subject:
PARTNER® ACS Release 7.0 Attaching a Modem to the
Administration Serial Port
Issue 1.0
COMPAS ID: 104200
1
Introduction
This document explains how to attach a US Robotics modem to the Administration Serial
Port of a PARTNER ACS R7 processor. This procedure can be used for other modem
brands, however you must consult your modem's documentation for the equivalent
settings.
2
Tasks Performed
Configure the modem for Administration Serial Port connectivity.
Connect the modem to the Administration Serial Port.
Program PARTNER in order to remove ringing lines from the modem's extension
(depending on connectivity method used).
3
Equipment Needed
In order to configure the modem:
PC with an available serial port and terminal emulation software such as
HyperTerminal.
DB-9 to DB-25 cable (AT modem cable)
To connect the modem to the PARTNER Administration Serial Port:
Standard RJ-45 cable
DB-25 to RJ45 adaptor (355A adaptor or equivalent)
DB-25 to DB-25 Null Modem
8/15/2008
Engineer's Notes
Avaya, Inc. Proprietary
Use Pursuant to Company Instructions
1
April 23, 2004
date:
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Avaya PARTNER ACS R7
Summary of Contents for Avaya PARTNER ACS R7
- Page 1 This document explains how to attach a US Robotics modem to the Administration Serial Port of a PARTNER ACS R7 processor. This procedure can be used for other modem brands, however you must consult your modem’s documentation for the equivalent settings.
- Page 2 Connecting to PARTNER This is the step-by-step procedure for connecting the US Robotics modem to the PARTNER ACS R7 processor. The procedure can be performed while the PARTNER is on and operating. 1. With the modem off, set DIP switches 4 and 8 down and all others up.
- Page 3 ON = Down, OFF = Up. Initialization String The modem initialization string for this configuration has the following definition: at&f0q1e0s0=3&w AT command Description &f0 Set to Factory Defaults (no Flow Control) Eliminate result codes Avaya, Inc. Proprietary Use Pursuant to Company Instructions 8/15/2008...
- Page 4 Disable echoing of local commands s0=3 Auto Answer on the third ring Store configuration to modem’s NVRAM &w Avaya, Inc. Proprietary Use Pursuant to Company Instructions 8/15/2008...
