Avaya X330F2 Installation Manual

Avaya
Avaya X330F2 Installation Guide

Installing the Expansion Sub-module in the Avaya P330

Removing an Existing Expansion Sub-module

Catalog No. 130102 Rev. B June 2001
The Avaya X330F2 Expansion sub-module provides two fiber Fast Ethernet
100Base-Fx ports.
1 Remove the blanking plate or other sub-module (if installed).
2 Insert the sub-module gently into the slot, ensuring that the Printed Circuit
Board (PCB) is aligned with the guide rails.
The PCB not the metal base plate fits into the guide rail.
3 Press the sub-module in firmly until it is completely inserted into the
Avaya P330.
4 Gently tighten the two screws on the front panel of the expansion sub-module
by turning the screws.
Caution: The expansion sub-modules contain components sensitive to electrostatic
discharge. Do not touch the circuit board unless instructed to do so.
1 Loosen the screws by turning the knobs.
2 Grasp the two knobs one near each side of the front panel, and pull gently but
firmly towards yourself.
3 Insert another expansion sub-module or the blanking plate.
Note: The Avaya P330 switch must not be operated with the expansion slot open;
the expansion sub-module should be covered with the supplied blanking plate if
necessary.
Note: X330F2 sub-modules are hot swapable and can be inserted or removed in an
operating base unit.
