DVR-462
Power Adapter

► Hard Disk Installation

Note: Before HDD installation, please make sure there is no pre-configured partition in this HDD.
If yes, please delete all the partition before install.
STEP 1: Remove the 3 screws from DVR-462
STEP 3: Place the HDD on the HDD plate of the
removed case and connect the power
and the SATA cable
CD Disk
I/O Cable
Quick Installation Guide
Battery x 2
SATA cable
STEP 2: Follow the direction to remove the
upper case
STEP 4: Put back the upper case and tight the
three screws
DVR-462
Remote Controller
HDD Screw x 4

Advertisement

loading
Need help?

Need help?

Do you have a question about the DVR-462 and is the answer not in the manual?

Questions and answers

Summary of Contents for Planet DVR-462

  • Page 1: Hard Disk Installation

    Note: Before HDD installation, please make sure there is no pre-configured partition in this HDD. If yes, please delete all the partition before install. STEP 1: Remove the 3 screws from DVR-462 STEP 2: Follow the direction to remove the...
  • Page 2: Quick Guide

    EXTERNAL I/O port. Network port. Connect to your switch or PC directly. Connect your USB mouse to control this DVR. For detailed information about DVR-462, please refer to the User’s Manual in the CD disk. Quick Guide PLANET Technology Corporation 11F., No.96, Minquan Rd., Xindian Dist., New Taipei City 231, Taiwan (R.O.C.)
