- Page 1 STORM 1 MINI BOWSER PRESSURE WASHER OPERATOR MANUAL Clemas & Co. Unit 5 Ashchurch Business Centre, Alexandra Way, Tewkesbury, Gloucestershire, GL20 8NB. Tel: 01684 850777 Fax: 01684 850707 Email: info@clemas.co.uk Web: www.clemas.co.uk...
- Page 2 ARMM4B Unloader ARMM4B Pump Oil 10W/40 Pump Oil 10W/40 Gearbox Oil EP90 Gearbox EP90 Tornado Storm 1 Mini Bowser Pump XT11 14 Motor MTR00100 Pressure 1500 PSI / 100 Bar Motor output P1 2.2KW Flow Rate 11 lpm Motor input P2 3.0KW...
- Page 3 Kits for the Tornado Mini Bowser Range Machine D1ES Electron Storm 1 Valve Kit 2186 1864 1828 1864 1864 1864 Seal Kit 2189 1874 1857 1874 1874 1874 Piston Kit 2629 2757 2629 2629 2629 Oil Kit 2188 1872 1855...
-
Page 4: Fault Finder
FAULT FINDER FAULT CAUSE REMEDY Machine stops suddenly Low oil check and top up oil Or will not start. Flat Ba ery Re charge (Electron ) Sudden pressure loss. Water supply failed. Check water supply. No chemical Check chemical drum, close valve Low pressure HP nozzle worn or Replace HP nozzle. - Page 5 MINIMUM SERVICE SCHEDULES DAILY CHECK THE FOLLOWING Oil level top up as required. Fuel tank top up as required. All hose unions for leaks replace O rings if leaking. Hose condi on cuts etc. EVERY 500 HOURS OR SIX MONTHS (WHICHEVER COMES FIRST) Drain and replace pump oil.
- Page 6 OPERATING INSTRUCTIONS ENGINE DRIVEN SAFETY Water at high pressure is dangerous and can cause serious injury. This machine is to be used with great cau on. Petrol is extremely ßammable and explosive under certain condi ons. EXHAUST FUMES CONTAIN CARBON MONOXIDE – Inhala on of such fumes can KILL. Diesel is ßammable and harmful if swallowed.
- Page 7 Always ensure that there is a suitable type Þre ex nguisher available and is within easy access. DO NOT leave an engine running una ended, ALWAYS STOP it before leaving the area. NEVER point the high pressure spray jet at any person, animal, glass or other Material which may sha er.
- Page 8 PREPARATION Water Supply: Ensure there is an adequate water supply either from the mains or a reservoir. A ach water supply hoses to suitable tap or immerse the suc on hose with approved suc on Þlter into the reservoir. NOTE: ONLY CLEAN WATER SHOULD BE USED. THE PUMP MAY BE DAMAGED IF DIRTY OR CONTAMINATED WATER IS ALLOWED TO PASS THROUGH THE PUMP.
- Page 9 Adjust pressure regulator as required to obtain working pressure if required. NOTE;:The high pressure water will cause the gun to “kick”. Make sure you have a Þrm grip of gun and lance. On comple on of opera on stop the engine. Operate lance trigger Turn “...
-
Page 10: Operation
PREPARATION TORNADO STORM 1 Water Supply: Ensure there is an adequate water supply either from the mains or a reservoir. A ach water supply hoses to suitable tap or immerse end of hose into reservoir NOTE: ONLY CLEAN FILTERED WATER SHOULD BE USED Hoses: Attach the high pressure hose to the pump connection. - Page 11 OPERATING HINTS TORNADO STORM 1 During very cold weather it is most important to protect the machine against freezing. DO NOT operate machine should it become frozen. Move it to a warm area and allow to thaw naturally. Check all hoses and couplings for leaks, tighten where necessary.
- Page 12 OPERATING INSTRUCTIONS STORM 1 SAFETY A Residual Current Device (R.C.D.) Earth Leakage Trip must be used with this machine. Water at high pressure is dangerous and can cause serious injury. This machine is to be used with great caution. NEVER point the high pressure spray jet at any person, animal, glass or any other material which may shatter.
- Page 16 Tornado Mini Bowser General Arrangement Tank Lid TOR0116 Lid Seals TOR01115 Hose reel MTM20021 15 Mtr Hose HH00050MVGHR Pump to Hose Reel Hose HH00188 Braked Caster Wheel Wheel Wheel500 Wheel400 Engine P1 Honda GX120 P2 Honda GX200 Chemical Pick Up Pipe DEM10115 Pump Unloader Valve...
- Page 17 Demon Storm 1 Cold Water Range—General Arrangement Cover DEM20181 Inlet Fi ngs DEM20441 3/8 X 1/2” Hose tail MTM0012FF03 Brass elbow 1/2FF...
- Page 18 Demon Storm 1—Easy Start Valve Gauge DEM20621 Easy Start Valve MTM39001 Easy start to water inlet pipe DEM10321...
- Page 19 Tornado Electron General Arrangement Lockable Emergency Stop DEM 100751 Battery Controller BAT013 Relay BAT015 Dual Voltage Charger BAT010...
- Page 23 Company/marke ng/lance chart issue 3 06/10...
- Page 25 COLD WATER LANCES Part No Descrip on N26001/1504 Nozzle P1 N26001/15045 Nozzle P2 N26001/1505 Nozzle P4 & D1ES MTM90040 Adjustable Nozzle DEM10031B QR Lamce P2 DEM10031Y QR Lance P1 DEM10031R QR Lance P4 & D1ES DEM10030 QR Trigger MTM70012 MVG Coupling...
- Page 26 Hose Insert MV00490 (items 1 & 2) High Pressure Hose HH00030MVG Hose Joiner MV00500 Alterna ve Hose Lengths 15 Metre HH00050MVG 30 Metre HH00100MVG...
- Page 30 1450 Code No Descrip on Code No Descrip on AR1322730 Screw AR1320020 Pump Head AR620301 Plug AR180101 O Ring AR1260162 Plug AR820361 Plug AR960160 O Ring AR1260200 Cranksha AR1269050 Complete Valve AR1320260 Cranksha AR880830 O Ring AR1380520 AR1320340 Support Ring AR1320370 Bearing AR1260220...
