- Page 1 A P R O U D H E R I T A G E O F E X P E R I E N C E & Q U A L I T Y D u a l - Z o n e W i n e C O O L E R V T - 1 5 5 S B W ( a p p r o x 1 5 5 b o t t l e s ) O W N E R ’...
- Page 2 Y o u r W i n e C e l l a r This unit can be used for Storage and/or Service. The unit has a glass door and soft interior light that you can use to display your wine. S e r v i n g W i n e s Storing wines at the proper temperature is important.
- Page 3 Upon receipt and inspection of unit, the supply cord must be replaced if it is damaged. Contact our customer service at 1-800-777-8466 or info@vinotemp.com. READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE...
-
Page 4: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ..........5 ELECTRICAL CONNECTION ............6 PARTS AND SPECIFICATIONS ............7 INSTALLATION ................8 OPERATING YOUR WINE COOLER..........10 CARE AND MAINTENANCE ............12 TROUBLESHOOTING..............13 TERMS OF SALE AND WARRANTY ..........14 W W W . V I N O T E M P . C O M... -
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of fire, electrical shock or injury when using your appliance, follow these basic precautions: • Do not operate this or any other appliance with a damaged cord. • Do not operate if housing is removed or damaged. •... -
Page 6: Electrical Connection
ELECTRICAL CONNECTION Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is damaged, frayed or shows cracks or abrasions across its length, have it replaced at an authorized service center. For your protection, this unit is equipped with a 3-conductor cord set that has a molded 3-prong grounding- type plug, and should be used in combination with a properly connected grounding-type outlet. -
Page 7: Parts And Specifications
PARTS AND SPECIFICATIONS Model No. VT-155SBW Voltage AC 115/120V Frequency 60 Hz Ambient Temperature Range 60°- 90°C Control Temperature Range 40°- 72°F Refrigerant R134a/3.88oz Power Consumption 1.4 kWh/24h Input Power 160W Volume 428L Net Weight 230 lbs Gross Weight 255 lbs Dimensions (W x D x H) 23.5"... -
Page 8: Installation
INSTALLATION • Remove all packing material before using your wine cooler. • IMPORTANT: Before connecting the unit to a power source, let it stand upright for approximately 24 hours. This will reduce the possibility of a malfunction in the cooling system from handling during transportation. -
Page 9: Installing Stainless Steel Handle
Lower Door Hinge Lock Screws Door Shaft Assembly Hinge Cover Screws Upper Door Hinge INSTALLING STAINLESS STEEL HANDLE This wine cellar includes a stainless steel handle that is not required to operate this unit. To install the handle please follow the below instructions: •... -
Page 10: Operating Your Wine Cooler
OPERATING YOUR WINE COOLER CONTROLS Power To turn the appliance ON or OFF, touch the at the same time for 5 seconds. Set or view the internal temperature setting for each zone. Light Turn the inner light ON or OFF. Raise the set temperature by 1°C or 1°F. -
Page 11: Door Lock
• When you touch SET again, the right LED indicator for LOWER ZONE will flash. Then proceed to touch the UP or DOWN to set the desired temperature for the LOWER ZONE. • The temperature will increase by 1°C or 1ºF if you touch UP once, or the temperature will decrease by 1°C or 1ºF if you touch DOWN once. -
Page 12: Care And Maintenance
DEFROSTING The wine cooler defrosts automatically. The evaporator behind the rear wall of the unit automatically defrosts and the condensate collects in the drainage channel behind the rear wall of the unit, and flows through the drainage hole into the drip tray by the compressor, where it evaporates. CARE AND MAINTENANCE CLEANING YOUR WINE COOLER IMPORTANT: Always unplug the unit before cleaning or performing maintenance. -
Page 13: Troubleshooting
PROBLEMS WITH YOUR WINE COOLER Most common problems can be solved easily, saving you the cost of a possible service call. Try the following suggestions to see if you can solve the problem before contacting Vinotemp at info@vinotemp.com. TROUBLESHOOTING PROBLEM POSSIBLE CAUSE •... -
Page 14: Terms Of Sale And Warranty
TERMS OF SALE AND WARRANTY Vinotemp International (“Seller”) and the person or entity that acquires these goods from Seller (“Purchaser”) hereby fully agree to the following terms and conditions of the sale: Shipping fees are the responsibility of the Purchaser whether freight prepaid or freight collect. - Page 15 1 7 6 2 1 S o u t h S u s a n a R o a d , R a n c h o D o m i n g u e z , C a l i f o r n i a 9 0 2 2 1 i n f o @ v i n o t e m p .
- Page 16 Rancho Dominguez, CA 90221 www.vinotemp.com Vinotemp is a registered trademark of Vinotemp International. All products, features, and services are subject to change without notice. We cannot guarantee the accuracy of the contents of this document. We disclaim liability for errors, omissions, or future changes.
