32) pg. -
Page 61: Lcd Monitor/Viewfinder Indications During Playback
LCD Monitor/Viewfinder Indications During Playback Displays the sound mode. Displays the Blank Search mode. Displays the tape speed. Appears while a tape is running. : Playback 3 : Fast-Forward/Shuttle search 2 : Rewind/Shuttle search : Pause 64 : Forward slow-motion 16 : Reverse slow-motion : Audio Dubbing 6e : Audio Dubbing Pause... -
Page 62: Index
Appears when the date/time is not set. Appears when the built-in clock battery runs out and the previously set date/time is erased. Consult your nearest JVC dealer for replacement. Appears for 5 seconds after power is turned on if the lens cap is attached. -
Page 63: Cautions
In case of connecting the unit’s power cord to an AC wall outlet other than American National Standard C73 series type use an AC plug adapter, called a “Siemens Plug”, as shown. For this AC plug adapter, consult your nearest JVC dealer. Plug adapter General Battery Precautions... -
Page 64: Viewfinder
Also refer to the cleaning cassette’s instructions. If, after using the cleaning cassette, the problems still exist, consult your nearest JVC dealer. Mechanical moving parts used to move the video heads and video tape tend to become dirty and worn out over time. - Page 65 Serious malfunctioning If malfunctioning occurs, stop using the unit immediately and consult your local JVC dealer. The camcorder is a microcomputer-controlled device. External noise and interference (from a TV, a radio, etc.) might prevent it from function- ing properly.
-
Page 66: Terms
Brighten The LCD Monitor ... Channels (Left/Right) ... Charge The Battery Pack ... Cinema ... Classic Film ... Clean The Camcorder ... Connections ... pg. 7, 8, 20, 21, 37, 38, 43, 48, 49 Darken The LCD Monitor ... Date/Time Display ... -
Page 67: Specifications
Dimensions (W x H x D) Weight Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject to change without notice. Camcorder : DC 11.0 V (Using AC Adapter) DC 7.2 V (Using battery pack) : Approx. - Page 68 VICTOR COMPANY OF JAPAN, LIMITED Printed in Japan COPYRIGHT© 2001 VICTOR COMPANY OF JAPAN, LTD. 1200HOV...
