- Page 1 VS-1 Chronograph Instructions & 2/4/6 YEAR Extendible Warranty. VS-1 CHRONOGRAPH INSTRUCTIONS © COPYRIGHT ST. MORITZ WATCH CORP. 2006...
- Page 2 We use the finest Swiss sensors to create the most accurate and dependable products possible. The VS-1 unit features an altimeter/barometer/weather station along with a full selection of advanced watch and chronograph functions. The VS-1also features a highly accurate digital compass.
- Page 3 Variables in a programming sequence are adjusted up using a QUICK PRESS of the A key and down using a QUICK PRESS of the B key. * In many programming modes, a PRESS & HOLD of either A or B will cause the variable to fast advance, allowing quicker setting. VS-1 CHRONOGRAPH INSTRUCTIONS © COPYRIGHT ST. MORITZ WATCH CORP. 2006...
- Page 4 - Enter (PRESS & HOLD) or Exit (PRESS) setting or calibration mode - Clear data in Chronograph or Altimeter Memory (PRESS & HOLD) - Exit (set or calibration) EL BACKLIGHT Press D for EL Backlight (with 3 seconds auto light-up) VS-1 CHRONOGRAPH INSTRUCTIONS © COPYRIGHT ST. MORITZ WATCH CORP. 2006...
- Page 5 NORMAL TIME View/switch T1-T2 COMPASS BAROMETER ALTIMETER ALTIMETER DATA SKI CHRONO (SPORT) CHRONOGRAPH CHRONOGRAPH DATA ALARM * In any mode, PRESS and HOLD C to change directly to Time mode. VS-1 CHRONOGRAPH INSTRUCTIONS © COPYRIGHT ST. MORITZ WATCH CORP. 2006...
-
Page 6: Time Mode
4. Press D to exit the setting screen and day of the week will be adjusted automatically. NOTE: If no button is pressed for 2-3 minutes, the display will return to Time mode automatically. VS-1 CHRONOGRAPH INSTRUCTIONS © COPYRIGHT ST. MORITZ WATCH CORP. 2006... -
Page 7: Compass Mode
CALIBRATING THE COMPASS The COMPASS of the VS-1 must be calibrated on a regular basis. The compass should be calibrated any time it does not seem to be working properly. We recommend calibrating the compass prior to any activity where optimal accuracy is desired, such as a long back country trip. -
Page 8: Reactivating Compass
- When you take bearings, readings are shown in 16 cardinal indications together with bearing in degrees. * The bearing shown in degrees in the center of the display indicates the direction that the VS-1’s 12 o’clock position is pointing to. - Page 9 BAROMETER The VS-1 is equipped with a highly sensitive barometer/weather station. The BAROMETER measures the Absolute Barometric Pressure and calculates the Barometric Pressure corrected to Mean Sea Level (MSL). Barometric pressure may be displayed in either Inches of Mercury (inHg) or Millibar/HectoPascals (mbar/hPa).
- Page 10 PRESS & HOLD B until the unit indicator (°F or °C) stops flashing, to switch temperature between °F and °C. NOTE: The TEMPERATURE or BAROMETRIC PRESSURE units chosen while in the BAROMETER mode will be the units displayed in the TIME OF DAY and ALTIMETER modes. VS-1 CHRONOGRAPH INSTRUCTIONS © COPYRIGHT ST. MORITZ WATCH CORP. 2006...
- Page 11 BARO BARO BARO 3. QUICK PRESS D to exit the setting screen. * If there is no button operation for 2-3 minutes, the display will automatically return to Barometer mode. VS-1 CHRONOGRAPH INSTRUCTIONS © COPYRIGHT ST. MORITZ WATCH CORP. 2006...
-
Page 12: Altimeter Mode
- A graph showing the changes in altitude is provided. * Graph will be cleared only after battery replacement or reset. - User can store altitude data in the VS-1 memory. (Maximum 20 sets of data) Reading the altitude graph The altitude graph shows the relative changes in altitude in the past with the current altitude represented on the right. -
Page 13: Altimeter Calibration
2. QUICK PRESS A (+) or B (-) to change the setting. PRESS & HOLD either button for high speed setting. 3. If you do not wish to reset the accumulated or maximum altitude data from the VS-1 memory, QUICK PRESS D to exit the Altimeter calibration mode, or….. -
Page 14: Chronograph Mode
WHAT ARE LAPS AND SPLITS The VS-1 Chronograph displays both LAP (sequential) and SPLIT (cumulative) times on screen. .A LAP is a discrete period of time from when the CHRONOGRAPH has started (Lap 1), or since the end of a previous lap. A SPLIT is the cumulative total of all previous LAPS. Any time an individual lap is timed, it also automatically generates a corresponding split. - Page 15 2. QUICK PRESS A to scroll through log of all Laps/Splits for the selected run. 3. Display will scroll through LAP/SPLIT times in the LOG, starting with the most recent LAP/SPLIT. After LAP 1, the VS-1 will scroll to show the BEST (fastest) LAP/SPLIT time, then the AVERAGE (calculated) LAP/SPLIT time.
- Page 16 SKI CHRONOGRAPH (“SPORT”) MODE The VS-1 is equipped with a timer system which is started at the top of a run and will track the time of your ski runs back to the base, stopping at a preset base altitude.
- Page 17 CHIME ON/OFF **NOTE: If the CHIME is turned ON, in either the AL-1 or AL-2 Alarm setting sequence, the VS-1 will give a double beep at the start of each hour. **IMPORTANT: Turning the CHIME on (in either the AL-1 or AL-2 Alarm setting sequence) also switches on the ACOUSTIC BUTTON (Button Chime) feature.
- Page 18 To return your watch, please print and fill out the form, or complete the details on the enclosed card and include it with the watch: please do not send the giftbox. Questions? 1-800-663-1881 (Weekdays, 9am-5pm Pacific Time) Email: watches@st-moritz.com website: www.st-moritz.com VS-1 CHRONOGRAPH INSTRUCTIONS © COPYRIGHT ST. MORITZ WATCH CORP. 2006...
