- Page 1 TORNADO ELECTRON MINI BOWSER PRESSURE WASHER OPERATOR MANUAL Clemas & Co. Unit 5 Ashchurch Business Centre, Alexandra Way, Tewkesbury, Gloucestershire, GL20 8NB. Tel: 01684 850777 Fax: 01684 850707 Email: info@clemas.co.uk Web: www.clemas.co.uk...
- Page 2 DEMON TORNADO MINI BOWSER RANGE Tornado P1 Mini Bowser Tornado P2 Mini Bowser Tornado P4 Mini Bowser Tornado D70 Mini Bowser Tornado Electron Mini Bowser Including electric start variants and bowser washers Declaration of Conformity (E.H.S.R.) We, Demon International Limited of Abbots Close, Lee Mill Industrial Estate,...
-
Page 3: Technical Specifications
Technical Specifications Tornado P1 Mini Bowser Tornado P4 Mini Bowser Engine Honda GX120 Engine Honda GX 340 11HP 360rpm Pump RSV 3G25D Pump AR RK 15.20H Pressure 1500 PSI Pressure 2900psi / 200Bar Flow 9lpm Flow 15 lp, / 3.3gpm... - Page 4 Kits for the Tornado Mini Bowser Machine Tornado D70 Tornado Electron Valve Kit 2186 1864 1828 1864 1864 Seal Kit 2189 1874 1857 1874 1874 Piston Kit 2629 2757 2629 2629 Oil Kit 2188 1872 1855 1872 1872 Support Ring Kit 1829 O Rings 2190...
-
Page 5: Fault Finder
FAULT FINDER FAULT CAUSE REMEDY Machine stops suddenly Low oil check and top up oil Or will not start. Flat Battery Re charge (Electron ) Sudden pressure loss. Water supply failed. Check water supply. No chemical Check chemical drum, close valve Low pressure HP nozzle worn or Replace HP nozzle. - Page 6 MINIMUM SERVICE SCHEDULES DAILY CHECK THE FOLLOWING Oil level top up as required. Fuel tank top up as required. All hose unions for leaks replace O rings if leaking. Hose condition cuts etc. EVERY 500 HOURS OR SIX MONTHS (WHICHEVER COMES FIRST) Drain and replace pump oil.
-
Page 7: Operating Instructions
OPERATING INSTRUCTIONS SAFETY Water at high pressure is dangerous and can cause serious injury. This machine is to be used with great caution. Petrol is extremely flammable and explosive under certain conditions. EXHAUST FUMES CONTAIN CARBON MONOXIDE – Inhalation of such fumes can KILL. Diesel is flammable and harmful if swallowed. - Page 8 Always ensure that there is a suitable type fire extinguisher available and is within easy access. DO NOT leave an engine running unattended, ALWAYS STOP it before leaving the area. NEVER point the high pressure spray jet at any person, animal, glass or other Material which may shatter.
- Page 9 PREPARATION Water Supply: Ensure there is an adequate water supply either from the mains or a reservoir. Attach water supply hoses to suitable tap or immerse the suction hose with approved suc tion filter into the reservoir. NOTE: ONLY CLEAN WATER SHOULD BE USED. THE PUMP MAY BE DAMAGED IF DIRTY OR CONTAMINATED WATER IS ALLOWED TO PASS THROUGH THE PUMP.
- Page 10 Adjust pressure regulator as required to obtain working pressure if required. NOTE;:The high pressure water will cause the gun to “kick”. Make sure you have a firm grip of gun and lance. On completion of operation stop the engine. Operate lance trigger Turn “...
- Page 13 Tornado Mini Bowser General Arrangement Tank Lid TOR0116 Suction Filter Lid Seals TOR01115 (Inside tank) Hose reel MTM20021 15 Mtr Hose HH00050MVG Pump to Hose Reel Hose HH00188 Braked Caster Wheel Wheel Wheel500 Wheel400 Engine P1 Honda GX120 P2 Honda GX200 Chemical Pick Up Pipe DEM10115 Pump...
- Page 14 Tornado Electron General Arrangement Lockable Emergency Stop DEM 100751 Battery Controller BAT013 Relay BAT015 Dual Voltage Charger BAT010...
-
Page 16: Warranty
WARRANTY This warranty covers the cost of all replacement parts and labour charges incurred, but does not cover the cost of transport or carriage. It is the owners responsibility to return the machine to a service depot or pay the travelling expenses of a engineer to attend. Demon Internationals decision in warranty matters is final and binding. -
Page 17: Warranty Procedure
Warranty Procedure End Users If your machine develops a problem: 1. Phone Demon for advice with the model and serial number to hand. 2. Describe fully the problem as best you can. 3. If the problem cannot be resolved over the phone then the machine can be booked in for repair and if the faults are covered by the warranty the repair will be carried out free of charge. - Page 26 1450 Code No Description Code No Description AR1322730 Screw AR1320020 Pump Head AR620301 Plug AR180101 O Ring AR1260162 Plug AR820361 Plug AR960160 O Ring AR1260200 Crankshaft AR1269050 Complete Valve AR1320260 Crankshaft AR880830 O Ring AR1380520 AR1320340 Support Ring AR1320370 Bearing AR1260220 Gasket AR1260750...
