■ User set mode

User set mode is accessed at power ON and allows you to
set seldom-changed settings. You can "customize" the trans-
ceiver operation to suit your preferences and operating style.
Entering the user set mode:
q While pushing and holding [P1] and [P2], rotate [VOL] to
turn the power ON.
• Turn power OFF in advance.
• "SET MODE" appears for 1 sec at power ON.
w Push and hold [P0] to enter user set mode.
e Push [P0] several times to select the appropriate item.
Then push [Side2] or [Side3] to set the desired level/condi-
tion.
• Available set mode functions are Backlight, LCD contrast,
Beep, Beep Level, Ringer Level, SQL Level, AF Min Level,
Mic Gain, VOX Gain*, VOX Delay*, Battery Voltage, Signal
Moni, Lone Worker and System Info.
* Appears only when the external VOX unit is connected.
r Push and hold [P0] again to exit set mode.
User set mode is also available using a programmable key.
Please refer to p. 10 [User Set Mode] section for instructions
regarding using the key assigned for user set mode.
[User Set Mode] allows for the quick item selection. Set "En-
able" for the often used items in the CS-F3160/F5060
. Ask your dealer for details.
ing software
NOTE: [Side2] or [Side3] and [P0] activate while in the
user set mode regardless of the assigned key functions.

■ Scrambler function

The voice scrambler function provides private communication
between stations. All versions have a built-in frequency inver-
sion type scrambler; however, an optional rolling or non-roll-
ing type is available as well.
➥ Push [Scrambler] to toggle the scrambler function ON or
OFF.
• " " (Scrambler indicator) appears when the function is ON.

■ Stun function

When the specified ID, set as a stun ID or kill ID, is received,
the stun function is activated.
When the stun ID is received, the transceiver becomes unus-
able. Entering of the password (p. 11) or receiving a specified
ID, set as a revive ID, is necessary to operate the transceiver
again in this case.
When the kill ID is received, the transceiver switches to the
cloning required condition. Cloning the transceiver is neces-
sary to operate the transceiver again in this case.
-
clon
