Summary of Contents for Saunier Duval OPALIA X13
- Page 1 O P A L I A I N W A R R A N T Y T E C H N I C A L H E L P L I N E 01773 828400 01773 828100 THESE ARE CAT II + APPLIANCES...
-
Page 2: Table Of Contents
The identification plate located on the inside of the appliance certifies the origin where the product was manufactured and the country for which it is intended. If you see any exception to this rule, please contact your nearest Saunier Duval dealer. Thank you in advance for your assistance. -
Page 3: Dimensions
DIMENSIONS The water-heater in delivered in two separate packages : - the water-heater - the flue system Net weight : 24 kg Gross weight : 26 kg Accessories Various size spouts are available. Please contact your supplier. 5 , 5 3 9 0 HEATER SCHEMATIC Incoming air... -
Page 4: Technical Data
TECHNICAL DATA Refer to the data badge for exact type of appliance Gas Category : II 2H3+ and the gases it is suitable for. Natural (G 20) (ref. 15 ° C and 1013 mbar) Variable output of 8,7 kW (29665 Btu/h) Ø... -
Page 5: Flue Configurations
FLUE CONFIGURATIONS The flue must be fitted with a minimum slope of HORIZONTALE FLUE 35 mm per metre towards the terminal. Maximum flue index : 60 Pa. This value is reached when L exceeds 3 m (include elbow) slope of 35 mm per metre Important : remove the flue restrictor ring when (L) exceeds 1 m. -
Page 6: Installation
To comply with it, please order a new one quoting part number current standards, this connector must be made 59114 from an approved Saunier Duval dealer. through a double-pole switch with a contact separation of no less than 3 mm. -
Page 7: Commissioning & Lighting
(up to 60 °C for a minimal flow rate) Operating principles The OPALIA X13 water-heater operates with no per- manent pilot : - when a hot water tap is opened, the gas entering the burner is ignited by a spark train emitted by the In this position the least hottest ignition electrode. -
Page 8: Servicing / Maintenance
The technical maintenance of the appliance must Dismantle heat exchanger and fill with a 15 % be carried out by a Saunier Duval approved inhibited acid solution, specialist who will more particularly inspect the leave to act for 10 to 15 minutes then rinse... -
Page 9: Fault Finding
FAULT FINDING fault cause > remedy the water-heater will not run but no electrical supply > check there is 230 V AC : the safety indicator light is not lit at the supply at the appliance plug > then check : the connections to the ignition PCB the fuse on the PCB the thermistor connections the flow sensor connections... - Page 10 FAULT FINDING Diag. A : gas valve, ignition module, water flow Diag. E : gas valve modulator connections sensor Diag. F : temperature sensor connections Diag. B : connections to main PCB (behind control Diag. G : air pressure switch connections housing) Diag.
- Page 11 Ever anxious to improve the quality of its appliances Saunier Duval reserves the right to modify the latter without prior notice. The technical information contained in our documents are given for guidance only and are without liability.
