Planet DVR-462 Quick Installation Manual

► Contents
DVR-462
Power Adapter

► Hard Disk Installation

Note: Before HDD installation, please make sure there is no pre-configured partition in this HDD.
If yes, please delete all the partition before install.
STEP 1: Remove the 3 screws from DVR-462
STEP 3: Place the HDD on the HDD plate of the
removed case and connect the power
and the SATA cable
Quick Guide
CD Disk Battery x 2
Remote Control
Quick Installation Guide
SATA cable
STEP 2: Follow the direction to remove the
upper case
STEP 4: Put back the upper case and tight the
three screws
DVR-462
HDD Screw x 4
