ES4700 series
Chassis Core Routing
Switch
i
www.edge-core.com

Advertisement

Table of Contents
loading

Related Manuals for Edge-Core ES4704BD

Summary of Contents for Edge-Core ES4704BD

  • Page 1 ES4700 series Chassis Core Routing Switch www.edge-core.com...
  • Page 2 Preface ES4700BD series switch is a high performance routing switch released by Edge-Core that can be deployed as the core layer device for campus and enterprise networks, or as an aggregation device for IP metropolitan area networks (MAN). ES4700BD series switch provides 4 and 10 slots , with support for various types of line cards and can seamlessly support a variety of network interfaces from 100Mb, 1000Mb to 10Gb Ethernet.

  • Page 3: Japan Vcci Class A

    Compliances and Safety Warnings FCC - Class A This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Safety Compliance

    Caution: Do not plug a phone jack connector in the RJ-45 port. This may damage this device. Les raccordeurs ne sont pas utilisés pour le système téléphonique! Safety Compliance...

  • Page 5: Installing The Switch

    Please read the following safety information carefully before installing the switch: WARNING: Installation and removal of the unit must be carried out by qualified personnel only. • The unit must be connected to an earthed (grounded) outlet to comply with international safety standards.
  • Page 6 • Le coupleur d’appareil (le connecteur du groupe et non pas la prise murale) doit respecter une configuration qui permet un branchement sur une entrée d’appareil EN 60320/IEC 320. • La prise secteur doit se trouver à proximité de l’appareil et son accès doit être facile. Vous ne pouvez mettre l’appareil hors circuit qu’en débranchant son cordon électrique au niveau de cette prise.
  • Page 7 Stromkabel. Dies muss von dem Land, in dem es benutzt wird geprüft werden: Schweiz Dieser Stromstecker muß die SEV/ASE 1011Bestimmungen einhalten. Europe Das Netzkabel muß vom Typ HO3VVF3GO.75 (Mindestanforderung) sein und die Aufschrift <HAR> oder <BASEC> tragen. Der Netzstecker muß die Norm CEE 7/7 erfüllen (”SCHUKO”).
  • Page 8 viii...

  • Page 9: Table Of Contents

    1.4.7 Dust Gauze ..................... 39 1.4.8 Rear Panel ....................40 1.4.9 Side Panels..................... 42 1.5 System Features ................44 1.5.1 ES4704BD System Features ..............44 1.5.2 ES4710BD System Features ..............45 Chapter 2 Hardware Installation..........47 2.1 Basic Requirements ................48 2.1.1 Site Requirements ................. 48 2.1.2 Temperature and Humidity Requirements ...........
  • Page 10 2.3.5 SFP transceiver installation ..............65 2.3.6 XENPAK transceiver installation ............66 2.3.7 Copper Cable/Fiber Cable Connection ..........66 2.3.8 Power supply connection ..............67 Chapter 3 Caractéristiques du système ES4700BD ....69...

  • Page 11: Chapter 1 Product Overview

    Chapter 1 Product Overview RECOMMENDATION: Please read this manual first before using the switch, following the instructions to avoid damaging the device. 1.1 Product Brief Fig 1-1 ES4704BD Switch Fig 1-2 ES4710BD Switch...

  • Page 12: Introduction

    IP metropolitan area networks (MAN). ES4704BD provides 4 slots, 3 or 2 of which are interface module slots. ES4710BD provides 10 slots, 8 of which are interface module slots. ES4700BD supports various types of line cards, and can seamlessly support network interfaces from 100Mb, 1000Mb to 10Gb Ethernet.
  • Page 13 Support for 10G Ethernet 10Gb Ethernet (10GbE) is a leap of Ethernet in both speed and distance, in which full-duplex technology is employed, thus avoiding low-speed, half-duplex CSMA/CD protocol. Moreover, 10GbE maintains the essence of the original Ethernet model, therefore can integrate with the current Ethernet environment seamlessly. ES4700BD supports multi-port 10Gb fiber modules, providing wider bandwidth and more powerful processing capacity, therefore simplifying network structure and lowering network infrastructure cost.
  • Page 14 Console, Telnet and SNMP. Console and Telnet management provides simple and easy CLI (command line interface). SNMP management is V1 and V2C compliant, supporting Ether-Like MIB, Bridge MIB and MIB II, and RMON 1/2/3/9 MIB. With Edge-Core's ECview, full SNMP network management is available. Furthermore, ES4700BD provides...

  • Page 15: Main Features

    1.1.3 Main Features ES4704BD 4 slots that can be configured in Primary controller-Primary Backup mode with 2 management modules and 2 network modules, or Single controller mode with one management module and 3 network modules. ES4710BD 10 slots that can be configured in Primary controller-Primary Backup mode with 2 management modules and 8 network modules, or Single controller mode with one management module and 8 network modules.

  • Page 16: Physical Specifications

    ES4704BD: 30kg (max. full configuration weight) □ ES4710BD: 65kg (max. full configuration weight) □ Mean Time Before Failure Min. 80,000 Hours MTBF □ 1.4 Hardware Components ES4704BD consists of the chassis, power supply system, ventilation system, system board, etc. 1.4.1 Chassis...
  • Page 17 The function module block is a board rack, which is the supporting structure for ES4704BD system boards (4 boards max). The fan block is located on the left side of the board rack, allowing one fan tray (4 axial fans for each fan tray).
  • Page 18 The boards are inserted vertically into the ES4704BD 4 unit boards are provided. There are four slots in ES4704BD from number 1 to number 4 in order of top to down. The first slot is used to install management module; the second slot is used to management module under 1+1 redundant backup mode or install various I/O interface modules.
  • Page 19 The ES4704BD system board is an essential part of the switch, located inside the switch and providing interconnectivity between the management switch modules (short for management card) and network interface modules (line card), and for all management and control signals.
  • Page 20 Fig 1-5 ES4710BD Front Panel view ① Management slot: 2 management slots are provided. One or two management switching modules EM4710BD-AGENT can be inserted in to the Management slots. ② Network slot: 8 network slots are provided. Various network modules can be added to the network slots, such as EM4700BD-12GT-RJ45, EM4700BD-12GX-SFP,EM4700BD-2XG-XENPAK,etc.

  • Page 21: Introduction To Es4700Bd Cards

    The following twelve cards for the ES4700BD are currently available: Main control card（EM4704BD-M12GX-SFP） ： The central switching and controlling module for the ES4704BD, System status control, switch management, user access control and administration, and network operation maintenance are performed here. 12 Gigabit SFP ports are also provided.
  • Page 22 MDIX function. 1.4.2.1 EM4704BD-M12GX-SFP The EM4704BD-M12GX-SFP is switching module for the ES4704BD. System status control, switch management, user access control and administration, and network maintenances are performed here. The board can be inserted into first or second slots of...
  • Page 23 1.4.2.1.1 Front Panel The EM4704BD-M12GX-SFP provides 12 1000Base-SFP ports. At the same time, it comes with 1 Console port (control console) and 1 10/100Base-Tx Ethernet port (management port). The Front Panel view is shown below: Fig 1-6 EM4704BD-M12GX-SFP Front Panel View 1.4.2.1.2 Front Panel - Indicator The following table describes the front panel indicators of EM4704BD-M12GX-SFP: Table 1.1EM4704BD-M12GX-SFP indicators description...
  • Page 24 No network connection present transceiver Transmission Sending receiving Blinking (Green) Indicator data 1.4.2.1.3 Front Panel Port Description The EM4704BD-M12GX-SFP provides 12 SFP (Mini GBIC) Gigabyte fiber transceiver slots. The following SFP transceivers are supported by the EM4704BD-M12GX-SFP: ET4201-SX Gigabit SFP MM 850 nm, 500m (SX) ET4201-LX Gigabit SFP SM 1310 nm, 10Km (LX) ET4201-LHX...
  • Page 25 EM4704BD-M12GX-SFP provides a RESET button for resetting the board. 1.4.2.2 EM4704BD-M24TX4GC The EM4704BD-M24TX4GC is switching module for the ES4704BD. System status control, switch management, user access control and management, and network maintenances are performed here. The board can be inserted into first or second slots of the chassis for Master-Slave redundancy.
  • Page 26 On (Yellow, blink at 8 System is shutting down On (Red, blink at 8 Cards malfunction Cards are powered off and can be removed On (Green) Master Master-Slave indicator Slave Fan Assembly On (Green) Fan operating normally Status On (Red) Fan malfunctioning indicator: Fan not present (with Alarm...
  • Page 27 ET4201-LX Gigabit SFP SM 1310 nm, 10Km (LX) ET4201-LHX Gigabit SFP SM 1310 nm, 40Km (LHX) ET4201-ZX Gigabit SFP SM 1550 nm, 80Km (ZX) ET4201-RJ45 Gigabit SFP to Copper cable RJ45 1.4.2.2.4 Front Panel – Console Port The EM4704BD-M24TX4GC provides a RJ-45 (receptacle) Console serial port. Users can connect to hosts via this port to perform system debugging, configuration, maintenance, management and host software loading.
  • Page 28 1.4.2.3.1 Front Panel The EM4710BD-AGENT comes with 1 Console port (control console) and 1 10/100Base-Tx Ethernet port (management port). The Front Panel view is shown below: Fig 1-8 EM4710BD-AGENT Front Panel view 1.4.2.3.2 Front Panel - Indicator The following table describes the front panel indicators of EM4710BD-AGENT: Table 1.7 EM4710BD-AGENT indicators description Panel Symbol Status...
  • Page 29 Power supply module operating normally or not present (with OK off) On (Green) Fan operating normally Fan malfunctioning or not present Assembly (with Alarm off) Status On (Yellow) Fan malfunction indicator: Alarm Fan operating normally or not present (with OK off) 1.4.2.3.3 Front Panel –...
  • Page 30 1.4.2.4 EM4700BD-12GT-RJ45 12 copper GT ports line card (EM4700BD-12GT-RJ45): supports 12 1000Base-T copper ports for layer 2 and layer 3 switching and routing. 1.4.2.4.1 Front Panel EM4700BD-12GT-RJ45 provides RJ45 ports (10/100/1000Mbps adaptive).The Front Panel view is shown below: Fig 1-9 EM4700BD-12GT-RJ45 Front Panel view 1.4.2.4.2 Front Panel - Indicator The following table describes the EM4700BD-12GT-RJ45’s front panel indicators: Table 1.10 EM4700BD-12GT-RJ45 indicator descriptions...
  • Page 31 Transmissio Blinking (Green) Sending or receiving data n Indicator 1.4.2.4.3 Front Panel Port Description The EM4700BD-12GT-RJ45 provides 12 RJ45 copper GT ports. Table 1.11 EM4700BD-12GT-RJ45 port description Port Type Specification 10/100/1000 Mbps auto sensing RJ-45 port MDI/MDI-X cable ant sensing Cat 5 UTP: 100 m 1.4.2.4.4 Front Panel –...
  • Page 32 On (Green, blinks at 1 Cards operating normally On (Green, blinks at 8 System is loading Operation On (Yellow, blinks at 8 System is shutting down indicator On (Red, blinks at 8 Hz) Malfunction status Cards is powered off and can be removed SFP port indicator Network connection on SFP...
  • Page 33 Fig 1-11 EM4700BD-2XG-XENPAK front panel view 1.4.2.6.2 Front Panel - Indicator following table describes front panel indicators EM4700BD-2XG-XENPAK: Table 1.13 Description of the EM4700BD-2XG-XENPAK indicators Panel Status Description Indicator Symbol On (green) Card powered. Power Indicator Card powered off On (Green, blinks at 1 Hz) Card operating normally On (Green, blinks at 8 Hz) System is loading...
  • Page 34 1.4.2.6.4 Front Panel – Reset Button The EM4700BD-2XG-XENPAK provides a RESET button for resetting the board. 1.4.2.7 EM4700BD-8GC16GX and EM4700BD-8GC16GX2XG EM4700BD-8GC16GX line card :supporting 8 gigabit combo ports and 16 fiber GB ports for layer2 and layer3 switching and routing and IPv6 wire speed forward. EM4700BD-8GC16GX2XG line card: supporting dual 10G XFP ports, 8 gigabit combo ports and 16 fiber GB ports for layer2 and layer3 switching and routing and IPv6 wire speed forward.
  • Page 35 (Green Network Interface Card running in normal flash) status (Green System loading (Network Interface Card flash) Booting after hot plug in) Running (Yellow System shutting down Indicator flash) On (Red 8Hz flash) Running status is in failure Network Interface Card is off and can be pulled out RJ-45 Interface indicator RJ-45 Interface Network Connection is...
  • Page 36 ET4201-LHX Gigabit SFP SM 1310 nm, 40Km (LHX) ET4201-ZX Gigabit SFP SM 1550 nm, 80Km (ZX) ET4201-RJ45 Gigabit SFP to Copper cable RJ45 EM4700BD-8GC16GX2XG supports XFP transceivers of the following types: ET5302-LR XFP 10G Transceiver 10KM ET5302-ER XFP 10G Transceiver 40km ET5302-SR XFP 10G Transceiver 300M 1.4.2.7.4 Front Panel RESET Button...
  • Page 37 Network Interface Card power off (Green Network Interface Card flash) running in normal status (Green System loading (Network flash) Interface Card Booting after hot plug in) Running Indicator (Yellow System shutting down flash) On (Red 8Hz flash) Running status is in failure Network Interface Card is off and can be pulled out SFP Interface indicator...
  • Page 38 1.4.2.8.3 Front Panel Interface Description EM4700BD-24TX4GC provides twenty four 10/100M and four 1G COMBO. Where 1G optical electronic port, EM4700BD-24TX4GC supports SFP transceivers of the following types: ET4201-SX Gigabit SFP MM 850 nm, 500m (SX) ET4201-LX Gigabit SFP SM 1310 nm, 10Km (LX) ET4201-LHX Gigabit SFP SM 1310 nm, 40Km (LHX) ET4201-ZX...
  • Page 39 Fig 1-16 EM4700BD-12GT12GC2XG front panel view 1.4.2.9.2 Front Panel Indicator description front panel indicator EM4700BD-12GT12GC EM4700BD-12GT12GC2XG is as follows: Table 1.17 EM4700BD-12GT12GC and EM4700BD-12GT12GC2XG indicator description Panel Status Meanings Indicator Sign On (Green) Network Interface Card power on Power Indicator Network Interface Card power off (Green Network Interface Card running in normal...
  • Page 40 n Indicator 1.4.2.9.3 Front Panel Interface Description EM4700BD-12GT12GC and EM4700BD-12GT12GC2XG provide twelve SFP 1G optical fibre transceivers and twenty four RJ-45 1G electronic port slots. EM4700BD-12GT12GC2XG provides two XFP 10G optical ports. EM4700BD-12GT12GC and EM4700BD-12GT12GC2XG support SFP transceivers of the following types: ET4201-SX Gigabit SFP MM 850 nm, 500m (SX) ET4201-LX...
  • Page 41 RJ-45 Interface indicator RJ-45 Interface Network Connection is On (Green) Status normal Indicator There is not network connection at RJ-45 Shared interface Transmissio On (Yellow) Sending or receiving data n Indicator 1.4.2.10.3 Front Panel Interface Description EM4700BD-48GT provide 48-port 10/100/1000M RJ-45 electronic port. All kinds of interface description are as follows Table 1.19 EM4700BD-48GT interface description Interface Format...
  • Page 42 EM4700BD-48GX-SFP Table 1.20 the Instruction of Indicator Lamps of EM4700BD-48GX-SFP Panel State Explanation Indicator Sign SFP Interface Indicator Lamps The network connection of SFP interface is State On（green） normal. Indicator There is no network connection on SFP Lamp interface Transmissio n Indicator On（green）...

  • Page 43: Power Supply

    1.4.3 Power supply 1.4.3.1 EM4704BD-AC ES4704BD uses 1 +1 redundant power supplies. Each of them may serve as a standby power supply for another. Under normal operation conditions, the two power supply modules concurrently operate and each of them bears half of the loads. If one of...

  • Page 44: Power Module Front Panel

    1.4.3.1.1 EM4704BD-AC (Alternating Current Power Module) When powered by AC inputs, the AC power module EM4704BD-AC and corresponding AC distribution box should be used in the ES4704BD. The input voltage of the EM4704BD-AC is 90V/264 VAC, with ranges between 90 ~ 264 VAC and frequency between 50 ~ 60 Hz, the maximum output power is 400W.
  • Page 45 Label On Green Power Module Output Status is okay Output Output LED Good Power Module has no output On Yellow Faulty Power Module /Not turning-on Abort LED Fault The Output Switch Power Module Working Fine 1.4.3.1.4 Switch of power supply for front panel EM4704BD-AC provides a power supply for controlling the power output of control module.

  • Page 46: Power Distribution Box

    1.4.4 Power Distribution Box 1.4.4.1 ES4704BD Power Distribution Box There is a special A.C. distribution box on the backboard of ES4704BD switch. In generally, the enterprises users usually ask for the 90~264VAC access. The panel of A.C. distribution box is equipped with a 90~264VAC socket for provide power supply to the equipment.

  • Page 47: System Backplane

    Fig 1-23 ES4710BD AC Power Distribution Box 1.4.5 System Backplane The system board of ES4704BD series switch is located inside the switch, providing interconnectivity in the high speed data links between management switching modules, network interface modules and between all management and control signals of various cards.

  • Page 48: Fan Tray

    1.4.6 Fan Tray 1.4.6.1 ES4704BD Fan Tray Three fan assemblies (EM4704BD-FAN) can be configured in the ES4704BD, and installed in a horizontal configuration into the fan module slots in the switch’s upper front panel. The three fan assemblies cover the entire board area, ensuring sufficient ventilation for the devices, hence enhancing the stability of devices even under high temperature environments.

  • Page 49: Dust Gauze

    Fig 1-27 EM4704BD-FAN Front Panel View 1.4.7 Dust Gauze 1.4.7.1 ES4704BD Dust Gauze The ES4704BD’s dust gauze lies under the board rack and prevents large particles in the air from entering the switch. The dust gauze should be inserted from the front of the...

  • Page 50: Rear Panel

    ES4704BD in a horizontal position. Fig 1-28 EM4704BD Dust Gauze Outlook 1.4.7.2 ES4710BD Dust Gauze The ES4710BD’s dust gauze lies under the board rack and prevents large particles in the air from entering the switch. The dust gauze should be inserted from the front of the ES4710BD in a horizontal position.
  • Page 51 1.4.8.1 ES4704BD Rear Panel The rear panel of the ES4704BD covers the switch backplane. To ensure safe operation of the switch, please do not open the rear panel. There are two reversible handles on the rear panel, they are used only for the installation and removal of the rear panel.

  • Page 52: Side Panels

    FIG 1-31 ES4710BD Rear Panel View 1.4.9 Side Panels...
  • Page 53 There are several rows of ventilation openings in the left and right sides of the switch, as shown above. FIG 1-32 ES4704BD Side Panels View Please do not block the ventilation openings and ensure that enough clearance is left on both sides of the switch for air circulation. Failure to do so can cause the chassis to overheat and the system to fail, or damage to components.

  • Page 54: System Features

    Failure to do so can cause the chassis to overheat and the system to fail, or damage to components. 1.5 System Features 1.5.1 ES4704BD System Features The ES4704BD Switch system features are described in the table below.

  • Page 55: Es4710Bd System Features

    Table 1.23 ES4704BD System Features (1) SDRAM 128MB FLASH 32MB Port: Traffic, LINK Status indicator: General: Power status, system status, hot-swap indicator Weight 30KG (Max full configuration weight) Physical Dimensions 440mm x266mm x421mm (W x H x D) Relative humidity...
  • Page 56 Weight 65KG (Max full configuration weight) Physical Dimensions 436mm x 797mm x 478mm (W x H x D) Relative humidity 10% ~ 90% with no condensing Operating 0°C ~ 40°C Temperature Nominal Input Voltage Power Supplies AC: 90 ~ 264 VAC, 50 ~ 60Hz (supporting 2+1 redundant backup of power modules) Power Consumption ≤...

  • Page 57: Chapter 2 Hardware Installation

    Chapter 2 Hardware Installation During the installation and use of the ES4704BD Switch, please follow the safety guidelines listed below: Basic Guidelines Disconnect power supplies from the chassis before disassembly or moving the switch. Install the switch in a clean area, ensuring proper temperature and humidity conditions.

  • Page 58: Basic Requirements

    hazardous. Only trained and qualified personnel should be allowed to operate and maintain the device. Reading through the installation guidelines before powering on the system. Notice ! Watch out for potential dangers, e.g. wet floors, ungrounded power lines, and worn power lines.

  • Page 59: Temperature And Humidity Requirements

    Make sure the rack or workbench is well grounded; if the workbench is not grounded, it should be placed near a grounding conductor to provide easy ground connection for the switch. 2.1.2 Temperature and Humidity Requirements To maximize the switch’s performance and lifespan, the site should maintain a desirable temperature and humidity.

  • Page 60: Preventing Electrostatic Discharge Damage

    Max. Diameter (µm) Max. Density 1.4×10 7×10 2.4×10 1.3×10 (particles/m³) In addition, salt, acid and sulfide in the air are also harmful to the switch. Such harmful gases will aggravate metal corrosion and the aging of some parts. The chosen site should avoid harmful gases, such as SO S, NO , NH...

  • Page 61: Rack Configuration

    Provide electromagnetic shielding if necessary 2.1.6 Rack Configuration The dimensions of the ES4704BD are designed to be mounted on a standard 6’’ rack, the dimensions are 440mm x 266mm x 421mm (W x H x D). The dimensions of the ES4710BD are designed to be mounted on a standard 19’’...

  • Page 62: Preparing For Installation

    2.2.1 Checking Switch Hardware Configuration and Accessories After verifying site requirements, you can now unpack the shipping container to verify the switch configuration and contents of the accessory kit. A basic configuration ES4704BD should include the following: ITEM No. Part name Number...

  • Page 63: Required Tools And Utilities

    Multi-mode fiber cable Connection Single-mode fiber cable cables Category 5 cable with RJ-45 connector 2.3 Hardware Installation The installation of the ES4704BD includes the following: Switch mounting Desktop installation Rack-mounting the switch Switch grounding Cards and modules installation Connecting to the Console...

  • Page 64: Switch Installation

    ● Verify that the workbench is strong enough to support the ES4704BD’s fully configured weight ● Plan a good position for your ES4704BD that is easy to operate and has an appropriate power source and grounding point. ● Place the ES4704BD safely on the workbench, avoid obstructions on any side of the switch.
  • Page 65 Note that the hangers are not weight bearing. They are used to fasten the switch. The mounting Shelf or sliding rails (bolt to the rack) will support the switch. The figure below shows the steps for mounting the hangers: Fig 2-1 Installing ES4704BD Switch Hangers Fig 2-2 Installing ES4710BD Switch Hangers...
  • Page 66 Bolt the hangers to the matching holes in the rack column with the screws provided. Be sure to tighten the screws smoothly. The ES4700BD should now be securely attached to the equipment rack. The procedure is shown below: Fig 2-3 Rack-mounting ES4704BD...

  • Page 67: Wearing An Esd Wrist Strap

    Fig 2-4 Rack-mounting ES4710BD 2.3.1.3 Wearing an ESD Wrist Strap An ESD Wrist Strap must be worn during the installation of the switch. To prevent any damage occurring to the device, avoid contact between the printed circuit boards and your clothing.

  • Page 68: Card And Module Installation

    Lightning protection grounding The lightning protection system is an independent system consisting of a lightning rod, conductor and connection joint with the grounding system. The grounding system usually is shared with the power reference grounding and green and yellow ground cable grounding. Lightning protection grounding is a building requirement, not a specific requirement of the switch.

  • Page 69: Removing And Installing The Dust Gauze

    Insert the gauze back to its original position in the switch Tighten the panel fasteners. Note: The dust gauze is installed on switch chassis shipment. The installation and removal of the dust gauze is shown below: Fig 2-5 Installation and removal of the ES4704BD dust gauze...

  • Page 70: Removing And Installing The Fan Tray

    2.3.3.3.1 Removing and Installing the ES4704BD Fan Tray The ES4704BD has two fan trays in the left section of the switch, and can be serviced from the front. The installation and removal of the fan tray is relatively simple. To install, just hold the fan tray in the correct direction, align with the corresponding slot and push to secure.
  • Page 71 Fig 2-7 The installation and removal of ES4704BD fan tray 2.3.3.3.2 Removing and Installing the ES4710BD Fan Tray The ES4710BD has three fan trays in the upper section of the switch, and can be serviced from the front. The installation and removal of the fan tray is relatively simple. To install, just hold the fan tray in the correct direction, align with the corresponding slot and push to secure.

  • Page 72: Removing And Installing Power Supply Modules

    2.3.3.4.1 Removing and Installing ES4704BD Power Supply Modules The ES4704BD employs a 1 +1 redundant power supply module combination, all two modules will work during normal operation. In case one module fails, it can be replaced while the system is operating without presenting an electrical hazard or damage to the system.
  • Page 73 Installation of a power supply module is shown below: Fig 2-9 The installation and removal of ES4704BD power supply modules 2.3.3.4.2 Removing and Installing ES4710BD Power Supply Modules The ES4710BD employs a 2 +1 redundant power supply module combination, all three modules will work during normal operation.
  • Page 74 Fig 2-10 The installation and removal of ES4710BD power supply modules Clean power module dust gauze： Power module dust gauze is provided in the front panel of the EM4710BD-AC power modules, which can be removed and installed easily. It can prevent large debris or particles in the air from being ingested into the power supply module.

  • Page 75: Connecting To The Console

    2.3.4 Connecting to the console The ES4704BD provides a RJ-45 port as the local console. Users can configure the switch through a character terminal (usually a PC) with RS-232 ports. The connection procedures are listed below: Step 1: Find a character terminal or a PC with a RS-232 serial port.

  • Page 76: Xenpak Transceiver Installation

    The laser may hurt your eyes. 2.3.6 XENPAK transceiver installation In the ES4704BD, Each EM4700BD-2XG-XENPAK line card provides 2 XENPAK 10GB fiber transceiver slots. The procedure for installing the XENPAK 10GB fiber transceiver is shown below: Step 1: Put on an ESD wrist strap (or antistatic gloves) Step 2: Insert the XENPAK transceiver onto the guide rail inside the 10GB line card.

  • Page 77: Power Supply Connection

    The connection procedure for fibers are listed below: Step 1: Remove the protective dust plug from the SFP/XENPAK fiber transceiver bore; take out the fiber cable and remove the protective cap from one end of the fiber cable. Keep the fiber end clean and neat. Step 2: Immediately attach the end of the fiber cable to the SFP/XENPAK transceiver, and the other end to the transceiver of the corresponding device.
  • Page 78 If the Power OK indicator does not illuminate after repeating the above steps, please contact the dealer. Do not open the switch chassis by yourself. Please contact the dealer in the case of any failure.

  • Page 79: Chapter 3 Caractéristiques Du Système Es4700Bd

    Chapter 3 Caractéristiques du système ES4700BD Les caractéristiques du système de switch ES4704BD sont décrites dans le tableau ci-dessous. Caractéristiques du système ES4704BD(1) SDRAM 128MB FLASH 32MB Port: Trafic, LIEN Indicateur d'état: Général : Indicateurs d'état d'alimentation, d'état système, d'échange à chaud Poids 30KG (Poids maxi de la configuration complète)
  • Page 80 Configuration de 10 slots base Échange à chaud Conception Partie noyau redondante échangeable à chaud résistante à la panne Alimentations redondantes échangeables à chaud Pendant l'installation du switch ES4704BD, veuillez suivre les consignes de sécurité listées ci-dessous : Consignes de base...
  • Page 81 1. Débranchez les alimentations du châssis avant de démonter ou de déplacer le switch. 2. Installez le switch dans une zone propre, en vous assurant des bonnes conditions de température et d'humidité. 3. Conservez les accessoires du dispositif dans un lieu sûr. 4.
  • Page 82 lignes sous tension non reliées à la terre, et les lignes sous tension usagées. Faites installer un interrupteur d'urgence dans l'atelier, de sorte que l'alimentation puisse être coupée rapidement en cas d'accident. Ne travaillez pas seul si des dangers potentiels existent. En cas d'accident, prenez les mesures suivantes : Mettez le système hors tension 2.
  • Page 83 au niveau de l'entretoise d'isolation, rendant la vis de fixation lâche. De plus, dans des environnements secs, de l'électricité statique est susceptible de se créer et de causer des dégâts aux circuits internes. Des températures extrêmes peuvent causer une baisse de la fiabilité et un vieillissement prématuré des matériaux isolants, réduisant ainsi la durée de vie en fonctionnement du switch.
  • Page 84 4. Fournissez une protection électromagnétique si nécessaire Configuration rack Les dimensions de l’ES4704BD sont conçues pour être monté dans un rack standard de 6”, ces dimensions étant de 440mm x 266mm x 421mm (L x H x P). Les dimensions de l’ES4710BD sont conçues pour être monté dans un rack standard de 19”, ces dimensions étant de 436mm x 797mm x 478mm (L x H x P).
  • Page 85 Exigences relatives à l'alimentation L’ES4704BD est conçu pour utiliser des alimentations électriques à découpage modulaires, prenant en charge 1 + 1 secours redondant de modules d'alimentation. La spécification électrique en entrée est indiquée ci-dessous: Tension nominale d'entrée...
  • Page 86 Après avoir vérifié les exigences liées à l'emplacement, vous pouvez à présent déballer le carton d'expédition pour vérifier la configuration du switch et le contenu du kit d'accessoires. Une configuration de base de l’ES4704BD doit comprendre ce qui suit : ITEM N°. Nom de la pièce Numéro...
  • Page 87 Notez que les supports ne supportent aucun poids. Ils servent à fixer le switch. L'étagère de montage ou les rails coulissant (boulonnés sur le rack) supportent eux le switch. La figure ci-dessous montre les étapes de montage des supports : Installation des supports du switch ES4704BD...
  • Page 88 Installation des supports du switch ES4710BD Étape 2 : Mettez le switch monté sur supports doucement dans le rack standard de 6”. En raison de la taille et du poids d'un ES4700BD, 2 personnes sont nécessaires pour terminer l'installation. Une personne se tenant de chaque côté...
  • Page 89 Montage en rack du ES4704BD Montage en rack du ES4710BD Porter un bracelet antistatique Il faut porter un bracelet antistatique pendant l'installation du switch. Pour éviter tout dégât sur le dispositif, évitez tout contact entre les circuits imprimés et vos vêtements.
  • Page 90 Étape 2: Serrez le fermoir et assurez-vous qu'il soit en contact maximal avec la peau Étape 3: Insérez l'extrémité équipement du bracelet dans la prise antistatique (indiquée par un symbole ESD) sur le panneau avant du switch Mise à la masse du switch Un bon système de mise à...
  • Page 91 doit être inférieure à 1 ohm. Installation de la carte et du module L’ES4700BD est un dispositif de montage en rack, diverses cartes et modules sont disponibles. Configuration de base: châssis, modules d'alimentation électrique (optionnel 1 + 1 redondant), back plane du système, plateau du ventilateur, gaze à poussières, boîte de distribution.
  • Page 92 qui est en panne Étape 4: Serrez les fixations du panneau sur la face avant Étape 5: Un remplacement réussi est indiqué par un témoin vert Power OK allumé et par un témoin de panne jaune éteint. L'installation d'un module d'alimentation électrique décrite...
  • Page 93 Connexion à la console L’ES4704BD comprend un port RJ-45 comme console locale. L'utilisateur peut configurer le switch via un terminal texte (en général un PC) avec ports RS-232. Les procédures de connexion sont listées ci-dessous : Étape 1: Trouvez un terminal texte ou un PC avec un port série RS-232.
