Internal
SCSI connector #2
Internal
SCSI connector #1
PCI UltraSCSI Host Adapter Card
FIGURE 1-1
Note – A single-ended host adapter is shown in
variations in components between the single-ended and differential host adapters.
To Install the Host Adapter
1. Open the system.
Refer to your system documentation for information about filler panels for your
system.
2. Attach the wrist strap between your wrist and a metal part of the system chassis.
3. For systems with a standby-type power switch, disconnect the power cord.
Standby-type power switches have a
The wrist strap between you and the chassis provides the ground path necessary to
safely remove and install the printed circuit boards and components without
damaging them.
4. Remove the filler panel for the desired slot.
Refer to your system documentation for information about filler panels for your
system.
5. Remove the host adapter from its protective bag.
PCI connector
VHDCI connector #1
. There are slight
FIGURE 1-1
icon.
Chapter 1
Installing the Host Adapter
VHDCI connector #2
3
