Symbol LS4278
Quick Reference Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LS4278 and is the answer not in the manual?

Questions and answers

Related Manuals for Symbol LS4278

Summary of Contents for Symbol LS4278

  • Page 1 Symbol LS4278 Quick Reference Guide...

  • Page 2: Warranty

    An implied license exists only for equipment, circuits, and subsystems contained in Motorola products. MOTOROLA, the Stylized M Logo and Symbol and the Symbol logo are registered trademarks of Motorola, Inc. Other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies and are hereby acknowledged.

  • Page 3: Battery Insertion/Removal

    Quick Reference Guide Introduction The Symbol LS4278 scanner combines excellent scanning performance and advanced ergonomics to provide the best value in a lightweight laser scanner. Whether used as a hand-held scanner or in hands-free mode in a stand, the scanner ensures comfort and ease of use for extended periods of time. Before...

  • Page 4: Wall Mount

    Symbol LS4278 Scanner Insertion in Cradle Table Top Wall Mount hook facing up Aiming...

  • Page 5: Beeper Definitions

    Standard Use Low/medium/high beeps Power up. High beep A bar code symbol was decoded (if decode beeper is enabled). Four long low beeps A transmission error was detected in a scanned symbol. The data is ignored. This occurs if a unit is not properly configured.

  • Page 6: Led Definitions

    Symbol LS4278 Beeper Sequence Indication High/low beeps Bluetooth disconnection event. Long low/long high beeps Page timeout; remote device is out of range/not powered. Long low/long high/long low/long Connection attempt was rejected by remote device. high beeps Code 39 Buffering High/low beeps New Code 39 data was entered into the buffer.

  • Page 7: Troubleshooting

    Refer to the Product Reference Guide for more type. information. Bar code symbol is Check the symbol to ensure it is not defaced. Try unreadable. scanning test symbols of the same bar code type. Distance between Move the scanner closer to or further from the bar scanner and bar code.

  • Page 8: Programming Bar Codes

    Symbol LS4278 Programming Bar Codes Following are some frequently used programming bar codes. NOTE For additional host types, refer to the Symbol LS4278 Product Reference Guide, p/n 72E-69834-xx, available on the Symbol LS4278 CD, or on the website: http://www.motorola.com/enterprisemobility/manuals. Set Defaults Scan SET DEFAULTS to set all parameters to their default values.

  • Page 9: Host Types

    Quick Reference Guide Host Types If a Synapse cable is used (i.e., part number STIxx-xxxx), the scanner autodetects the Synapse cable and there is no need to scan bar codes to enable the Synapse host. If a USB interface is used, the scanner autodetects the USB and defaults to the HID keyboard interface.
  • Page 10 Symbol LS4278 Country Keyboard Types (Country Codes) GERMAN Windows SPANISH Windows ITALIAN Windows SWEDISH Windows UK ENGLISH Windows JAPANESE Windows PORTUGUESE-BRAZILIAN Windows...
  • Page 11 Quick Reference Guide RS-232 Host Types STANDARD RS-232 ICL RS-232 NIXDORF RS-232 MODE A NIXDORF RS-232 MODE B FUJITSU RS-232 OPOS/JPOS USB Host Types HID KEYBOARD EMULATION IBM HAND-HELD USB...
  • Page 12 Symbol LS4278 IBM 46XX Host Types PORT 5B PORT 9B Wand Emulation Host Type SYMBOL WAND Many Wand hosts require input as Code 39 data. Scan the following bar codes to enable or disable transmission of data to the Wand host as Code 39 data.
  • Page 13 Quick Reference Guide Radio Communications Host Types Scan a bar code below to choose how the scanner connects to a remote device. Scan Cradle Host if connecting to the Symbol STB4278 cradle. CRADLE HOST SERIAL PORT PROFILE (MASTER) SERIAL PORT PROFILE (SLAVE)
  • Page 14 Symbol LS4278 NOTE If three scanners are actively connected to the cradle (Multipoint-to-Point mode), a fourth scanner cannot connect regardless of the pairing mode. UNLOCKED PAIRING MODE (Default) LOCKED PAIRING MODE Pairing Methods There are two pairing methods. The default method pairs (connects) the scanner and cradle when the pairing bar code on the cradle is scanned.

  • Page 15: Ergonomic Recommendations

    Symbol Technologies, Inc., the Enterprise Mobility business of Motorola, Inc. ("Motorola"). All Symbol devices are designed to be compliant with rules and regulations in locations they are sold and will be labeled as required. Any changes or modifications to Symbol Technologies equipment, not expressly approved by Symbol Technologies, could void the user's authority to operate the equipment.

  • Page 16: Power Supply

    Operation of the device without regulatory approval is illegal. Power Supply Use only a Symbol-approved power supply (p/n 50-14001-001R) output rated 5 VDVC and minimum 650mA. The power supply is certified to EN60950-1 with SELV outputs. Use of alternative power supply will invalidate any approval given to this device and may be dangerous.

  • Page 17: Marking And European Economic Area (Eea)

    Italy requires a user license for outside usage. Statement of Compliance Symbol Technologies, Inc., hereby, declares that this device is in compliance with the essential requirements and other relevant provisions of Directives 1999/5/EC, 89/336/EEC and 73/23/EEC. Declaration of Conformities may be obtained from http://www.motorola.com/enterprisemobility/doc/.

  • Page 18: Laser Devices

    Symbol LS4278 Laser Devices Complies with: 21CFR1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated July 26, 2001. EN60825-1:1994+ A1:2002 +A2:2001, IEC60825-1993+A1:1997+A2:2001. Class 1 Laser devices are not considered to be hazardous when used for their intended purpose.
  • Page 19 Quick Reference Guide Español: Para clientes en la Unión Europea: todos los productos deberán entregarse a Motorola al final de su ciclo de vida para que sean reciclados. Si desea más información sobre cómo devolver un producto, visite: http://www.motorola.com/recycling/weee. Français : Clients de l'Union Européenne : Tous les produits en fin de cycle de vie doivent être retournés à Motorola pour recyclage.

  • Page 20: Service Information

    1-800-927-9626 http://www.motorola.com/enterprisemobility MOTOROLA and the Stylized M Logo and Symbol and the Symbol logo are registered in the U.S. Patent and Trademark Office. All other product or service names are the property of their respective owners. © Motorola, Inc. 2008...
