Avaya Voice Priority Processor
Installation

Connect Power

4. Connect the power plug from the AC adapter to the jack labeled PWR on the Avaya Voice
Priority Processor.
Use only the provided Class II AC Adapter with output 24VDC, 1A.
5. Plug the AC adapter into an 110VAC outlet to apply power to the Avaya Voice Priority
Processor.
6. The system will cycle through diagnostic testing and the LEDs will blink for about one minute.
When the system is ready for use:
• The
ERROR
•
should be blinking.
Status 1
After the Avaya Voice Priority Processor is installed, you must configure the Wireless IP Telephones.
For Wireless IP Telephone configuration, see the Avaya 3606 Wireless IP Telephone Installation and
Configuration Guide or the Avaya 3616/3626 Wireless IP Telephone Installation and Configuration
Guide.
10
LED should be off.
555-301-102, Issue 2
July 2003
