Options - Icom IC-iF3161 Instruction Manual

D BATTERY PACKS
Battery pack Voltage
950 mAh (min.)
BP-230N
7.4 V
980 mAh (typ.)
1900 mAh (min.)
BP-232N 7.4 V
2000 mAh (typ.)
Battery case for AAA
BP-240
(LR03) × 6 alkaline
* 1 When the power save function is turned ON, and the operating
periods are calculated under the following conditions;
TX : RX : standby = 5 : 5 : 90
* 2 Operating period depends on the alkaline cells used.
D CHARGERS
• BC-119N
desktop charger
+ BC-145S
ac adapter
For rapid charging of battery pack. An AC adapter is sup-
plied with the charger depending on versions.
Charging time: Approx. 3 hours when BP-232N is attached.
• BC-121N - + AD-106
multi charger
+ BC-157S
ac adapter
For rapid charging of up to 6 battery packs (six AD-106s
are required) simultaneously. An AC adapter should be pur-
chased separately.
Charging time: Approx. 3 hours when BP-232N is attached.
Capacity Battery life* 1
7.35 hrs.
14 hrs.
2
—*
+ AD-106
charger adapter
(6 pcs.)
charger adapter

OPTIONS

• BC-160
desktop charger
For rapid charging of battery pack. An AC adapter is sup-
plied with the charger depending on versions.
Charging time: Approx. 3 hours when BP-232N is attached.
• BC-171
desktop charger
For regular charging of battery packs. We recommend that
the BP-230N charging. An AC adapter is supplied with the
charger depending on versions.
Charging time: Approx. 10 hours when BP-232N is attached.
Approx. 4 hours when BP-230N is attached.
D BELT CLIPS
• MB-93
swivel belt clip
• MB-94
belt clip
Exclusive alligator-type belt clip.
• MB-96N/96F
leather belt hanger
D OPTIONAL UNITS
• UT-96R 2/5
tone unit
• UT-109R /UT-110R
scrambler units
Non-rolling type (UT-109R)/Rolling type (UT-110R) voice
scrambler unit provides higher communication security.
• UT-126H
digital modulator
Provides 6.25 kHz digital mode operation.
• UT-124R
man down unit
Provides a measure of safety when working in a hazardous
environment, etc.
8
+ BC-145S
ac adapter
+ BC-147S
ac adapter
/
demodulator unit
