Planet DVR-1670 User Manual

4/16-channel h.264 digital video recorder
Hide thumbs Also See for DVR-1670:
Table of Contents

Advertisement

Quick Links

Download this manual
4/16-Channel
H.264 Digital Video Recorder
DVR-470
DVR-1670
USER'S MANUAL
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVR-1670 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Planet DVR-1670

Summary of Contents for Planet DVR-1670

  • Page 1 4/16-Channel H.264 Digital Video Recorder DVR-470 DVR-1670 USER’S MANUAL Page 1...

  • Page 2: Fcc Caution

    Copyright Copyright © 2007 by PLANET Technology Corp. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of PLANET.
  • Page 3 Do not dispose of WEEE as unsorted municipal waste and have to collect such WEEE separately. Revision User’s Manual for PLANET 4/16-channel H.264 Digital Video Recorder Model: DVR-470 / DVR-1670 Rev: 1.0 (March, 2007) Part No. EM-DVR460_1670 Page 3...

  • Page 4: Table Of Contents

    Chapter1 Product Introduction...6 Summary ...6 Features ...6 Chapter2 Installation...8 Checking the DVR and Its Accessories...8 HDD Installation ...8 Rear Panel Description...9 External Alarm In/Out Connection ...10 Chapter3 Operational Instructions ...11 Front Panel ...11 IR Controller ...13 Menu Description...15 3.3.1 Menu Items ...15 3.3.2...
  • Page 5 DVR Connect Cable Definition ...90 UTP network connect cable made method...90 RS-232 connect cable made method ...91 Appendix B Specifications ...92 Appendix C List of Recommended DVR Peripherals ...94 Appendix D Quick Search Function Table ...96 Appendix E Troubleshooting ...98 Page 5...

  • Page 6: Chapter1 Product Introduction

    Support max. 16 channels video input (PAL/NTSC) at most. Each channel is independent, H.264 hardware compression. For DVR-470 , total frame is 100FPS (PAL) or 120FPS (NTSC). For DVR-1670, total frame is 200FPS (PAL, first 8-ch 100FPS and second 8-ch 100FPS) or 240FPS (NTSC, first 8-ch 120FPS and second 8-ch 120FPS).
  • Page 7 Network record live stream. Network download and playback the recorded files in DVR. Remote upgrade the firmware. RS-232 supports transparent channel function so that the remote PC can use DVR to control serial devices. Support IE to preview and config DVR.

  • Page 8: Chapter2 Installation

    HDD Installation Installation notice The DVR has not HDD when leaving factory. Based on the record schedule, you can calculate the total capacity you need (refer to Appendix A). Please ask the specialist to disassembly the DVR and install HDD.

  • Page 9: Rear Panel Description

    Standard BNC. Connect monitor, output video and menu. 1 channel RCA (1.0 Vp-p, 75 4 channel RCA (1.0 Vp-p, 75 DVR-1670 uses DB15 connectores. DVR-470 uses on board BNC connectors. VGA display. Connect RS-232 devices. Refer to Appendix B for pin definition.

  • Page 10: External Alarm In/Out Connection

    Please note the usage of jumper JJ1. If you use DC, either of connections is OK. We suggest you to use those DC under 12V, 1A. If you use AC, please open the jumper. There are 4 jumpers (JJ1, JJ2, JJ3 and JJ4) in DVR main board, corresponding with 4 alarm output. The default is closed.

  • Page 11: Chapter3 Operational Instructions

    MENU Function Keys EDIT PLAY Name DVR is ready. Green means you can use IR remote control. Red means there is alarm. Twinkle in red means reading or writing HDD. Network status. IR receiver. Input number, lower case, upper case character and symbols.
  • Page 12 3. Playback speed control. Menu confirmation; Select or × to enable or disable; Pause playback. Device switch with power indicator lamp. Green means DVR is working; Red means DVR is powered off; No light means no power is supplied. Page 12...

  • Page 13: Ir Controller

    IR Controller Index Name POWER Numeric Keys EDIT PLAY INFO VOIP MENU PREV Direction Keys ENTER Description Turnoff device. Enable/Disable IR remote control Same as numeric keys of front panel. Same as EDIT key of front panel. Same as A key of front panel. Same as REC key of front panel.
  • Page 14 Press【DEV】key, input the DVR device ID (default is “88”, can be changed in “Display” menu) and then press 【 ENTER】 key. If the “STATUS” lamp of DVR front panel is turned into green, it means you can use IR controller to operate this DVR.

  • Page 15: Menu Description

    Mask area setup Image View tampering area and response setup Video signal loss Motion detection sensitivity, area and response setup DVR IP address DNS IP Multicast IP address Network Remote host IP and port NAS IP and directory PPPoE username and password...

  • Page 16: Menu Operation

    Text information 3.3.2 Menu Operation How to enter into menu mode Press【MENU】key to enter into DVR main menu. Press【PLAY】short key to enter into playback menu. Perss【REC】short key to enter into manual record menu. Perss【PTZ】short key to enter into PTZ control interface.
  • Page 17 Each menu contains different kinds of items. There is a small rectangular frame named “Active Frame” which is pointing to the selected item. This “Active Frame” can be moved by 【 】or【 】keys. There are such kinds of menu items： 1.

  • Page 18: Character Input

    Character Input In the menu interface, if you enter into edit status (for example, in the “camera name” edit box), at the bottom of screen, the input status is appeared： Here it means you can press numeric keys to input digital number. Press 【A】...

  • Page 19: Chapter4 Basic Operation Guide

    Step2：Switch on the power button on the real panel. If【POWER】lamp is in red, just press【POWER】button to start DVR. When DVR is started, 【 POWER】lamp is in green. On the monitor or VGA display, DSP and HDD initialization process will be shown.
  • Page 20 Camera record status is following： Icon Icon Color Status Description White No video signal Yellow Vdieo input Pink Manual recording Green Real time recording Blue Motion detect recording External alarm recording Page 20...
  • Page 21 Yellow Pink Green Blue Press numeric keys to switch over individual camera preview. If DVR has less than 10 channels, press one numeric key to switch corresponding channel. For example, press 【 2】 key to preview 2 camera. If DVR has 10 or more than 10 channels, press two numeric keys to switch corresponding channel.

  • Page 22: User Name And Password

    The “Active Frame” will be moved to “Confirm” button. Press【ENTER】key to enter into main menu. If there is beeper alarm, it means the user name and password are not matched. After three error times, DVR will enter into preview mdoe.
  • Page 23 Setp 2：Enter into password modification menu Move the “Active Frame” to “Password” icon by using【 】/【 】keys. Press【ENTER】 key to enter into following password menu： Step 3：Input new password Press【EDIT】key to enter into edit box. You can use numeric keys to input new password. The password can be null.

  • Page 24: Ptz Control

    1 camera PTZ. Select channel In PTZ control mode, you can press numeric keys to select channel. If DVR has less than 10 channels, press one numeric key to select. For example, press【2】 key to selct 2 PTZ.
  • Page 25 In PTZ control mode, press【REC/SHOT】key, and press the preset number (three numeric keys), DVR will adjust the corresponding preset number. Repeat pressing【REC/SHOT】key, and press the preset number, DVR will adjust that preset number. When you exit PTZ control mode, the camera will stay at the current position.

  • Page 26: Manual Record

    Manual Record Note：The user must have the corresponding right, DVR has HDD and HDD is formatted already. Manual record In preview mode, press【REC】key, in the pop-up login dialog, select the name and input the correct password, you can enter into the “Manual Record” interface.

  • Page 27: Playback

    Card Number：DVR can get text number through RS-232 or network port. The text is sent from devices such as ATM machine, POS machine or others. DVR can overlay the text on the real time image and record. You can use the text to search the recorded files and playback them.
  • Page 28 If the second channel is selected, these two channels can be playbak synchronously. If DVR can not find the matched files, a failure dialog box will be pop-up. 2. Playback by Time：In the playback interface, select channel number, record type and time section, move “Active Frame”...
  • Page 29 If the matched files are more than 8, you can use numeric keys or【↑】 【↓】keys to select page. Use【↑】 【↓】keys to move scroll bar to the file, press【ENTER】key to playback the selected file. If DVR can not find the matched files, a message dialog will be pop-up. Operation when playback Playback picture：...
  • Page 30 Exit playback In playback interface, press【ESC】key to enter into preview mode. In playback interface, press 【MENU】 key to enter into main menu, press 【REC】 key to enter into manual record, and press【PTZ】key to enter into PTZ control mode. Page 30...

  • Page 31: Backup Recorded Files

    A pop-up dialog will display the backup status. If bakup device is not connected correctly or DVR do not detect the backup device, the following dialog will be pop-up. Please ask administrator for more information.
  • Page 32 You can repeat step 2 to select many segments. 30 segments can be selected in all; After you select all segments, press【ESC】key, a message window will pop-up. If you press “Confirm” button, DVR will start to backup the selected segments. If you press “Cancel” button, DVR will abort backup.

  • Page 33: Shut Down Dvr

    DVR can not be shut down. Shut down DVR abnormally Use the power switch of real panel When DVR is run, if you switch off the power, the HDD in DVR will be damaged. Please avoid such operation. Take away the power cable Please avoid taking away the power cable directly.

  • Page 34: Chapter5 Parameters Setup Guide

    RS232 work mode Change video output standard Administrator and Password When DVR is left from factory, there is one default administrator. The name is “admin” and password is “12345”. The name can not be changed, while the password can be. Password modification Press【MENU】key, in the login dialog, select the username as “admin”, use【→】key, move...
  • Page 35 Move “Active Frame” to “User” icon, press【ENTER】key to enter into “User Management” menu. In the user name list box, only “admin” is existed. You can use【→】key, move “Active Frame” to password edit box, and press【EDIT】key to enter into edit status. Press numeric keys to input the new password.

  • Page 36: Add And Delete User

    Add and Delete User Enter into “User Management” interface. Add user The steps are following： Step 1：Enter into “User Management” menu Please refer to chapter 5.1 Step 2：Add new user name In the “User Management” menu, move “Active Frame” to “Add” button and press 【ENTER】, in the pop-up dialog, input the new user name (refer to chapter 3.4), press 【ENTER】and return “User Management”...
  • Page 37 PTZ control：Locally control PTZ; Record：Manual start/stop recording; Playback：Local playback and backup the recorded files; Parameters Setup：Locally setup the DVR parameters; Log：Locally view the log on DVR; Utilities：Locally upgrade firmware, format HDD, reboot DVR and shut down DVR, etc. Page 37...
  • Page 38 Com Control：DVR RS-232 transparent channel function. MAC address This MAC address is not the address of DVR but the PC that will access DVR. If you setup this MAC address, only the PC with this MAC address can access this DVR. At PC end, in DOS prompt, you can use “ipconfig”...

  • Page 39: Unit Name And Device Id

    When you use IR controller to operate DVR, you must use device ID to select DVR. The default device ID of DVR is “88”. If there are more than one DVR in one place, please define different device ID for each DVR. Otherwise, the IR controller will control all DVR with the same device ID at the same time.

  • Page 40: Video Output Standard And Vga Setup

    NTSC video output. VGA setup There is one VGA interface at the real panel of DVR. You can use it to connect with VGA display. You can define VGA resolution, refresh frequency in “Display” menu. There are following options：1024*768/60Hz, 800*600/60Hz and 800*600/75Hz. You can use【...

  • Page 41: Osd Setup

    OSD settings include： System time, time format, time display position, camera name, camera name display position, etc. System Time In “Display” menu, you can setup DVR system date and time. Display System Time You can setup display properties for each camera, including display status, position and format.
  • Page 42 Display mode：There are several display modes：Opaque&Steady, Transparent&Steady, Transparent&Flashing, Opaque&Flashing, Move “Active Frame” to “OSD” item, you can select one mode. Display position and format： Move “Active Frame” to “Position” button on the right side of “OSD”, press 【ENTER】to enter into setup image, you can find there are 22*18 (for NTSC, 22*15) small panes, and OSD position is in red.
  • Page 43 Chapter 3.4). The camera name can support 32 characters. Step 3：Press【ENTER】key to exit edit status. Move “Active Frame” to “Confirm” button, press 【 ENTER】 to save the modification and you can see the new camera name. Press “Cancel” button or【ESC】key to abort. Setup Camera Name Position If you do not want to display camera name, just disable the check box beside camer name edit box.

  • Page 44: Video Parameters Setup

    Video Parameters Setup For different camera and different background, in order to get the best video image, you need to adjust video parameters such as brightenss, saturation, contrast and hue, etc. You can setup the camera individually, and also you can copy the video parameters of one camera to any other cameras.

  • Page 45: Mask Area Setup

    Mask Area Setup In some cases, maybe you want mask the sensitive area. This area will not be preview and recorded. The mask area setup steps are following： Step 1：Enter into “Image Setup” menu： Step 2：Select one camera：You can use【 】 【 】keys to select one camera. Step 3：...
  • Page 46 (22*15 for NTSC), you can use【↑】 【↓】 【→】 【←】keys to move the yellow pane to your hope position and press【EDIT】key, the yellow pane will be turned into red, then you can use【↑】 【↓】 【→】 【←】keys to extend the red pane. This red area is the mask area.

  • Page 47: View Tampering Alarm

    View Tampering Alarm If you enable this function, when someone blocks the camera spitefully, DVR will make warning alarm. Step 1：Enter into “Image Setup” memu： Step 2：Select camera：Please use【 】 【 】keys to select one camera. Step 3：Select sensitivity：You can use【↑】 【↓】keys to select the sensitivity for “View Tampering”...
  • Page 48 You can set 4 periods for each day one week. Also you can copy the schedule of one day to other days. Notes：Time periods can not be repeated. Please reboot DVR to make the parameters into effective.

  • Page 49: Video Loss Alarm

    Step 4： Setup alarm schedule： You can setup working schedule. Only when the video loss is happened in the schedule, DVR will response. Note：The 4 time periods can not be repeated. Please reboot DVR to make parameters into effective. Page 49...
  • Page 50 Step 5：Setup alarm policy：You can select one or more response solutions, including “On Screen Warning”, “Audible Warning”, “Upload to Center” and “Trigger Alarm Output”. You can use 【↑】 【↓】and 【EDIT】key to enable or disable them. “×” is disable and “ ” is enable.

  • Page 51: Motion Detection Alarm

    5 (the highest) and “Off”. You can use【↑】 【↓】keys to select one. If you select “Off” option, DVR will not response even if there is motion detection. If you select other options, it will active “Motion Area Setup” button and “Policy Setup” button. If you select low sensitivity such as 0, only when there are great motion detection, DVR can response.
  • Page 52 The whole screen is divided into 22*18 panes (NTSC：22*15). There is one yellow panel on the upper left side. The motion area setup steps are the same as that of mask area setup (refer to chapter 5.7). The only differences are that you can use 【 PTZ】 key to set the whole screen as motion area, and mutil motion areas can be defined.
  • Page 53 “Rec Type” as “Motion Detection” or “Motion | Alarm”. Please refer to chapter 5.12 for recording setup. Step 7： Motion alarm schedule： When the motion alarm is happened in schedule, DVR will response such as “On Screen Warning”, “Audible Warning”, “Upload to Center” and “Trigger Alarm Output”.

  • Page 54: Preview Properties

    Preview mode：For preview mode item, you can use【↑】 【↓】key to select one mode. If DVR has only 1 channel, you can select only “1 Screen” option. If DVR has 4 channels, there are “1 Screen” and “4 Screen” options. If DVR has more than 4 but less than 9 channels, there are “1 Screen”, “4 Screen”...
  • Page 55 Secondly, move “Active Frame” to one of these windows, press numeric keys to input camera index (If DVR has less than 10 channels, just use one numeric key, otherwise, use 2 numeric keys). The small window will display that camera number. In this way you can change the display order.

  • Page 56: Recording Setup

    CIF, 2CIF, DCIF, 4CIF. DVR-470 supports QCIF and CIF. 100FPS (PAL) or 120FPS (NTSC) DVR-1670 supports QCIF and CIF. First 8-ch has 100FPS and second 8-ch has 100FPS (PAL) or first 8-ch has 120FPS and second 8-ch has 120FPS (NTSC) Note：If you change this resolution option, please reboot DVR to make it into effective.
  • Page 57 If you select variable bit rate, DVR will adjust the actual bit rate according to the video movement. When there is not much movement, DVR will use low bit rate, while there is much movement, DVR will use high bit rate. In this case, DVR can save HDD usage and network bandwidth.
  • Page 58 Note：When the camera’s recording schedule is modified, you must reboot DVR to make it into effective. All day recording setup： Step 1：Enter into recording schedule menu In recording menu, use【ENTER】or【EDIT】key to enable record function (“ ” flag), press “Schedule” button to enter into recording schedule menu.
  • Page 59 Step 1：Enter into recording schedule menu In recording menu, use【ENTER】or【EDIT】key to enable record function (“ ” flag), press “Schedule” button to enter into recording schedule menu. Step 2：Select ond day and disable all day recording option For “Day” item, there are options：Monday, Tuesday, Wednesday, Thursday, Friday, Saturday and Sunday.

  • Page 60: External Alarm Input And Relay Output

    5.13 External Alarm Input and Relay Output For DVR-470, there are 4 external alarm input and 2 relay output. For DVR-1670, there are 16 external alarm input and 4 relay output. In “Alarms” menu, you can setup for each external alarm input. In main menu, move “Active Frame” to “Alarms” icon and press 【ENTER】key to enter into alarms menu：...
  • Page 61 “Alarm” or other related type. Please refer to chapter 5.12. Step 5：Schedule for alarm handle method When there is external alarm happened in the schedule, DVR will response according to the handle methods. Step 6：Alarm handle method You can select one or more handle method：“On Screen Warning”, “Audible Warning”,...
  • Page 62 First select one camera, then select one of following PTZ linkage： Preset：Set the flag as “ ” to enable preset, in the preset number edit box and input one preset number that has been setup already. Please refer to chapter 5.15 for preset setup. Sequence：Set the flag as “...
  • Page 63 In “Alarms” menu, you can copy parameters of current alarm output to other alarm output. Step 6：Save setup When you finish setup, in “Alarms” menu, press “Confirm” button to save all parameters. Note：If any schedule is modified, you must reboot DVR to make it into effective. Page 63...

  • Page 64: Network Parameters

    IP with one fixed Internet IP, DVR will send some information such as DVR name, DVR serial number, DVR current IP to that fixed IP address. We call that fixed Internet IP as DNS IP. The DNS server with that fixed Internet IP can receive DVR information and used to resolve DVR dynamic IP.

  • Page 65: Ptz

    IP address in “Network” menu. 5.15 PTZ There is one RS-485 port at DVR rear panel used for PTZ control. You can setup RS-485 parameters to match your PTZ protocol. In main menu, move “Active Frame” to PTZ icon and press【ENTER】key, you can enter into PTZ menu as following：...
  • Page 66 KTD-348, infinova, PIH-7625, LCU, DennarDome, etc. Other PTZ protocols will be added with the new firmware. Note：In DVR “PTZ” menu, if you select Pelco-P protocol, when you setup PTZ address, please plus or minus one compared with Camera ID. For example, if camera ID is 2, the DVR PTZ address is set as ID 3.
  • Page 67 Cruise setup：Cruise is remembering the track of PTZ movement. Please make sure the PTZ you are using can support cruise function. Preset setup In “PTZ” menu, move “Active Frame” to “Setup” button on the right side of “Preset” item, press【ENTER】, you can enter into “Preset” setup menu： Add preset number：You can input preset number (among 1-128) in the edit box.
  • Page 68 In “Sequence” setup menu, first input the sequence number. The sequence is among 1 --- 16. Each sequence is made up of cruise points, and each cruise point includes preset number, dwell time and dwell speed. Dwell time is the time staying at that preset number. Dwell speed is the speed that PTZ is moved to that preset number.
  • Page 69 Press “RecCru” button, you will enter into “PTZ control” interface. You can start controlling PTZ with direction keys, press 【 ENTER】 to save the operation track and return “Cruise” setup menu. Press “StartCru” button to repeat the PTZ track until you press “Stop” button. Press “Return”...

  • Page 70: Rs232 Setup

    5.16 RS232 setup There is one RS-232 port at DVR rear panel. In main menu, move “Active Frame” to “RS232” icon and perss【ENTER】key, you enter into “RS232” setup menu： RS232 menu description RS-232 parameters：Including baud rate, data bit, stop bit, parity, flow control, etc.
  • Page 71 Confirm：Save parameters and return main menu. Cancel：Abort modification and return main menu. Example：PPP (Modem) passive dialup through PSTN There are two Modems. One is connected DVR RS-232 port with DCE cable. The other is connected with PC COM port. Setup at DVR end Step 1：...
  • Page 72 Step 3：Save setup In “Recording” menu, press “Confirm” button to save parameters. Step 4：Setup Modem used on DVR side Use DCE calbe to connect Modem with PC serial port. You can use HyperTerminal or NetTerm to setup modem： AT&F ---- Retore default parameters (Generally, Modem is hard flow control) AT&S0=1---- Set Modem as answer...
  • Page 73 Page 73...
  • Page 74 Step 3：Establish the dialup connection Select the Modem connected with PC just like the dialup network connection, input the telephone number connected with DVR’s modem. Input the username, password. They must be the same as that DVR PPP setup. Step 4：During the dialup connection, it will give the message of “verification of username and password”, after successfully verification;...

  • Page 75: Exceptions

    IP address conflict, network failure, and NTSC/PAL differ. Enter into “Exceptions” menu： Including the following handle methods： Audible Warning：DVR beep warning. Upload to Center：Send exception information to center host PC. Trigger Alarm Output：trigger local relay output. You can select more than one handle methods.

  • Page 76: Transaction Information

    5.18 Transaction Information The DVR can actively obtain or passively receive the credit card number from ATM machine linked through network or serial port, and credit card number can be overlay on live video, recorded and playback. The following description indicates how to carry out relevant parameter setting according to different links to ATM machine.
  • Page 77 Transaction type and code When the ATM machine is sending transaction information to bank center, DVR will capture the data package through network, and analyse the data according to the format. Then DVR will overlay the correspond text on live video.
  • Page 78 In the case, you must set the RS-232 of DVR as transparent channel mode as following： A software must be run in the ATM machine, and send the credit card number, transaction code to DVR through RS-232 port. Please provide detail ATM machine communication protocol for actual projects.
  • Page 79 In the case, you must set the RS-232 of DVR as transparent channel mode as following： Also, a software must be run in ATM machine, and send command to DVR through RS-232 port based on special communication protocol. Page 79...

  • Page 80: Chapter6 Utilities

    Save Parameters Save factory default parameters into FLASH memory. You can reboot DVR to make them into effective. Restore Parameters Restore factory parameters for DVR. The IP address, gateway and port number will not be restored. Chapter6 Utilities Page 80...

  • Page 81: Upgrade

    Input the ftp server IP and press【ENTER】key. DVR will connect with FTP server through network and download the firmware file. If you select “USB” mode, please make sure you connect one USB flash memory with DVR and the firmware file is in its root directory.

  • Page 82: Hard Disk Management

    Check HDD work status Capacity, Free space, Stand by or not, Normal status or not. Format HDD Before formatting stop all recording. After formatting, you must reboot DVR, otherwise DVR will not work normally. Clear Alarm Out Clear the alarm output manually.
  • Page 83 If you want to view the log based on default option, just press 【 ENTER】 key. DVR will list all matched information. Also you can select options to search (By Type, By Date, By Type&Date). By Type To view log information of the assigned type.
  • Page 84 Step 4：When searching is finished, DVR will list all matched alarm information. In the list box, the information includes：Index, Occur Time, Major Type, Minor Type, Panel User, Net User, Host Address, Para. Type, Channel No, HDD No, Alarm In and Alarm Out. You can press “More Info”...

  • Page 85: System Information

    System Information Press “System Info” icon in “Utilities” menu, you can get DVR system information： Page 85...

  • Page 86: Chapter7 Firmware Upgrade

    Chapter7 Firmware Upgrade The DVR firmware is stored in FLASH ROM. You can use DVR upgrade function to write the firmware file (digicap) into FLASH. There are two cases that you need to upgrade DVR firmware. One is update old firmware.
  • Page 87 Select “Users/rights” under “Security” menu item. The following dialog box will be pop-up. Create new user. Click “new user’. New user dialog pops up. Input user name “target”. Click “OK”. In the password dialog, input password “target” in “New Password” and “Verify Password”...
  • Page 88 In the “User/Rights Security” Dialog, select “User Name” as “target”. In “Home Directory” edit box, input the path where the firmware file (digicap) is placed. Then press “Done” to exit. 7. Next time, you need not setup again, just double click and open “wftpd32.exe” to upgrade the DVR/DVS firmware. Page 88...

  • Page 89: Upgrade Mode

    (digicap) is placed under root directory of USB flash memory. After you reboot DVR, if you can only hear the startup sound, but can not see startup picture, you can input shell commands under HyperTerminal. You need one host PC to run FTP server and HyperTerminal software, and make sure DVR and host PC are in the same sub net.

  • Page 90: Appendix Advr Connect Cable Definition

    Pin definition To make the network cable according to the actual situation, there are two options： (1) Use the following method to make the network cable when DVR is connected with network hub or switch. The corresponding relationship of the direct cable (2) Use the following method to make the cross network cable when DVR is directly connected with client-end PC.

  • Page 91: Rs-232 Connect Cable Made Method

    The corresponding relationship of cross cable 2 RS-232 connect cable made method DVR-802x has standard DB9 RS-232 interface, like PC COM port. Pin definition “I” means DVR input and O means DVR output. Pin index Name Description Carrier Detect Receive Data...

  • Page 92: Appendix B Specifications

    Relay output Appendix B Specifications DVR-470 H.264 PAL：704*576 (4CIF), NTSC：704*480 (4CIF) CIF/QCIF BNC (Electrical Level：1.0Vp-p, resistance：75Ω) 32Kbps--2Mbps, self-define 1 channel, RCA (Linear Electrical Level, OggVorbis 16Kbps Page 92 DVR-1670 PAL：200FPS NTSC：240FPS Video/Video&Audio RCA (Linear Electrical Level, Resistance：600Ω) Resistance：600Ω) OggVorbis 16Kbps...
  • Page 93 Power supply Power consumption Working temperature Working humidity Size Weight PAL：176*144(QCIF), 352*288(CIF), 704*288(2CIF), 528*384(DCIF), 704*576(4CIF); NTSC：176*120(QCIF), 352*240(CIF), 704*240(2CIF), 528*320(DCIF), 704*480(4CIF). 100~240VAC, 6.3A, 50~60 HZ 20--42W (without HDD) -10℃--＋55℃ 10％--90％ 14.25 inch standard (440mm*390mm*70mm) ≤8Kg (without HDD and CD-R/W) Page 93...

  • Page 94: Appendix C List Of Recommended Dvr

    Appendix C List of Recommended DVR USB DVD-R/W： LG GSA-E10L 2. BENQ EW164B USB CD-R/W： 1. BENQ external 5232WI-ok2 2. ASUS CRW-4824A + USB Convertor case 3. SONY CD-R/RW CRX230AD + Convertor cable 4. SONY CD-R/RW CRX225E + Convertor cable 5.
  • Page 95 West Digital： 1. WD Caviar WD400BB 2. WD Caviar WD800BB 3. WD Caviar WD1200BB 4. WD Caviar WD2000BB 5. WD Caviar WD2500BB 6. WD Caviar SE WD1600BB 7. WD Caviar SE WD2000JB 8. WD Caviar SE WD2500JB 9. WD Caviar SE WD3000JB Page 95...

  • Page 96: Appendix D Quick Search Function Table

    Exception response, such as HDD error, HDD full, illegal access, etc. Recording, video loss status display. Using PPPoE dialup function, support DNS. TCP, UDP, RTP, Multicast. Control DVR through network. Send alarm information to host PC through network. Remote control PTZ. Remote setup DVR parameters. Page 96 Index 4.3&5.1...
  • Page 97 View log 【*Note】The network SDK and client demo source code are included in attached CD. Remote record real time stream. Remote playback the recorded files in DVR Download recorded files in DVR. Remote upgrade firmware. Remote control serial device connected with serial port of DVR.

  • Page 98: Appendix E Troubleshooting

    DVR continuously reboots after start up, and makes a sound like “di” every 10 seconds. There are no images in the monitor connected with VOUT after DVR is started.
  • Page 99 Notes： Place the DVR in well ventilated space so that it operates within the allowed range of temperature and humidity as in specification. If the circuit board is wet, dust on circuit board can cause a short circuit. The circuit board, lug and socket, housing fan and housing should be cleaned by brushing regularly.
