Planet DVR-461 Quick Manual

► Contents
DVR-461
Power Adapter

► Hard Disk Installation

Note: Before HDD installation, please make sure there is no pre-configured partition in this HDD.
If yes, please delete all the partition before install.
STEP 1: Remove the 3 screws from DVR-461
STEP 3: Place the HDD on the HDD plate of the
removed case and connect the power
and the SATA cable firmly
Quick Guide
CD Disk Battery x 2
Quick Installation Guide
SATA cable
Remote Control
STEP 2: Follow the direction to remove the
upper case
STEP 4: Put back the upper case and tight the
three screws
DVR-461
Power Cord
HDD Screw x 4
