Summary of Contents for Edge-Core ES4005V

  • Page 1 Powered by Accton 5/8-Port Gigabit Switch Installation Guide ES4005V ES4008V www.edge-core.com...
  • Page 3 Quick Installation Guide 5-Port Gigabit Ethernet Switch Gigabit Ethernet Switch with 5 10BASE-T / 100BASE-TX / 1000BASE-T (RJ-45) Ports 8-Port Gigabit Ethernet Switch Gigabit Ethernet Switch with 8 10BASE-T / 100BASE-TX / 1000BASE-T (RJ-45) Ports...
  • Page 4 ES4005V ES4008V E032005-R01 150000017400H...
  • Page 5: Table Of Contents

    Contents Introduction Features and Benefits Front Panel RJ-45 Ports LEDs ES4005V ES4008V Rear Panel Installing the Switch Package Contents Selecting a Site Instructions Applications Product Specifications Physical Characteristics Switching Criteria Troubleshooting Diagnosing Switch Indicators Power and Cooling Problems Installation Cables...
  • Page 6 Contents...
  • Page 7: Introduction

    Introduction These switches are high-performance Gigabit Ethernet switches designed for delivering Gigabit connectivity to the desktop. They provide 5/8 full-duplex 1000BASE-T ports that significantly improve network performance and boost throughput for high-bandwidth applications. With 10/16 Gigabits of aggregate bandwidth, these switches provide the quickest solution to meeting the growing demands on your network's limited resources.
  • Page 8: Leds

    Traffic is passing through the port. 1000M Indicates the port is operating at 1000 Mbps. Indicates the port is not operating at 1000 Mbps. ES4005V ES4008V Rear Panel The DC power receptacle is located on the rear panel of the switch.
  • Page 9: Installing The Switch

    Note that the switch can be installed on any suitable large flat suface. Package Contents This package includes: • 5/8-Port Gigabit Ethernet Switch (ES4005V or ES4008V) • Four rubber foot pads • Appropriate DC power adapter • This User Guide...
  • Page 10: Applications

    Installing the Switch Connecting PCs: Connect each PC to an RJ-45 port on the switch using Category 5, 5e, or 6 shielded or unshielded twisted-pair (UTP or STP) cable, maximum length 100 meters (328 ft). Switch 10/100/1000 will support up to 5/8 PCs.
  • Page 11: Cascading Switches

    Applications 100 Mbps 10 Mbps 100 Mbps 1000 Mbps 100 Mbps 10 Mbps Workstations Server 100 Mbps Workstation 1000 Mbps Workstation Standalone LAN 100 Mbps 100 Mbps Workstations Servers 1000 Mbps Workstation 10 Mbps 100 Mbps 1000 Mbps Segment Segment 100 Mbps Workstation Server...
  • Page 12: Product Specifications

    Indicator Panel Power Ports: Link/Act, 1000 Mbps Dimensions ES4005V: 13.0 x 8.56 x 31.9 cm (5.15 x 3.38 x 1.26 in.) ES4008V: 17.46 x 8.6 x 3.29 cm (6.9 x 3.4x 1.3 in.) Weight ES4005V: 275 g (0.606 lb) ES4008V: 375 g (0.827 ib)
  • Page 13: Troubleshooting

    Troubleshooting Diagnosing Switch Indicators Symptom Power LED does not light after power on. Probable Causes DC power adapter may be defective. Possible Solutions • Check for loose connections. • Check the power outlet by using it for another device. • Replace the DC power adapter. Symptom Port (link) LED does not light after connection is made.
  • Page 14: Cables

    Cables Cable Specifications Cable Types and Specifications Cable Type Max. Length Connector 10BASE-T Cat. 3, 4, 5 100-ohm UTP 100 m (328 ft) RJ-45 100BASE-TX Cat. 5 100-ohm UTP 100 m (328 ft) RJ-45 1000BASE-T Cat. 5, 5e, 6 100-ohm UTP 100 m (328 ft) RJ-45 Caution: DO NOT plug a phone jack connector into...
  • Page 15: 1000Base-T Pin Assignments

    1000BASE-T Pin Assignments The table below shows the 1000BASE-T MDI and MDI-X port pinouts. These ports require that all four pairs of wires be connected. Note that for 1000BASE-T operation, all four pairs of wires are used for both transmit and receive. Use 100-ohm Category 5 or 5e unshielded twisted-pair (UTP) or shielded twisted- pair (STP) cable for 1000BASE-T connections.
  • Page 16: Adjusting Existing Category 5 Cabling

    EMI Certification Adjusting Existing Category 5 Cabling If your existing Category 5 installation does not meet one of the test parameters for 1000BASE-T, there are basically three measures that can be applied to try to correct the problem: Replace any Category 5 patch cables with high-performance Category 5e cables.
  • Page 17: Ce Mark Declaration Of Conformance For Emi And Safety (Eec)

    CE Mark Declaration of Conformance for EMI and Safety (EEC) This information technology equipment complies with the requirements of the Council Directive 89/336/EEC on the Approximation of the laws of the Member States relating to Electromagnetic Compatibility and 73/23/EEC for electrical equipment used within certain voltage limits and the Amendment Directive 93/68/EEC.
  • Page 18: Safety Compliance

    Safety Compliance Safety Compliance Please read the following safety information carefully before installing the switch: Warning: Installation and removal of the unit must be carried out by qualified personnel only. Warning: Do not plug a phone jack connector in the RJ-45 port. This may damage this device.
  • Page 20 ES4005V ES4008V E032005-R01 150000017400H...
