Summary of Contents for Momentum VS-1
- Page 1 ENGLISH VS-1 Chronograph (Series v2) Instructions & 2/4/6 YEAR Warranty Information VS-1 CHRONOGRAPH v2.0 INSTRUCTIONS © COPYRIGHT ST. MORITZ WATCH CORP. 2008...
- Page 2 We use the finest Swiss sensors to create the most accurate and dependable products possible. The VS-1 unit features an altimeter/barometer/weather station along with a full selection of advanced watch and chronograph functions. The VS-1 also features a highly accurate digital compass.
- Page 3 ENGLISH INTRODUCTION The Momentum® VS-1 is a digital product that provides Altimeter, Barometer, Compass, Altimeter Log Data, Ski, Sail (CountdownTimer), Dual Time, Chronograph And Alarm Functions. Features: Altimeter - 1 meter (or foot) resolution and with working range from -700 meters (-2296 feet) to 9000 meters (29520 feet).
- Page 4 -TO STOP SCROLLING - TURN ON BACK LIGHT (S2) -SELECT VIEWS OR DISPLAY OPTION -REVERSE (DECREASE) SETTING -STOP/RESET -SELECT AL1/AL2/CHIME (S1) -START/STOP -REACTIVATE COMPASS FUNCTION -ALARM ON/OFF -FORWARD (INCREASE) SETTING VS-1 CHRONOGRAPH v2.0 INSTRUCTIONS © COPYRIGHT ST. MORITZ WATCH CORP. 2008...
- Page 5 NORMAL TIME (T1) DUAL TIME (T2) COMPASS BAROMETER ALTIMETER LOG DATA CHRONOGRAPH SAIL ALARM ***Press and hold S3 (approx 3-4 seconds) in any mode to return to Normal Time mode. VS-1 CHRONOGRAPH v2.0 INSTRUCTIONS © COPYRIGHT ST. MORITZ WATCH CORP. 2008...
-
Page 6: Time Mode
4. Press S4 to exit setting mode and save setting data 5. If there is no key operation for 2-3 minutes, the watch will auto exit the setting mode and return to normal mode. VS-1 CHRONOGRAPH v2.0 INSTRUCTIONS © COPYRIGHT ST. MORITZ WATCH CORP. 2008... -
Page 7: Compass Mode
CALIBRATING THE COMPASS The COMPASS of the VS-1 must be calibrated on a regular basis. The compass should be calibrated any time it does not seem to be working properly. We recommend calibrating the compass prior to any activity where optimal accuracy is desired, such as a long back country trip. - Page 8 - When you take bearings, readings are shown in 16 cardinal indications together with bearing in degrees. * The bearing shown in degrees in the center of the display indicates the direction that the VS-1’s 12 o’clock position is pointing to.
-
Page 9: Barometer Mode
1. Use S2 to switch to the barometer display with Sea level and actual pressure. 2. Hold down S1 until the “unit” indicator (mbar/hPa or in Hg) stops flashing, to switch readout between mbar/hPa and in Hg. VS-1 CHRONOGRAPH v2.0 INSTRUCTIONS © COPYRIGHT ST. MORITZ WATCH CORP. 2008... - Page 10 3. Press S4 to exit the setting screen. * If there is no button operation for 2-3 minutes at setting screen, the display will return to the Barometer mode automatically. VS-1 CHRONOGRAPH v2.0 INSTRUCTIONS © COPYRIGHT ST. MORITZ WATCH CORP. 2008...
-
Page 11: Altimeter Mode
* The graph is not intended to give an exact altitude: it provides an overview of the trend of change in altitude. To switch between meters and feet Press and hold down S1 until the unit indicator (M or Ft) stops flashing to switch altitude between meters and feet. VS-1 CHRONOGRAPH v2.0 INSTRUCTIONS © COPYRIGHT ST. MORITZ WATCH CORP. 2008... - Page 12 If you wish to erase all recorded LOG data, continue to press and hold S4 after the selected LOG Data is erased, then the words CLR ALL, HOLD will begin to flash. Continue pressing S4, then all recorded log data will be erased/ deleted, and the display will show “----”. VS-1 CHRONOGRAPH v2.0 INSTRUCTIONS © COPYRIGHT ST. MORITZ WATCH CORP. 2008...
-
Page 13: Ski Mode
ENGLISH SKI MODE The VS-1 is equipped with an automatic timer for timing ski runs. Press S3 to select SKI mode * Mode prompt “SKI” is displayed briefly. - Press S1 to start 10 seconds auto count down, then start skiing when countdown reaches 00:00. Timing starts. -
Page 14: Chronograph Mode
CHRONOGRAPH MODE The VS-1 includes a highly accurate chronograph (stopwatch) function, capable of recording up to 100 split/lap times. It can time events up to 23 hours, 59 minutes and 59 seconds. It can be used to time simple single events, show intermediate (split) times, or show two or more finishing times. - Page 15 1. Ensure countdown is stopped. Press S2 once to reset to previously set base countdown time. If desired, press S2 repeatedly to set a new base countdown time. (With each press of the S2 button, VS-1 will cycle down from 120:00”00 minutes to 60:00”00 minutes in 10:00 minute increments;...
-
Page 16: Alarm Mode
** NOTE: when Chime is turned on, watch will beep briefly, every hour on the hour. Also note that, when Chime is turned on, ALL BUTTONS WILL GIVE A BRIEF BEEP TO CONFIRM WHEN PRESSED. To stop buttons beeping, turn Chime off. VS-1 CHRONOGRAPH v2.0 INSTRUCTIONS © COPYRIGHT ST. MORITZ WATCH CORP. 2008... -
Page 17: All-Reset Function
BATTERY REPLACEMENT This new series VS-1 watch is equipped with a user-friendly battery hatch, which allows you to change the battery yourself, should you not have time to send it in to one of our authorized Service Centers for service. If you decide to do the battery change yourself, take special care when removing the battery hatch, then, after battery replacement, screw the back on firmly, taking special care not to cross-thread or damage the o-ring, as this ensures the ongoing, reliable water-resistance of your watch. -
Page 18: Two Year Warranty
Nobody knows your watch like we do! Expert technicians, original parts and the latest equipment will ensure that your watch is serviced right. RETURNING YOUR WATCH FOR SERVICE OR MAINTENANCE: If your watch requires service, please return it to the nearest St. Moritz / Momentum Service Center. The most current Service addresses are available on our website at http://www.st-moritz.com/pages/servicelocations.php. http://www.st-moritz.com/pages/serviceinformation.php A service return form is also available on our website at .
