Summary of Contents for Vinotemp VT-16TEDS
- Page 1 A P R O U D H E R I T A G E O F E X P E R I E N C E & Q U A L I T Y W I N E C E L L A R V T - 1 6 T E D S ( 1 6 b o t t l e ) O W N E R ’...
- Page 2 Y o u r W i n e C e l l a r This unit can be used for Storage and/or Service. The unit has a glass door and soft interior light to elegantly display your wine. S e r v i n g W i n e s Storing wines at the proper temperature is important.
- Page 3 Upon receipt and inspection of unit, the supply cord must be replaced if it is damaged. Contact our customer service at 1-800-777-8466 or info@vinotemp.com. READ ALL INSTRUCTIONS BEFORE USING THIS WINE COOLER...
-
Page 4: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ..........5 ELECTRICAL CONNECTION ............5 CABINET DIAGRAM ..............6 CIRCUIT DIAGRAM..............6 TECHNICAL DATA ............... 7 INSTALLATION INSTRUCTIONS............. 8 OPERATING YOUR WINE CELLAR ..........8 CARE AND MAINTENANCE ............8 TROUBLESHOOTING ..............10 TERMS OF SALE AND WARRANTY ..........11 SERVICE &... -
Page 5: Important Safety Instructions
WARNING: Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is damaged, please contact Vinotemp Customer Service at 1-800-777-8466 or info@vinotemp.com. For your protection, this unit is equipped with a 3-... -
Page 6: Cabinet Diagram
CABINET DIAGRAM Hinge Cover Temperature Control Buttons Light Light Switch Button Fan Cover Magnetic Seal Shelf Glass Foot Door Handle Water Box Door Frame CIRCUIT DIAGRAM... -
Page 7: Technical Data
TECHNICAL DATA Model No. VT-16TEDS Capacity 46L / 16 Bottles Voltage 110V Current 1A (@59°F) Protection Class Frequency 60Hz Climate Class SN;N Input Power Power Consumption 1 (@59°F) kW · h/24h Temperature Range 54-66°F Approx. Net Weight 34.1 Lbs Approx. Gross Weight 38 Lbs Approx. -
Page 8: Installation Instructions
INSTALLATION INSTRUCTIONS Before Using Your Wine Cellar: • Remove any exterior and interior packing material. • Check to be sure the following parts are included: For 16 Bottle Wine Cellar, 3 slide out shelves. 1 instruction manual. • Before connecting the appliance to the power source, let it stand upright for approximately 2 hours. -
Page 9: Care And Maintenance
CARE AND MAINTENANCE Cleaning Your Wine Cellar • Unplug the wine cellar and remove the bottles. • Wash the inside with a warm water and baking soda solution. The solution should be about 2 tablespoons of baking soda to a quart of water. •... -
Page 10: Troubleshooting
TROUBLESHOOTING You can solve many common wine cellar problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before contacting Vinotemp at info@vinotemp.com. SYMPTOM POSSIBLE CAUSE Door will not close •... -
Page 11: Terms Of Sale And Warranty
Any claim for damages incurred during shipment by the carrier of the goods are insured and handled directly with the carrier and must be noted at time of delivery. Any damages due to manufacture defects will be handled directly with Vinotemp International, subject to the limited warranty. -
Page 12: Service & Important Notice
17621 S. Susana Road Rancho Dominguez, CA 90221 Vinotemp is a registered trademark of Vinotemp International. All products, features, and services are subject to change without notice. We cannot guarantee the accuracy of the contents of this document. We disclaim liability for errors, omissions, or future changes.
