TEC MA-1650-4 Series Programming Manual

Electronic cash register
Hide thumbs
Table of Contents

Advertisement

Quick Links

TEC Electronic Cash Register
MA-1650-4 SERIES
Programming Manual
Document No.
EO3-11070B
Original
Apr., 1996
(Revised Apr., 1998)
PRINTED IN JAPAN

Advertisement

Table of Contents
loading

Related Manuals for TEC MA-1650-4 Series

Summary of Contents for TEC MA-1650-4 Series

  • Page 1 TEC Electronic Cash Register MA-1650-4 SERIES Programming Manual Document No. EO3-11070B Original Apr., 1996 (Revised Apr., 1998) PRINTED IN JAPAN...

  • Page 2: Programming Manual

    EO8-11092 MA-1350-2 SERIES PROGRAMMING MANUAL (Stand-alone Level)

  • Page 3: Table Of Contents

    5. SYSTEM START-UP PROCEDURE ..........13 6. RAM CLEAR, DATA CLEAR, STATUS CLEAR ....... 16 7. TERMINAL FILE PROGRAMMING ..........19 8. VERIFICATION OF PROGRAMMED DATA ........177 Copyright © 1999 by TOSHIBA TEC CORPORATION All Rights Reserved 570 Ohito, Ohito-cho, Tagata-gun, Shizuoka-ken, JAPAN...

  • Page 4: Introduction

    EO3-11070 MA-1650-4 SERIES 1. INTRODUCTION This programming manual for TEC electronic cash register MA-1650 series is provided for salespersons, field engineers and other personnel. This manual is comprised of two parts: Stand-alone level and Master-Satellite level. The Master-Satellite level handles addition to and changes of the Stand-alone level only. Please be sure to read the Stand-alone level first.

  • Page 5: Hardware Specifications

    EO3-11070 MA-1650-4 SERIES 3. HARDWARE SPECIFICATIONS TERMINAL MODEL CONFIGURATIONS Series Type: Destination Code: US/CA series (US, etc.) Drawer Type S: SP drawer A: New SP drawer Validation Type Blank: 1 line M: Multi (11) lines FIU Type Standard Models: MA-1650-4-S-US...
  • Page 6 EO3-11070 MA-1650-4 SERIES SIZE: 460 mm (width) x 450 mm (depth) x 348 mm (height) ... including rubber feet or 412 mm (height) when Customer Display is popped up. WEIGHT: 16.5 kg AC 117 V, 100 V, 230 V ± 10%; 50/60 Hz ± 10%...
  • Page 7 EO3-11070 MA-1650-4 SERIES NUMBER OF KEYS ON THE KEYBOARD: Ordinary (Stroke Type) Keyboard ... Max. 90 keys Flat (Moisture-proof) Keyboard ... Max. 145 keys PLU Keyboard (PK-2) ... Max. 130 keys (option) KEY ENTRY METHOD: Two-key Roll-over DISPLAY: OPERATOR DISPLAY: Upper Row (Factory option) ... 16-digit dot fluorescent display Display Color ...

  • Page 8: Capacities

    EO3-11070 MA-1650-4 SERIES 4. CAPACITIES INDEXING CAPACITIES: Input Item Digits Remarks Amount Quantity in Multiplication 3 integer digits + 3 decimal digits Unit Price in Multiplication Scale Unit Price Parallel Type Scale Tender by Media Keys Non-add Number Percent Rate...
  • Page 9 EO3-11070 MA-1650-4 SERIES BASIC MEMORY CAPACITIES: (NOTE: At item counts, “6+2 dig.” means that it has 6 integer digits and 2 decimal digits.) Major Group Memory (max. 10 Major Groups) Memory Type Counter or Total digits Daily Memory Item Count...
  • Page 10 EO3-11070 MA-1650-4 SERIES PLU Memory (900 PLUs (standard); max. 1500 PLUs without PLU Inquiry option or with Standard Memory use; max. 65000 PLUs with PLU Inquiry option or with Expansion Memory use; the maximum number of PLUs varies depending on the RAM allocation.)
  • Page 11 EO3-11070 MA-1650-4 SERIES Salesperson Memory (max. 99 salespersons) Memory Type Counter or Total digits Daily Memory Net Sale without Tax Item Count 6 + 2 Amount Net Sale with Tax Item Count 6 + 2 Amount Gross Sale Item Count...
  • Page 12 EO3-11070 MA-1650-4 SERIES Financial Memory (continued) DAILY NAME OF TOTAL/COUNTER REMARKS COUNTER TOTAL COUNTER TOTAL COUNTER DIGITS TYPE DIGITS DIGITS DIGITS Tax 1 to Tax 4 4 x 10 4 x 10 Tax 5 (Manual Tax) Net Sale With Tax...
  • Page 13 EO3-11070 MA-1650-4 SERIES Financial Memory (continued) DAILY NAME OF TOTAL/COUNTER REMARKS COUNTER COUNTER COUNTER TOTAL TOTAL TYPE DIGITS DIGITS DIGITS DIGITS Debit-in-drawer ENTRY EBT Cash-in-drawer ENTRY EBT F/S-in-drawer ENTRY Food Stamp-in-drawer ENTRY Food Stamp Change Item Correct ENTRY Item Corr on DP+/PLU+...
  • Page 14 EO3-11070 MA-1650-4 SERIES Financial Memory (continued) DAILY NAME OF TOTAL/COUNTER REMARKS COUNTER TOTAL COUNTER TOTAL COUNTER TYPE DIGITS DIGITS DIGITS DIGITS Tax 1 to 4 Exempt 4 x 10 4 x 10 Tax Exempt 1 to 4 by Food Stamp...
  • Page 15 EO3-11070 MA-1650-4 SERIES Others DAILY NAME OF TOTAL/COUNTER REMARKS COUNTER TOTAL COUNTER TOTAL COUNTER TYPE DIGITS DIGITS DIGITS DIGITS Hourly Range Reset Counter ENTRY PLU Reset Counter ENTRY Department Reset Counter ENTRY Financial Reset Counter ENTRY PLU Group Reset Counter...

  • Page 16: System Start-Up Procedure

    EO3-11070 MA-1650-4 SERIES 5. SYSTEM START-UP PROCEDURE Case 1: To start-up using the MA-1650 terminal only: RAM Clear (Chapter 6) For using Expansion Memory, perform RAM Allocation Setting this setting. For using Standard Memory, (Chapter 7, Submode 79) this setting is necessary only for using any other than the default value for memory allocation.
  • Page 17 EO3-11070 MA-1650-4 SERIES Case 3: To start-up using a PL-3: When the expansion memory is not installed, the terminal can be started up by the PL-3. FDK Format Save preprogrammed terminal data onto the PL-3. Load data saved into the PL-3 into another terminal.
  • Page 18 EO3-11070 MA-1650-4 SERIES • Program Data Save/Load Turn OFF the ECR power, and wait for 15 seconds. Connect one end of the bus direct cable to the PL-3 unit, and the other end to the PL-3 interface connector of the ECR.

  • Page 19: Ram Clear, Data Clear, Status Clear

    EO3-11070 MA-1650-4 SERIES 6. RAM CLEAR, DATA CLEAR, STATUS CLEAR RAM CLEAR If the register becomes completely inoperative due to battery discharge or malfunction of program memory, the RAM clear operation must be carried out following the procedure listed below. When a RAM clear is operated, all the memory content that has been stored in the RAM will be cleared (i.e.

  • Page 20: Status Clear

    EO3-11070 MA-1650-4 SERIES STATUS CLEAR The Status Clear operation will only clear an error or key-lock condition that disables normal operations. Thus the sales data and programmed data will not be cleared (except when a Status Clear is used to clear a key-lock during a sale, the sale item data already entered in the sale will be cleared).
  • Page 21 EO3-11070 MA-1650-4 SERIES -- RECEIPT SAMPLES -- RAM CLEAR DATA CLEAR STATUS CLEAR 11-14-1994 MON #0 11-14-1994 MON #0 11-14-1994 MON #0 RAM-C DATA-C STATUS-C 0001 11:28TM 0001 11:30TM 0002 11:30TM - 18 -...

  • Page 22: Terminal File Programming

    EO3-11070 MA-1650-4 SERIES 7. TERMINAL FILE PROGRAMMING TABLE OF TERMINAL FILE PROGRAMMING OPERATIONS BASIC KEY FUNCTIONS AND KEYBOARD VARIATIONS IN PROGRAMMING OPERATIONS .............. 21 CHARACTER ENTRIES ....................................22 CONDITION REQUIRED FOR PROGRAMMING OPERATIONS ....................... 29 PROGRAMMING ITEM CONDITION (NOTE) Mode/Submode No. PAGE SFKC (Selective Function Key Code) PROGRAMMING .........

  • Page 23: Basic Key Functions

    EO3-11070 MA-1650-4 SERIES NOTE: TC = After Table Clear DGZ = After Department GT Reset PGZ = After PLU GT Reset FZ = After Financial Daily Reset HZ = After Hourly Range Reset All Resets = After Daily and GT Reset...
  • Page 24 EO3-11070 MA-1650-4 SERIES When the PLU Keyboard PK-2 (hardware option) is connected: 1) Character Keys provided on the PK-2 Character Setting Sheet may be used to directly enter the characters (DIRECT CHARACTER ENTRY method). Any characters not provided there (and those provided as well) may be entered, in the CHARACTER CODE ENTRY method, through the Numeric Keys and the [#] key on the ECR keyboard.

  • Page 25: Character Entries

    EO3-11070 MA-1650-4 SERIES CHARACTER ENTRIES As already stated, there are two methods of operations for character settings for names or messages: CHARACTER CODE ENTRY Method and DIRECT CHARACTER ENTRY Method. CHARACTER CODE ENTRY Method This method is to set a character by entering a Character Code and depressing the [#] key. This method is allowed in either of Case 1 and Case 2, but is operated only on the ECR keyboard (Ordinary Type or Flat Type).

  • Page 26: Character Code Entry Method

    EO3-11070 MA-1650-4 SERIES Character Code Entry Method Character Code Table 1: Standard Characters - 23 -...
  • Page 27 EO3-11070 MA-1650-4 SERIES Character Setting Operations: • To set a regular-sized character, enter the COL (column) code and then the ROW code, followed by the [#] key. ex.) To set “%”, enter 205 and depress [#]. To set “kg”, enter 1508, and depress [#].

  • Page 28: Direct Character Entry Method

    EO3-11070 MA-1650-4 SERIES Direct Character Entry Method Using Flat Keyboard (installed as the ECR Main Keyboard): -- Setting Mode Key Layout -- (Use the special template for this purpose and insert it between the film layers covering the Flat Keyboard. This key layout is applicable to only certain submodes.)
  • Page 29 EO3-11070 MA-1650-4 SERIES Using TKB-1 (Programming Keyboard; hardware option) Shift Keys (1 to 4), Shift Lock Key Used to designate the shift of the character keys. Each character has three different characters, each of which is designated by the Shift Key 1 to Shift Key 3. (The Shift Key 4 is not used for the MA-1650 series models.) Shift Key 2 and Shift Key 3 are effective for one following character only.

  • Page 30: Function Keys

    EO3-11070 MA-1650-4 SERIES Function Keys Except for the [CODE] key, each of the function keys corresponds to the identical key installed on the ECR keyboard as to the function in programming operations. ([CLEAR] = [C], [X] = [@/FOR]) The [CODE] key cannot be used for the MA-1650 series ECRs.
  • Page 31 EO3-11070 MA-1650-4 SERIES Using PK-2 (PLU Keyboard; hardware option) The PK-2 is used to enter a required PLU code by simply depressing the code-preset key on the PK-2 keyboard in the REG or MGR mode. In addition, the PK-2 can be used to enter characters directly during the programming operations that require character settings, such as STORE NAME/MESSAGE AND COMMERCIAL MESSAGE PROGRAMMING, DEPARTMENT TABLE PROGRAMMING, etc.

  • Page 32: Condition Required For Programming Operations

    EO3-11070 MA-1650-4 SERIES CONDITION REQUIRED FOR PROGRAMMING OPERATIONS At the top of each programming operation a “CONDITION” is given. Unless the register satisfies this condition, the programming operations will not be allowed. There are two types of conditions: “Any time outside a sale”...
  • Page 33 EO3-11070 MA-1650-4 SERIES SFKC (Selective Function Key Code) PROGRAMMING This operation is to determine the keyboard layout with the required keys and must be carried out first before any other programming operation. If a RAM CLEAR has been operated prior to the SFKC programming, program only the keys that require changes from the SFKC in the Standard Keyboard which has automatically been set by the RAM Clear operation.
  • Page 34 EO3-11070 MA-1650-4 SERIES SFKC PROGRAMMING OPERATION FLOW Mode Lock: BLIND 76 [AT/TL] ISFKCI [KEY] [AT/TL] to read preset SFKC The key that requires the function of the SFKC. Repeat SFKC TABLE SFKC KEY NAME MEMORY TO BE OPENED (REMARKS) dead-key code...
  • Page 35 EO3-11070 MA-1650-4 SERIES SFKC TABLE (continued) SFKC KEYNAME MEMORY TO BE OPENED (REMARKS) PR OPEN (Preset Open) No memory LC OPEN (Listing Capacity Open) No memory OPEN (PR/LC Open) No memory VALIDATE (Validation) Validation Counter # (Non-add Number) No memory...
  • Page 36 EO3-11070 MA-1650-4 SERIES SFKC TABLE (continued) SFKC KEYNAME MEMORY TO BE OPENED (REMARKS) 117 to -- vacant -- FSTL TEND (Food Stamp Total/Tender) Food Stamp Total, Food Stamp-in-drawer, Food Stamp Change CUR 1 (Foreign Currency 1) Foreign Currency 1-in-drawer CUR 2 (Foreign Currency 2)
  • Page 37 EO3-11070 MA-1650-4 SERIES SFKC TABLE (continued) SFKC KEYNAME MEMORY TO BE OPENED (REMARKS) DISPLAY 2 (Display 2) No memory (Available for V1.9 or after) DISPLAY 3 (Display 3) No memory (Available for V1.9 or after) DISPLAY 4 (Display 4) No memory (Available for V1.9 or after) DISPLAY 5 (Display 5) No memory (Available for V1.9 or after)
  • Page 38 EO3-11070 MA-1650-4 SERIES STANDARD KEYBOARD 2 (auto-set by RAM CLEAR on V1.8 or before) -- Flat Keyboard Type -- PLU Preset-code keys • Department keys VALI RECEIPT HOLD RECEIPT RECALL ISSUE VOID DATE ITEM TX/M FS/M VOID CORR @/FOR DOLL...
  • Page 39 EO3-11070 MA-1650-4 SERIES STANDARD KEYBOARD 3 (auto-set by RAM CLEAR on V1.9 or after) -- Ordinary Keyboard Type -- VALI HOLD PRINT RECEIPT RECALL DATE CARD SALES SI/M TX/M COMMENT PERSON VOID VALI DOLL FS/M OPEN DISC DATE CARD @/FOR...
  • Page 40 EO3-11070 MA-1650-4 SERIES STANDARD KEYBOARD 4 (auto-set by RAM CLEAR on V1.9 or after) -- Flat Keyboard Type -- PLU Preset-code keys • Department keys VALI RECEIPT HOLD RECEIPT RECALL ISSUE VOID DATE ITEM PRINT TX/M FS/M VOID CORR @/FOR...
  • Page 41 EO3-11070 MA-1650-4 SERIES RAM ALLOCATION SETTING (Submode 79) This submode sets the capacity of the Expansion Memory, the number of cashiers, the number of PLUs, the number of check tracks (customer files), the number of data capture records, and the number of Negative Cards to be checked.
  • Page 42 EO3-11070 MA-1650-4 SERIES * Code to designate Expansion Memory Capacity: 0: No Expansion Memory (i.e. with Standard Memory only) 1: 512KB 2: 1MB 3: 2MB 4: 3MB 5: 4MB ** Codes to designate System Setting (Combine the following four codes in a maximum of 4 digits. For example, enter 12 to designate 1 and 2.):...
  • Page 43 EO3-11070 MA-1650-4 SERIES Setting Example) To allocate the RAM as in the following: Expansion Memory: 4MB (Code 5) System Setting: System Setting Codes 1 to 3 are used. Number of Cashiers: 4 cashiers Number of PLUs: 4,000 PLUs Number of Check Tracks:...
  • Page 44 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION PROGRAMMING (Submode 11 or 18) This operation is used to set the ECR’s basic features and selective functions to meet the requirements of the market and your user. CONDITION After Financial Daily Reset OPERATION For User System Options:...
  • Page 45 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS NON-PRINT OPTION I ITEM SELECTIVE STATUS REMARKS STANDARD STATUS Time (on Sale Receipt, PRINT RESET Report, Program Receipt) NON-PRINT Sale Item Count on each...
  • Page 46 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS NON-PRINT OPTION II ITEM SELECTIVE STATUS REMARKS STANDARD STATUS Discount/% Discount NOTE below PRINT RESET Memory of Department Report NON-PRINT RESET -- vacant --...
  • Page 47 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS OPTIONAL FUNCTION I ITEM SELECTIVE STATUS REMARKS STANDARD STATUS Fraction Rounding If both RESET, it will be Follow Bit 2 status. RESET ROUND UP ROUND OFF.
  • Page 48 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS OPTIONAL FUNCTION II ITEM SELECTIVE STATUS REMARKS STANDARD STATUS Zero-skip in All Depart- Departments/Groups Print all Departments data RESET ment and Department with no sales will be Group Reports skipped in the report.
  • Page 49 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS SELECTIVE ITEMIZER CONTROL ITEM SELECTIVE STATUS REMARKS STANDARD STATUS SI1 Total Amount on Will print on Journal in PRINT (and DISPLAY) RESET Receipt and Remote slip either status.
  • Page 50 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS REMOTE SLIP PRINTER CONTROL ITEM SELECTIVE STATUS REMARKS STANDARD STATUS Remote Slip Print Compul- NOT COMPULSORY RESET sory for any PB entry in REG or MGR mode COMPULSORY NOTE 1 below.
  • Page 51 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS OPTIONAL FUNCTION III ITEM SELECTIVE STATUS REMARKS STANDARD STATUS Display Message Method The message to be dis- 16 CHARACTERS HELD RESET played is programmable,...
  • Page 52 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS SCANNING OPTION I ITEM SELECTIVE STATUS REMARKS STANDARD STATUS NOTE below Conversion of Shortened RESET Padding preceding digits with 0 Type UPC-E of Barcodes...
  • Page 53 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS NON-PRINT OPTION III ITEM SELECTIVE STATUS REMARKS STANDARD STATUS RESET -- vacant -- Check No. Code in En- RESET PRINT dorsement Printing NON-PRINT Date/Time Line in En-...
  • Page 54 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS MANAGER INTERVENTION ITEM SELECTIVE STATUS REMARKS STANDARD STATUS RESET -- vacant -- RESET -- vacant -- RESET -- vacant -- RESET -- vacant --...
  • Page 55 EO3-11070 MA-1650-4 SERIES * This address is applicable for V2.0 or after. SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS V2.0 OPTION ITEM SELECTIVE STATUS REMARKS STANDARD STATUS NOTE 1 below. Date of Birth Entry before...
  • Page 56 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS VALIDATION ITEM SELECTIVE STATUS REMARKS STANDARD STATUS Single-or Multi-Validation NOTE 1 below. SINGLE-VALIDATION RESET MULTI-VALIDATION Date Print PRINT RESET NON-PRINT Consecutive No. (of PRINT...
  • Page 57 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS TAX CONTROL I ITEM SELECTIVE STATUS REMARKS STANDARD STATUS Multiple Taxes NOTE 1 below CONSOLIDATED PRINT RESET Consolidated or Separate Print on Receipt SEPARATE PRINT...
  • Page 58 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS TAX CONTROL II ITEM SELECTIVE STATUS REMARKS STANDARD STATUS GST feature or FOOD FOOD STAMP RESET STAMP feature GST Fraction Process If both RESET, RESET Follow Bit 3 status.
  • Page 59 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS SCANNING OPTION II ITEM SELECTIVE STATUS REMARKS STANDARD STATUS Print Selection of PLU NOTE below NON-PRINT RESET scanned code PRINT RESET -- vacant --...
  • Page 60 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS DRAWER OPTION ITEM SELECTIVE STATUS REMARKS STANDARD STATUS Drawer-close Compulsory NOTE 1 below. NOT COMPULSORY RESET COMPULSORY Drawer Warning Alarm RESET NON-ACTIVE ACTIVE NOTE 2 below.
  • Page 61 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS OPTIONAL FUNCTION IV ITEM SELECTIVE STATUS REMARKS STANDARD STATUS No-sale Entry After Non- ALLOWED RESET add # Entry PROHIBITED Number of Times for Non-...
  • Page 62 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS OPTIONAL FUNCTION V ITEM SELECTIVE STATUS REMARKS STANDARD STATUS NOTE 1 below Preset Point for one Ordinary Digit Process RESET decimal digit Preset Point One Decimal Digit U.S.
  • Page 63 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS OPTIONAL FUNCTION VI ITEM SELECTIVE STATUS REMARKS STANDARD STATUS IPD or INPD on Journal in NOTE 1 below RESET REG and MGR modes INPD CARD No.
  • Page 64 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS OPTIONAL FUNCTION VII ITEM SELECTIVE STATUS REMARKS STANDARD STATUS NOTE below Customer Display Method ORDINARY RESET (Increment Type) PUT-AWAY (Holding Type) RESET -- vacant --...
  • Page 65 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS OPTIONAL FUNCTION VIII ITEM SELECTIVE STATUS REMARKS STANDARD STATUS [%+] and [%-] after a ANY NUMBER OF TIMES RESET Subtotal Within a Sale ONLY ONCE ALLOWED...
  • Page 66 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS OPTIONAL FUNCTION IX ITEM SELECTIVE STATUS REMARKS STANDARD STATUS Date Set and Print Order If both RESET, it will be RESET Follow Bit 2 status.
  • Page 67 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS OPTIONAL FUNCTION X ITEM SELECTIVE STATUS REMARKS STANDARD STATUS Decimal Point in Item -- ex.) 1.5% • (POINT) RESET Count and % Rate -- ex.) 1,5%...
  • Page 68 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS SCALE OPTION ITEM SELECTIVE STATUS REMARKS STANDARD STATUS Scale Data 5 or 4 digits for 5 digits RESET Parallel Type Scale 4 digits RESET...
  • Page 69 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS FOREIGN CURRENCY OPTION ITEM SELECTIVE STATUS REMARKS STANDARD STATUS [CUR 1] (Foreign Cur- These bits selections are 0.00 (£, F, DM, etc.) RESET rency 1) Zero-suppress also applied to the print.
  • Page 70 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS OPTIONAL FUNCTION XI ITEM SELECTIVE STATUS REMARKS STANDARD STATUS This bit is applicable for PLU Tax/Food Stamp RESET Obeys PLU Own Status Status on PLU Entry V2.0 or after.
  • Page 71 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS OPTIONAL FUNCTION XII ITEM SELECTIVE STATUS REMARKS STANDARD STATUS This bit must always be RESET RESET -- vacant -- Cashier Identifying Code Entry Method...
  • Page 72 EO3-11070 MA-1650-4 SERIES * This address is applicable for V1.9 or after. SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS EBT OPTION I ITEM SELECTIVE STATUS REMARKS STANDARD STATUS [DISPLAY 1] Key Function NOTE 1 below...
  • Page 73 EO3-11070 MA-1650-4 SERIES * This address is applicable for V1.9 or after. SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS EBT OPTION II ITEM SELECTIVE STATUS REMARKS STANDARD STATUS NOTE 1 below Over-tendering using the...
  • Page 74 EO3-11070 MA-1650-4 SERIES * This address is applicable for V3.0 or after. SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS EFT OPTION ITEM SELECTIVE STATUS REMARKS STANDARD STATUS RESET -- vacant -- Store Copy printed on the...
  • Page 75 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS IN-LINE OPTION ITEM SELECTIVE STATUS REMARKS STANDARD STATUS Copying of Backup Data Manual Copying only RESET Auto Copying feature Retry for Collection RESET Manual Retry only...
  • Page 76 EO3-11070 MA-1650-4 SERIES SYSTEM OPTION TABLE Standard Bit Set (auto-set by RAM Clear) ADDRESS No. CONTENTS PC OPTION ITEM SELECTIVE STATUS REMARKS STANDARD STATUS RESET -- vacant -- BCC Receive Text Check- RESET CHECK NON-CHECK Reset Report Issuance on RESET...
  • Page 77 EO3-11070 MA-1650-4 SERIES STORE NAME/MESSAGE AND COMMERCIAL MESSAGE PROGRAMMING (Submode 1) CONDITION Any time outside a sale OPERATION Mode Lock: SET Repeat for (For sequentially another line. 1 [X] | Line No. | [ST] programming lines, the line number specification can be skipped.)
  • Page 78 EO3-11070 MA-1650-4 SERIES ex.) To program the following draft as the Store Name/Message and Commercial Message (under the option “Store Name by DOT PRINTER”): Store Name/ Line No. 1 Message portion, Which can be 1 3 4 3 P E A C H D R I V E Line No.
  • Page 79 EO3-11070 MA-1650-4 SERIES CASHIER CODE AND NAME PROGRAMMING (Submode 2) Programming CONDITION Any time outside a sale OPERATION Mode Lock: SET | Cashier Code | [NS] 2 [X] (See NOTE 1 below.) Submode No. For Address 1 : Cashier Name...
  • Page 80 EO3-11070 MA-1650-4 SERIES ex.) To program the following cashier data: Cashier Code 1: Name JONES, Status 0 (for Sale Entries) Cashier Code 2: Name SMITH, Status 0 (for Sale Entries) Cashier Code 3: Name MEHL, Status 1 (for Training Entries)
  • Page 81 EO3-11070 MA-1650-4 SERIES Deletion CONDITION After the Daily and GT Cashier’s Resets, (and his/her Sign OFF for Code Entry Type) OPERATION Mode Lock: SET Repeatable for another cashier to be deleted. 2 [X] [ITEM CORR] |Cashier Code| [NS] [AT/TL] [VOID] Submode No.
  • Page 82 EO3-11070 MA-1650-4 SERIES DEPARTMENT TABLE PROGRAMMING (Submode 3) Programming CONDITION To change the Positive/Negative Status: After Department and PLU Daily and GT Resets To change any other programmed data or to newly program departments: Any time outside a sale OPERATION...
  • Page 83 EO3-11070 MA-1650-4 SERIES NOTES: 1. The “Address Nos” designation at the top after “3 [X]” can be skipped if not necessary. If entered, the designated Address(es) will automatically be accessed after the department designation. For example, if you enter |0204| [#] here (designate each address by entering a two-digit code; 01 for Address 1, 02 for Address 2, etc.), you will then enter:...
  • Page 84 EO3-11070 MA-1650-4 SERIES Address No. Description of Programming Contents -- Continued -- Enter 0 for linking neither Major nor Minor Groups (the preceding zeros may be omitted). NOTE: The “Major Group” and “Minor Group” here are merely namings for those two grouping total memories.
  • Page 85 EO3-11070 MA-1650-4 SERIES Address No. Description of Programming Contents -- Continued -- Preset Price • For a preset department (preset-price department), enter a maximum of 6- digit price, and depress [#]. 1 to 999999 (result: $0.01 to $9999.99) When the option “Preset Point for one decimal digit allowed” is selected, the decimal digit can be entered after entering a maximum of 5 integer digits and [•] key.
  • Page 86 EO3-11070 MA-1650-4 SERIES Address No. Description of Programming Contents -- Continued -- Setting Examples: To set only Status 2 to ON ....Enter 2 [#] To set Statuses 2, 3, 5 to ON ..Enter 235 [#] To set none of statuses to ON ..Enter 0 [#] Status 2 Selection •...
  • Page 87 EO3-11070 MA-1650-4 SERIES Address No. Description of Programming Contents -- Continued -- Tax Status • Enter a one- to four-digit Status Code for applicable Taxes. Or enter 0 if the department handles non-taxable items. 0: Non-taxable (More than one code can be entered for 1: Tax 1 (Tax 1 taxable) combining Tax1 to Tax4 taxable status.
  • Page 88 EO3-11070 MA-1650-4 SERIES Address No. Description of Programming Contents -- Continued -- Sub-link Department Code • This entry is useful when the department item entry should always be followed by another department’s item sale. If the department is not applied to this case, skip this address entry.
  • Page 89 EO3-11070 MA-1650-4 SERIES Address No. Description of Programming Contents -- Continued -- 6) When the [ITEM CORR] key is operated immediately after the Head- link item entry, the Sub-link compulsory status will also be canceled. 7) When the [ITEM CORR] key is operated immediately after the compulsory Sub-link item entry, an error will result.
  • Page 90 EO3-11070 MA-1650-4 SERIES ex.) To program the following status and name for each department: DEPT Address 1 Address 2 Address 3 Address 4 Address 5 Address 6 Address 7 Address 8 Adderss 9 CODE Linked GP Dept Preset Status 1...
  • Page 91 EO3-11070 MA-1650-4 SERIES KEY OPERATION: To program the data listed in the table on the preceding page: Mode Lock: SET, enter 3, depress [X]. STORE 1343 PEACH DRIVE PHONE: 87-6437 1 [DP#] 1 [ST] 0101 [#] (Dept. 1; Address 1: Linked GP0101)
  • Page 92 EO3-11070 MA-1650-4 SERIES Deletion CONDITION After Department and PLU Daily and GT Resets OPERATION Mode Lock: SET Individual Department Deletion Repeatable for other depts to be deleted. [ITEM CORR] [DEPT] 3 [X] [AT/TL] [VOID] |Department Code| [DP#] Submode No. All Department Deletion...
  • Page 93 EO3-11070B MA-1650-4 SERIES PLU TABLE PROGRAMMING (Submode 4) This submode can be operated when new PLU items are to be added, PLU program data is to be changed, or PLUs are to be deleted. Programming or Changing CONDITION Any time outside a sale...
  • Page 94 EO3-11070B MA-1650-4 SERIES NOTES: 1. The “Address Nos” designation at the top after “4 [X]” can be skipped if not necessary. If entered, the designated Address(es) will automatically be accessed after the PLU Code designation. (The idea is the same as the Address Nos Designation in the DEPARTMENT PROGRAMMING operation.)
  • Page 95 EO3-11070B MA-1650-4 SERIES Address No. Description of Programming Contents -- Continued -- Status 1 Selection • Enter the Status Codes 1 to 7 whose status must be set to ON side. More than one code may be entered. Enter 0 when none of the statuses should be set to ON.
  • Page 96 EO3-11070B MA-1650-4 SERIES Address No. Description of Programming Contents -- Continued -- Status 2 Selection • Enter the Status Codes 2 to 7 (Code 3 is vacant.) whose status must be set to ON side. More than one code may be entered. Enter 0 when none of the statuses should be set to ON.
  • Page 97 EO3-11070B MA-1650-4 SERIES Address No. Description of Programming Contents -- Continued -- Tax Status • Enter one- to four-digit Status Codes for applicable Taxes. Non-taxable (More than one code can be entered for Tax 1 (Tax 1 taxable) combining Tax1 to Tax4 taxable status.
  • Page 98 EO3-11070B MA-1650-4 SERIES Address No. Description of Programming Contents -- Continued -- PLU Group No. (for purposes of reports) • Enter a 2-digit code (1 to 99) as a PLU Group No. to which the PLU belongs, and depress [#]. To cancel the Group No. once set, enter 0 and depress [#].
  • Page 99 EO3-11070B MA-1650-4 SERIES (Revision Date: Aug. 11, ‘98) Address No. Description of Programming Contents -- Continued -- (10) 3) The linkage is effective in a sale only for one Head-link PLU and one Sub-link PLU. If the Sub-link PLU is further programmed with another Sub-link PLUs (with a Link-PLU Table No.), the third PLU will...
  • Page 100 EO3-11070B MA-1650-4 SERIES Address No. Description of Programming Contents -- Continued -- Tare Table No. (for Scale-compulsory PLUs only) Enter the Tare Table No. (1 to 9). The content of each Tare Table is set later in a separate operation (submode 26). In a scale item entry of a PLU with a Tare Table No.
  • Page 101 EO3-11070B MA-1650-4 SERIES ADDITIONAL NOTES If a PLU is linked to a negative Department, the PLU is automatically set as negative PLU. If a PLU is linked to an Other Income Department, the PLU is automatically set as Other Income PLU.
  • Page 102 EO3-11070B MA-1650-4 SERIES ex.) To program the following PLUs: Address Address Address Address Address Address Address Address Address Address Address Address CODE Linked Preset Status- HI-CONE Whole Link-PLU Tare Indiv. PLU M & M Dept. Name Price Status Unit Package...
  • Page 103 EO3-11070B MA-1650-4 SERIES KEY OPERATION: for programming some of the PLUs listed on the preceding page. (Presumed that the following PLUs are newly programmed.) STORE 1343 PEACH DRIVE Mode Lock: SET, enter 4, depress [X]. PHONE: 87-6437 Open 8:00am to 7:00pm...
  • Page 104 EO3-11070B MA-1650-4 SERIES Deletion CONDITION To delete a PLU with sales data of zero: Any time outside a sale To delete a PLU with sales data of not zero: After PLU Reset OPERATION Mode Lock: SET Individual PLU Deletion Repeatable for another PLU to be deleted.

  • Page 105: Plu Programmed Data Copying

    EO3-11070B MA-1650-4 SERIES PLU Programmed Data Copying This operation is used to copy the programmed data of a PLU item and to use it in programming another PLU item, thus eliminating time in PLU programming operation. CONDITION To program new PLUs or to change any programmed contents of PLUs:...
  • Page 106 EO3-11070B MA-1650-4 SERIES CODING PLUs (supplement to PLU programming operations) A maximum of 6-digit or 13-digit No. may be assigned to each PLU as PLU Code, depending on the system option selection of the PLU Code digits. Any number within this limit may be assigned to each PLU. The following description is applied to the “Manual PLU Entry System Type”.
  • Page 107 EO3-11070B MA-1650-4 SERIES Example using 4-digit codes) -- in case of a clothing shop -- 2 1 3 0 Merchandise serial No. assigned under the same number of the preceding digits. Size ID (1 for Small, 2 for Medium, 3 for Large, etc.) Color ID (0 for White, 1 for Gray, 2 for Black, etc.)
  • Page 108 EO3-11070B MA-1650-4 SERIES TIME SETTING OR ADJUSTMENT (Submode 5) CONDITION Any time outside a sale STORE 1343 PEACH DRIVE OPERATION Mode Lock: SET PHONE: 87-6437 Open 8:00am to 7:00pm 5 [X] |Hour| |Minute| [AT/TL] Closed: every Wednesday (0 to 23) (00 to 59)
  • Page 109 EO3-11070B MA-1650-4 SERIES HOURLY RANGE SETTING (Submode 7) (for report purposes) CONDITION After Hourly Range Reset NOTES: 1. A maximum of 24 hourly ranges can be set. OPERATION Mode Lock: SET 2. To change the table of hourly ranges once set, partially or en-...
  • Page 110 EO3-11070B MA-1650-4 SERIES AMOUNT LIMIT SETTING FOR FUNCTION KEYS (Submode 8) This submode sets the high amount limit in finalizing transactions by tendering through each media key and also sets the high and low amount limits in entering amount through departments.
  • Page 111 EO3-11070 MA-1650-4 SERIES FINANCIAL REPORT ITEM NAME PROGRAMMING (Submode 9) In this operation, the item names printed in Financial Reports are programmed. Many of them are also used to print in sales receipts. Other line items merely used in receipts or others than listed here will be programmed in Submode 10.
  • Page 112 EO3-11070 MA-1650-4 SERIES FINANCIAL REPORT ITEM NAME TABLE Item Total/Counter Name Standard Program Code Grand Total G | T | | | | | | | | N|E|T| |G|T| | | | | | NET GT G | S | | | | | | | |...
  • Page 113 EO3-11070 MA-1650-4 SERIES FINANCIAL REPORT ITEM NAME TABLE (Continued) Item Total/Counter Name Standard Program Code E|B|T| |F|/|S| |I|D| | Media 8-in-drawer (EBT F/S) Food Stamp-in-drawer F|S|I|D| | | | | | | | Item Correct of positive Food Stamp CHANGE...
  • Page 114 EO3-11070 MA-1650-4 SERIES FINANCIAL REPORT ITEM NAME TABLE (Continued) Item Total/Counter Name Standard Program Code Foreign Currency 1 C|U|R|1| | | | | | | | Used as each foreign Foreign Currency 2 C|U|R|2| | | | | | | | currency-in-drawer memory in Financial Reports.
  • Page 115 EO3-11070 MA-1650-4 SERIES NOTES: 1. The maximum number of characters programmable for each item is in the table on the next page. Please note that some items require their name entries as one set. The maximum number of characters in the table shows the capacity in regular-sized characters. One double-sized character occupies two regular-sized characters’...
  • Page 116 EO3-11070 MA-1650-4 SERIES PRINT LINE ITEM NAME TABLE (Continued) Max. Number of Characters Item Item Name or Application Standard Program Code |#|C|L|T|M| | | | | | The following items must be set together. (NOTE 2) Register No. Symbol Cashier/Clerk Symbol...
  • Page 117 EO3-11070 MA-1650-4 SERIES PRINT LINE ITEM NAME TABLE (Continued) Max. Number of Characters Item Item Name or Application Standard Program Code Cashier Sign ON S|I|G|N| |O|N| | | | | Cashier Sign OFF S|I|G|N| |O|F|F| | | | Cashier Sign IN...
  • Page 118 EO3-11070 MA-1650-4 SERIES NOTES: 1. The name in Standard Program for the Amount Mark in Item Code 7 is set with a blank after a RAM Clear. When the specific Amount Mark for the domestic currency is required on sales receipts (such as £, F, $), you must program the entire contents of Item Code 7.
  • Page 119 EO3-11070 MA-1650-4 SERIES NON-TAXABLE AMOUNT LIMIT SETTING (Submode 12) This submode is applied only to the Provinces of Quebec and Ontario, Canada. CONDITION After Financial Daily Reset If the programmed data in this submode is carried out: Tax 1 will automatically be exempted from the sale total when the sum of the sale portion subject to Tax 1 and the sale portion subject to Tax 2 is equal to or less than the set limit amount.
  • Page 120 EO3-11070 MA-1650-4 SERIES MINOR GROUP NAME PROGRAMMING (Submode 13) In this operation, the name of each Minor Group is programmed. Which Departments and Minor Groups are linked to each Major Group has already been set in the DEPARTMENT PROGRAMMING operation, Submode 3.
  • Page 121 EO3-11070 MA-1650-4 SERIES MAJOR GROUP NAME PROGRAMMING (Submode 14) In this operation, the name of each Major Group is programmed. Which Departments and Minor Groups are linked to each Major Group has already been set in the DEPARTMENT PROGRAMMING operation, Submode 3.
  • Page 122 EO3-11070 MA-1650-4 SERIES CUSTOMER FILE CODE (CHECK TRACK NO.) AND NAME SETTING (Submode 15) This submode creates files for customers whose sales are to be processed using the check track memory. CONDITION Any time outside a sale OPERATION Mode Lock: SET Repeat for other codes.
  • Page 123 EO3-11070 MA-1650-4 SERIES Deletion of All Customer File Codes [ITEM CORR] 15 [X] [ALL VOID] [AT/TL] [VOID] NOTE: If the balance of the deleted code is not zero, the Transfer memory of the code will automatically be adjusted to zero. At that time, the previous balance to be reset will be printed.
  • Page 124 EO3-11070 MA-1650-4 SERIES DISPLAY UPPER-ROW MESSAGE PROGRAMMING (Submode 17) This submode programs the message content to be displayed, when certain items are entered, on the upper row of the Operator Display and Customer Display. CONDITION Any time outside a sale...
  • Page 125 EO3-11070 MA-1650-4 SERIES NOTES: 1. A maximum of 16 characters can be programmed as the message for each Item Code. Only regular-sized characters are effective. 2. As shown in the table above, the Standard Program Message is prepared for each Item Code (which is auto-set after a RAM Clear).
  • Page 126 EO3-11070 MA-1650-4 SERIES Report Code Table Report Report Name Mode for output Code GTX GTZ Financial All Individual Cashier All Salesperson Credit Card Company Sales (All Indiv. Companies) Department Group Each Media Sales and In-drawer Total Hourly Range All Department...
  • Page 127 EO3-11070 MA-1650-4 SERIES ex.) To program the following report combinations: STORE 1343 PEACH DRIVE Table No. Report Code: Report Name PHONE: 87-6437 Open 8:00am to 7:00pm Closed: every Wednesday 6: Credit Card Company 8: Dept Group 11-14-1994 MON #1 9: Each Media Sales and In-drawer...
  • Page 128 EO3-11070 MA-1650-4 SERIES SALESPERSON CODE AND NAME PROGRAMMING (Submode 20) By programming Salesperson Codes here, those codes may be used in sales entries. In addition, the name of each salespersons can be programmed in maximum 12 characters. Programming CONDITION Any time outside a sale...
  • Page 129 EO3-11070 MA-1650-4 SERIES Deletion CONDITION After Daily Salesperson Reset OPERATION Mode Lock: SET Repeat for othr salespersons to be deleted. [ITEM CORR] 20 [X] |Salesperson Code| [ST] [AT/TL] [VOID] NOTE: When a Salesperson Code is deleted in the above operation, no entries using that code will be accepted until the code is again opened in the “Programming”...
  • Page 130 EO3-11070 MA-1650-4 SERIES CREDIT CARD COMPANY ID CODE AND NAME PROGRAMMING (Submode 21) This operation programs the name of each credit card company. In sales entries, credit cards of maximum 12 different companies may be used by entering the ID code for the company (1 to 12) and then depressing the [CARD No.] key prior to the [Chg] key for finalizing a sale.
  • Page 131 EO3-11070 MA-1650-4 SERIES • On V1.9 or after, the names shown on the table below are initially programmed for credit card company names. Company Initial Program Remarks ID Code V|I|S|A| | | | | | | | M|A|S|T|E|R| |C|A|R|D| A|M|E|X| | | | | | | |...
  • Page 132 EO3-11070 MA-1650-4 SERIES 5. The number of the fed lines after RAM clear is programmed to 4 on the remote slip printer and the receipt/journal printer. -- Refer to the sample operation on the next page -- ex.) To program the following endorsement message: Line No.1...
  • Page 133 EO3-11070 MA-1650-4 SERIES KEY STATUS PROGRAMMING (Submode 23) This submode programs the various selective statuses of media keys and other function keys. CONDITION Any time outside a sale OPERATION Mode Lock: SET 23 [X] |Key Code| [ST] |Bit Nos for SET status| [#] [AT/TL] Combination of Bit Nos 1 to 8;...
  • Page 134 EO3-11070 MA-1650-4 SERIES KEY STATUS TABLE RESET: Follow Bit 2 status / SET: TOTAL-only Key If Both RESET:allows both TOTAL and TENDER RESET: Follow Bit 1 status / SET: TENDER-only Key vacant bit SHORT-TENDERING ... RESET: Allowed / SET: Prohibited OVER-TENDERING ...
  • Page 135 EO3-11070 MA-1650-4 SERIES KEY STATUS TABLE (Continued) VALIDATION RESET: Free / SET: Compulsory MGR INTERVENTION (in REG mode) RESET: Free / SET: Compulsory TAX 1 STATUS (NOTE 2) RESET: Non-taxable / SET: Taxable TAX 2 STATUS (NOTE 2) RESET: Non-taxable / SET: Taxable...
  • Page 136 EO3-11070 MA-1650-4 SERIES KEY STATUS TABLE (Continued) NOTE 4: The following shows the Validation Compulsory status combination and the Validation Print content in case of finalizing a sale with a previous balance. KEY STATUS SELECTION RESULTING RESULTING VALIDATION Media’s New Balance’s...
  • Page 137 EO3-11070 MA-1650-4 SERIES LINK-PLU TABLE PROGRAMMING (Submode 25) This submode programs Link-PLU Tables and their respective Sub-link PLUs. When a PLU is programmed with a Link-PLU Table No. (Address 10 of the PLU TABLE PROGRAMMING operation), an entry of the PLU will automatically enter the Sub-link PLU that is programmed in the Link-PLU Table No.
  • Page 138 EO3-11070 MA-1650-4 SERIES Deletion of Link-PLU Tables CONDITION Any time outside a sale OPERATION Mode Lock: SET Repeat for othr tables to be deleted. [ITEM CORR] 25 [X] |Link-PLU Table No.| [ST] [AT/TL] [VOID] TARE TABLE AND GENERAL UNIT WEIGHT SETTING (Submode 26) In the PLU TABLE PROGRAMMING operation (Submode 4), some of Scale-compulsory PLUs may be set with a Tare Table No.
  • Page 139 EO3-11070 MA-1650-4 SERIES ex.) To set the following: STORE 1343 PEACH DRIVE Tare Table No. 1 with Tare Weight 0.13 LB, PHONE: 87-6437 General Weight 2 LB (Code 2). Open 8:00am to 7:00pm Closed: every Wednesday Mode Lock: SET, 26 [X]...
  • Page 140 EO3-11070 MA-1650-4 SERIES ex.) To set following PLU Codes to KEYs (of SFKC 96) on the ECR keyboard: STORE 1343 PEACH DRIVE Mode Lock to SET. PHONE: 87-6437 PLU Code 27 [X] Open 8:00am to 7:00pm Closed: every Wednesday 11-14-1994...
  • Page 141 EO3-11070 MA-1650-4 SERIES ECR Ordinary Type Keyboard ECR Flat Type Keyboard (V1.8 or before) - 138 -...
  • Page 142 EO3-11070 MA-1650-4 SERIES ECR Flat Type Keyboard (V1.9 or after) REPORT ITEM PRINT/NON-PRINT SETTING (Submode 28) This submode programs the items to be printed out on reports. CONDITION Any time outside a sale OPERATION Mode Lock: SET Repeat for other items.
  • Page 143 EO3-11070 MA-1650-4 SERIES ex.) To set the following item to be non-printed on reports (presumed that all the items have been set to print): STORE 1343 PEACH DRIVE PHONE: 87-6437 Tax 3 (Item Code 10) Open 8:00am to 7:00pm Tax 4 (Item Code 11)
  • Page 144 EO3-11070 MA-1650-4 SERIES REPORT ITEM NAME TABLE (Continued) Item Total/Counter Name Standard Program Code Media 7 Sales (EBT Cash) E|B|T| |C|A|S|H| | | | Media 8 Sales (EBT F/S) E|B|T| |F|/|S| | | | | Food Stamp Sales F|S| |T|L| | | | | | |...
  • Page 145 EO3-11070 MA-1650-4 SERIES REPORT ITEM NAME TABLE (Continued) Item Total/Counter Name Standard Program Code Taxable Total 4 T|X|B|L|4| | | | | | | Selective Itemizer Total 1 S|I|1| |T|L| | | | | | S|I|2| |T|L| | | | | |...
  • Page 146 EO3-11070 MA-1650-4 SERIES PLU GROUP NAME PROGRAMMING (Submode 29) This submode programs the name of each PLU Group. Which PLUs are linked to which PLU Groups has already been set in the PLU TABLE PROGRAMMING operation, Submode 4. CONDITION Any time outside a sale...
  • Page 147 EO3-11070 MA-1650-4 SERIES COMMENT MESSAGE PROGRAMMING (Submode 30) Applicable on V1.9 or after This submode programs various 10 comment messages. CONDITION Any time outside a sale OPERATION Mode Lock: SET 30 [X] |Message Code| [ST] Character Entries [ST] [AT/TL] (Max. 24 characters for...
  • Page 148 EO3-11070 MA-1650-4 SERIES DISPLAY MESSAGE PROGRAMMING (Submode 31) The “DISPLAY MESSAGE” here means the message to be displayed in the 16-digit dot windows of the Operator Display panel (and Customer Display panel if the 16-digit dot windows are installed as hardware option) while the Mode Lock of the terminal is in the “LOCK”...
  • Page 149 EO3-11070 MA-1650-4 SERIES OPERATION: Mode Lock; SET; enter 31, depress [X]. STORE 1343 PEACH DRIVE 1 [ST] (Line No.1) (3 [ST]) (Line No.3) PHONE: 87-6437 504 [#] (T) 407 [#] (G) Open 8:00am to 7:00pm Closed: every Wednesday 408 [#] (H)
  • Page 150 EO3-11070 MA-1650-4 SERIES ERROR MESSAGE PROGRAMMING (Submode 32) The messages to be set programmed here will be displayed when errors occur. Each error will be indicated with an error tone, and the Error Message (to be set here) is displayed in maximum 16 characters.
  • Page 151 EO3-11070 MA-1650-4 SERIES ERROR CODE AND MESSAGE TABLE Error Content or Cause of Error Standard Program Message Code O|P|E|R|A|T|I|O|N| |E|R|R|O|R| Operation or Key Sequence error M|A|N|A|G|E|R| |R|E|Q|U|I|R|E|D Manager Intervention required V|A|L|I|D|A|T|I|O|N| |C|M|P| | Validation required Drawer-close Compulsory error C|L|O|S|E| |D|R|A|W|E|R| | | |...
  • Page 152 EO3-11070 MA-1650-4 SERIES MEDIA PICK-UP WARNING SETTING (Submode 33) This submode sets the limit of the amount-in-drawer of each media key. When a transaction is finalized and each media-in-drawer amount exceeds the limit value set here, the message “DRAWER LIMIT” (programmable in Submode 32) is displayed with an error tone generated (NOTE).
  • Page 153 EO3-11070 MA-1650-4 SERIES FUNCTION KEY (COMBINATION KEY) SETTING (Submode 34) This submode programs a string of keys on each FUNCTION key ([FUNCTION 1] to [FUNCTION 10]). Using such programmed [FUNCTION] keys, the operator can eliminate time in various routine operation procedures.
  • Page 154 EO3-11070 MA-1650-4 SERIES NEGATIVE AMOUNT KEY LIMIT AMOUNT SETTING (Submode 35) This submode sets the limit amount to be entered through each of the negative-amount keys [VND CPN] ,[STR CPN] ,[BTL RTN] , and [DOLL DISC]. CONDITION Any time outside a sale...
  • Page 155 EO3-11070 MA-1650-4 SERIES DRAWER WARNING TIME SETTING (Submode 38) This submode sets the number of seconds as the period of time for the cash drawer remaining open until the alarm buzzer is generated to warn operator to close the drawer.
  • Page 156 EO3-11070 MA-1650-4 SERIES READ/RESET REPORT NAME PROGRAMMING (Submode 39) This submode programs the report names to be printed at the top of each READ/RESET reports. CONDITION Any time outside a sale OPERATION Mode Lock: SET Repeat for other FUNCTION keys.
  • Page 157 EO3-11070 MA-1650-4 SERIES READ/RESET REPORT NAME TABLE READ/RESET REPORT NAME TABLE Daily Read Daily Reset GTX: GT Read GTZ: GT Reset Report Report Type Standard Program X| |F|I|N|A|N|C|I|A|L| Financial Z| |F|I|N|A|N|C|I|A|L| GTX G|T|X|F|I|N|A|N|C|I|A|L GTZ G|T|Z|F|I|N|A|N|C|I|A|L All Cashier X| |C|L|E|R|K| | | | |...
  • Page 158 EO3-11070 MA-1650-4 SERIES READ/RESET REPORT NAME TABLE (Continued) Daily Read Daily Reset GTX: GT Read GTZ: GT Reset Report Report Type Standard Program X| |P|L|U| |Z|O|N|E| | Zone PLU Z| |P|L|U| |Z|O|N|E| | GTX G|T|X| |P|L|U| |Z|O|N|E GTZ G|T|Z| |P|L|U| |Z|O|N|E...
  • Page 159 EO3-11070 MA-1650-4 SERIES PLU UNIT PRICE DOLLAR DISCOUNT/EXTRA CHARGE AMOUNT SETTING (Submode 40) Applicable for V2.0 or after This submode sets the dollar discount amount or the extra charge amount for PLU price. CONDITION Any time outside a sale OPERATION Mode Lock: SET Repeat for another code.
  • Page 160 EO3-11070 MA-1650-4 SERIES AGE LIMIT SETTING (Submode 41) Applicable for V2.0 or after This submode sets an age limit to purchase a sales item restricted by the programmed age limit. CONDITION Any time outside a sale OPERATION Mode Lock: SET Repeat for another code.
  • Page 161 EO3-11070 MA-1650-4 SERIES FOREIGN CURRENCY ROUNDING PROCESS SETTING, 1-digit type (Submode 48) This submode programs the rounding process of the sale paid in foreign currencies (tendered in foreign currencies) and of the entries of No-sale Exchange from Domestic Currency to Foreign Currency. This submode is applicable to the Foreign Currencies whose option “Special Rounding for Foreign Currency APPLIED 1 digit”...
  • Page 162 EO3-11070 MA-1650-4 SERIES FOREIGN CURRENCY ROUNDING PROCESS SETTING, 2-digit type (Submode 49) This submode programs the rounding process of the sale paid in foreign currencies (tendered in foreign currencies) and of the entries of No-sale Exchange from Domestic Currency to Foreign Currency. This submode is applicable to the Foreign Currencies whose option “Special Rounding for Foreign Currency APPLIED 2 digits”...
  • Page 163 EO3-11070 MA-1650-4 SERIES CREDIT CARD NO. NEGATIVE CHECK FILE PROGRAMMING (Submode 54) In this submode, the list of Credit Card Nos to be rejected in the REG mode is programmed. This programming is available only when the expansion memory is installed.
  • Page 164 EO3-11070 MA-1650-4 SERIES BARCODE INDIVIDUAL FLAG TYPE DESIGNATION (Submode 55) This submode is available for the Scanning System type. The processes of individual flags for the UPC In-store Marking Codes are designated here. As for detailed instructions of the UPC Barcode System, refer to the Scanning Specifications in the document of System Explanation separately issued.
  • Page 165 EO3-11070 MA-1650-4 SERIES PLU ADDITION TO PLU ADDITIONAL TABLE FILE (Submode 64) This submode is used to add PLUs in the PLU Additional Table File. This programming is available only when the expansion memory is installed. CONDITION Any time outside a sale...
  • Page 166 EO3-11070 MA-1650-4 SERIES * This programming is applicable to V3.0 or after EFT KEY STATUS PROGRAMMING (Submode 65) This submode programs the various selective statuses of the EFT media keys. CONDITION Any time outside a sale OPERATION Mode Lock: SET...
  • Page 167 EO3-11070 MA-1650-4 SERIES * This programming is applicable to V3.0 or after. EFT INFORMATION SETTING (Submode 66) This submode programs the various parameters regarding the EFT process. CONDITION Any time outside a sale OPERATION Mode Lock: SET 66 [X] 1 [ST]...
  • Page 168 EO3-11070 MA-1650-4 SERIES * This programming is applicable to V3.0 or after. EFT CARD TYPE DESCRIPTOR SETTING (Submode 67) This programming programs the descriptors of the various EFT cards for the data packet. CONDITION Any time outside a sale OPERATION...
  • Page 169 EO3-11070 MA-1650-4 SERIES PC TRANSMISSION INFORMATION SETTING (Submode 68) This submode is effective for a system with a PC connection, and provides settings of various requirements for transmission with the PC. CONDITION Any time outside a sale OPERATION Mode Lock: SET...
  • Page 170 EO3-11070 MA-1650-4 SERIES PLU FILE SEQUENTIAL SORT CHECK (Submode 93) This operation sequentially executes the checks of code BCD and same code presence for the PLU file. This operation is available only when the expansion memory is installed. CONDITION Any time outside a sale...

  • Page 171: Department Preset Price Setting Or Changing

    EO3-11070 MA-1650-4 SERIES DEPARTMENT PRESET PRICE SETTING OR CHANGING The preset price of each department may be set in the DEPARTMENT TABLE PROGRAMMING (Submode 3) already described. However, in setting or changing the price only but not other programmed data, the following operation will be more convenient.
  • Page 172 EO3-11070 MA-1650-4 SERIES PLU PRESET PRICE SETTING OR CHANGING, WHOLE PACKAGE QUANTITY CHANGING The preset price of each PLU may be set in the PLU TABLE PROGRAMMING (Submode 4) already described. However, in setting or changing the price and/or the whole package quantity only but not other programmed data, the following operation will be more convenient.
  • Page 173 EO3-11070 MA-1650-4 SERIES Changing the Whole Package Quantity (and the price accordingly) CONDITION Any time outside a sale OPERATION Mode Lock: SET Barcode Scanning New Whole |PLU Code| [PLU] Package [ST] |New Preset Price| [#] [AT/TL] Quantity 6 or 13 digits Repeatable for other PLUs * Repeatable from here if the PLU Code is sequential.
  • Page 174 EO3-11070 MA-1650-4 SERIES %+ AND %- PRESET RATE SETTING A preset rate may be set on each of the [%+] and [%-] keys, one independent rate for each key. Once a rate is preset, the % key will simply be depressed without a prior rate entry to activate the preset rate. If a rate is entered prior to the depression of the key, the entered rate (manual rate) will be activated instead.
  • Page 175 EO3-11070 MA-1650-4 SERIES PRESET RATE SETTING FOR SELECTIVE ITEMIZERS (SI1 and SI2) If any of [ST1/TL] (or [SI/TL]) and [SI2/TL] keys are installed on the keyboard, a preset rate may be programmed on each key. As for the functions and applications of the Selective Itemizers, refer to the description on the next page.
  • Page 176 EO3-11070 MA-1650-4 SERIES A preset % rate may be programmed for each of SI1 and SI2 (on the preceding page), and whether the calculated amount will add to, subtract from, or non-affect the sale total is a selective option. Whether the amount resulted by depressing the [SI/TL] key will print or non-print is another selective option.

  • Page 177: Foreign Currency Exchange Rate Setting

    EO3-11070 MA-1650-4 SERIES FOREIGN CURRENCY EXCHANGE RATE SETTING In this program, the rate of each foreign currencies (corresponding to the [CUR1] to [CUR5] keys) will be set. By setting a rate on each Foreign Currency Key, reading the sale total and tendering in the foreign currency value will be possible for sale finalization.
  • Page 178 EO3-11070 MA-1650-4 SERIES ex.) To set three foreign currency rates: Domestic Currency ..U.S. $ Assigning: [CUR 1] ..French Franc [CUR 2] ..Deutsche Mark [CUR 3] ..Japanese yen Conditions given for Domestic and Foreign Currencies (The rates here are merely examples.)

  • Page 179: Tax Table Programming

    EO3-11070 MA-1650-4 SERIES TAX TABLE PROGRAMMING A maximum of four tax tables can be programmed (Tax 1, Tax 2, Tax 3, Tax 4) in accordance with installation of [TX1/M], [TX2/M], [TX3/M], [TX4/M] keys. On V1.9 or after, a rate of inclusive tax can be programmed.
  • Page 180 EO3-11070 MA-1650-4 SERIES NOTES: 1. For Tax 2, Tax 3, Tax 4 table programming, follow the same procedure in TYPE 1, 2, or 3 on the preceding page, using [TX2/M] or [TX3/M] or [TX4/M] instead of [TX1/M]. 2. If multiple tax tables are programmed, the Tax 1 table must be set first, then Tax 2, Tax 3, and Tax 4.
  • Page 181 EO3-11070 MA-1650-4 SERIES ex. 2) TAX 2 COMBINATION OF NON-CYCLIC BREAKS AND % RATE STORE 1343 PEACH DRIVE Tax Table Key Operation PHONE: 87-6437 Amount Open 8:00am to 7:00pm Closed: every Wednesday Range Levied Mode Lock: SET 11-14-1994 MON #1 $0.00 to $0.09...

  • Page 182: Gst Rate Setting

    EO3-11070 MA-1650-4 SERIES GST RATE SETTING This operation sets the rate of GST (Goods and Service Tax) in CANADA. CONDITION After Financial Daily Reset OPERATION Mode Lock: SET |GST Rate| [GST/M] 0.01 to 99.99 (%) (Use the [.] key if the decimal portion is contained.)

  • Page 183: Verification Of Programmed Data

    EO3-11070 MA-1650-4 SERIES NOTE: The preceding zeros, if entered, will not be printed. For example, if “001234” is entered in the above operation, “#1234” will always be printed as the Register No. ex.) To set the following: 3001 STORE 1343 PEACH DRIVE...

  • Page 184: Amount

    EO3-11070 MA-1650-4 SERIES 2. To read out the data of programming operations without a Submode No., the following operation will read all the data together: 1 0 0 [AT/TL] To read the data of the following operations: • % + and % - PRESET RATE •...
  • Page 185 EO8-11092 MA-1350-2 SERIES PROGRAMMING MANUAL (M/S Level)
  • Page 186 EO3-11070 MA-1650-4 M/S LEVEL PROGRAMMING MANUAL TABLE OF CONTENTS Chapter page 1. INTRODUCTION ................. 1 2. SYSTEM OVERVIEW ................. 2 3. SYSTEM START-UP PROCEDURE ........... 3 4. RTR DECLARATION, TERMINAL DESIGNATION ......5 5. MASTER-SATELLITE SYSTEM PROGRAMMING......7 6. DLLs (Down Line Loading) ............. 19 7.

  • Page 187: Introduction

    EO3-11070 MA-1650-4 SERIES 1. INTRODUCTION This programming manual describes information on programming and other related operations of the MA-1650 Master-Satellite System. Please start reading this manual after going through the MA-1650 Programming Manual for the stand-alone level. By adding the IFU Board for Master-Satellite, a Batch-consolidation or Scanning system of a maximum of 16 terminals can be built.

  • Page 188: System Overview

    EO3-11070 MA-1650-4 SERIES 2. SYSTEM OVERVIEW SYSTEM CONFIGURATION RS-232C Master Backup Master Terminal Terminal Remote Slip Printer Remote Slip Printer Scanner Scanner Scale Scale RS-485 Satellite Satellite Satellite Terminal Terminal Terminal Remote Slip Printer Remote Slip Printer Remote Slip Printer...

  • Page 189: System Start-Up Procedure

    EO3-11070 MA-1650-4 SERIES 3. SYSTEM START-UP PROCEDURE 3.1 TO START-UP USING THE MA-1650 TERMINALS ONLY <MASTER TERMINAL> <SATELLITE TERMINALS> including Backup Master Terminal RAM Clear ↓ RAM Clear ↓ RAM Allocation Setting Set M/S System selection, various In-line ID No. Setting system requirements, and allocation.
  • Page 190 EO3-11070 MA-1650-4 SERIES 3.2 TO START-UP USING A PC OR A PL-3 To perform start-up using the PC or the PL-3, refer to the stand-alone level start-up procedure. 1) When performing a DLL directed from the PC, only the terminals actually connected should be designated in the terminal list attached to the PC command.

  • Page 191: Rtr Declaration, Terminal Designation

    EO3-11070 MA-1650-4 SERIES 4. RTR DECLARATION, TERMINAL DESIGNATION 4.1 RTR (Register-to-Register) DECLARATION By depressing the [RTR] key on the Master Terminal, various in-line jobs (DLLs, Consolidated Read/Reset Report takings, etc.) can be performed. CONDITION Any time outside a sale OPERATION...

  • Page 192: Terminal Designation

    EO3-11070 MA-1650-4 SERIES 4.3 TERMINAL DESIGNATION This operation can be performed before any in-line service operation. When this operation is skipped, no specific terminals are designated, i.e., the in-line service operations will be performed to all the terminals. CONDITION Any time outside a sale...

  • Page 193: Master-Satellite System Programming

    EO3-11070 MA-1650-4 SERIES 5. MASTER-SATELLITE SYSTEM PROGRAMMING This chapter describes on settings required for the Master-Satellite System and on remarks and notes for the settings. As for the settings for the Stand-alone level, refer to the Programming Manual for Stand-alone Level.
  • Page 194 EO3-11070 MA-1650-4 SERIES Below and on the following page are the list of programming items specified to be programmable or unprogrammable in accordance with the Terminal level. Programmable / Blank: Unprogrammable S/A: Stand-alone Master Terminal (when RTR Declaration is ON) Satellite Terminal (including Backup Master and Master Terminal with RTR Declaration is OFF).
  • Page 195 EO3-11070 MA-1650-4 SERIES List of Programming Operations on Terminals (Continued) Programming Item Mode Submode Terminal Level Media Pick Up Warning Function Key Negative Amount Key Limit Drawer Warning Time Read/Reset Report Name PLU Price Dollar Discount/Extra Charge Amount Age Limit Table...
  • Page 196 EO3-11070 MA-1650-4 SERIES PLU TABLE ADDITION/CHANGE/DELETION WITH DLL (Submode 63) • For a system with the feature “PLU not to be inquired” selected The data entered on the Master Terminal is immediately loaded into the Satellite Terminals, item by item.
  • Page 197 EO3-11070 MA-1650-4 SERIES Deletion CONDITION The sales data of the required PLUs are zero and all terminals are outside a sale, programming, or report taking operations. (When the feature “PLU not to be inquired” is selected) The sales data of the required PLUs are zero, and anytime outside a sale for the Master Terminal (when the feature “PLU not to be inquired”...
  • Page 198 EO3-11070 MA-1650-4 SERIES TERMINAL CONNECTION TABLE SETTING (Submode 69) This submode is required for in-line services. Enter the In-line ID No. and the Register No. of each terminal (including the Master Terminal) connected to the in-line cable. CONDITION Any time outside a sale...
  • Page 199 EO3-11070 MA-1650-4 SERIES IN-LINE TRANSMISSION INFORMATION SETTING (Submode 70) This submode provides settings of various requirements for in-line transmission. CONDITION Any time outside a sale OPERATION Mode Lock: SET and IN-LINE Lamp illuminated 70 [X] 1 [ST] |LLR Receive Timer| [#] Max.
  • Page 200 EO3-11070 MA-1650-4 SERIES DEPARTMENT PRESET PRICE SETTING OR CHANGING WITH DLL (Submode 72) This submode is used to newly set or change preset prices to required departments, and loads the price data into Satellite Terminals. CONDITION Any time outside a sale for Master or Satellite...
  • Page 201 EO3-11070 MA-1650-4 SERIES PLU PRICE CHANGE WITH DLL (Submode 73) This submode is used to change prices of PLUs and/or the Whole Package Quantity changes of Split Package Pricing PLUs existent in the PLU Table files. CONDITION Any time outside a sale for Master or Satellite (when the feature “PLU not to be inquired”...
  • Page 202 EO3-11070 MA-1650-4 SERIES TERMINAL ID SETTING (Submode 77) This submode is available for in-line terminals (including the master and backup master terminals). It must be operated separately on each terminal since the Terminal ID should vary from terminal to terminal. The data set in this submode is used as the in-line address of the terminal for in-line service operations.
  • Page 203 EO3-11070 MA-1650-4 SERIES RAM ALLOCATION SETTING (Submode 79) This submode is almost the same as the same submode stated in the Programming Manual for the stand-alone level, except that the submode here specifies the RAM allocation in the Master-Satellite System.
  • Page 204 EO3-11070 MA-1650-4 SERIES ** Codes to designate System Setting (Combine the following four codes in a maximum of 4 digits. For example, enter 12 to designate 1 and 2.): 1: “Floating Cashier” feature is selected. 2: “PLU to be inquired” feature is selected.
  • Page 205 EO3-11070 MA-1650-4 SERIES VERIFICATION OF PROGRAMMED DATA The programmed data can be read for verification purposes. CONDITION Anytime outside a sale (Sign OFF required under Cashier Signing Method) OPERATION Mode Lock: X or SET with IN-LINE Lamp illuminated or extinguished.

  • Page 206: Dlls (Down Line Loading)

    EO3-11070 MA-1650-4 SERIES 6. DLLs (Down Line Loadings) The DLL operations will send and load the programmed data of the Master Terminal (the terminal file portion described in Chapter 7 in the Programming Manual for the stand-alone level) into the Satellite Terminals. Thus, in an in-line system, program data are mostly generated or changed on the Master Terminal, and the Satellite Terminals only wait for the data sent from the Master Terminal through DLL operations.
  • Page 207 EO3-11070 MA-1650-4 SERIES 2. For those data programmed with no Submode No., operate the following for DLLs: 5 0 0 [AT/TL] “500” is fixed for DLLs of the following programmed contents: • Percent Rate • Selective Itemizer Rate • Foreign Currency Rate •...
  • Page 208 EO3-11070 MA-1650-4 SERIES DLL Job List DLL Item Code Condition Remarks SFKC After all Daily & GT The DLL is not executed to termi- Resets nals with a different keyboard type. Store Name/Message, Commercial Anytime Message Cashier Code & Name After All Cashier Operable only when the “Non-float-...
  • Page 209 EO3-11070 MA-1650-4 SERIES DLL Job List (Continued) DLL Item Code Condition Remarks Function Key Anytime It is not loaded to terminals pro- grammed with a keyboard of any key layout different from that of the Master. Negative Amount Key Limit...

  • Page 210: Print Format Of Dll Operations

    EO3-11070 MA-1650-4 SERIES DISPLAY INDICATIONS OF DLL OPERATIONS The followings are displayed in the 16-digit dot windows, 10-digit 7-segment window, and IN-LINE Lamp of the Operator Display panel during a DLL execution: <Master Terminal> blink SLIP DLL Code IN-LINE Illuminated...

  • Page 211: Reservation And In-Line Reports

    EO3-11070 MA-1650-4 SERIES 7. RESERVATION AND IN-LINE REPORTS As for Reservation and In-line Read/Reset reports in the Master-Satellite System, refer to the MA-1650 Owner’s Manual (for Master-Satellite System). - 25 -...

  • Page 212: Inquiries

    EO3-11070 MA-1650-4 SERIES 8. INQUIRIES This chapter describes various inquiries made from each terminal to the Master Terminal and affect data (sales data updating). 8.1 PLU INQUIRIES When the feature “PLUs to be inquired” is selected and a PLU is entered in a sale (entered manually or through a barcode) on each terminal, the terminal inquires the PLU to the Master Terminal.

  • Page 213: Cashier Occupy Inquiries

    EO3-11070 MA-1650-4 SERIES AFFECT When a Customer File entry is determined on a terminal, the terminal sends an AFFECT text to the Master terminal (and Backup Master Terminal), and updates the sales data of the Master Terminal (and Backup Master Terminal).

  • Page 214: Backup Data Control

    EO3-11070 MA-1650-4 SERIES 9. BACKUP DATA CONTROL 9.1 OVERVIEW OF BACKUP FUNCTION By connecting a Backup Master Terminal (Terminal ID No. 2) to the Master-Satellite System, the Center File in the Master Terminal will be backed up. Thus, if the Master Terminal becomes down, the Backup Master can replace the Master function to continue operation.
  • Page 215 EO3-11070 MA-1650-4 SERIES 9.3 SALES DATA UPDATE PROCESS When sales data has been entered on a terminal, the terminal sends AFFECT data to the Master Terminal to update the sales data in the Center File. Then the terminal sends the same data to the Backup Master Terminal to update the Backup Data also.
  • Page 216 EO3-11070 MA-1650-4 SERIES While the Backup Error Flag is ON, the following actions will be made: 1) Every time a long receipt is issued from the Master Terminal, a short buzzer tone is generated to warn the operator of the Backup Error occurrence.

  • Page 217: Transaction Data Capture

    EO3-11070 MA-1650-4 SERIES 10. TRANSACTION DATA CAPTURE The Transaction Data Capture function is possible when the features of “PC Connected” and “With Transaction Data Capture Function” are both selected in System Options. This function enables to store details of sale entries made on each terminal into the Master Terminal as transaction data, and to transfer the data by request of the PC.

  • Page 218: Transmission Error

    EO3-11070 MA-1650-4 SERIES 11. TRANSMISSION ERROR When a terminal makes an inquiry but a communication error occurs for some reason and the inquiry to the other station is not possible, the message “IRC CONNECT ERR” (standard program; programmable) is displayed on that terminal and operation is stopped.

  • Page 219: Error Canceling Process

    EO3-11070 MA-1650-4 SERIES MASTER IS BUSY <16-digit Dot Windows> NOTE: The display contents in the 7-segment portion remains the same as before the error occurrence. The error status will be canceled by the [C] key. 11.3 ERROR CANCELING PROCESS There are two error-canceling processes in accordance with the inquiring job contents.

  • Page 220: Other In-Line Operations

    EO3-11070 MA-1650-4 SERIES 12. OTHER IN-LINE OPERATIONS The following are other operations relating to in-line service operations but not described in the preceding chapters. TABLE OF CONTENTS page TIME OUT ............................34 SUSPENDING ..........................35 RETRY ............................35 INCOMPLETE ENDING ......................... 35 CANCEL ............................

  • Page 221: Time Out

    EO3-11070 MA-1650-4 SERIES TIME OUT A Time-Out condition arises when the Master Terminal is making an in-line service operation, such as X/Z report collection, DLL, etc. to the Satellite Terminals. The service timer is provided for servicing each of the Satellite Terminals, thus on exceeding the time limit, a Time-Out condition will occur.

  • Page 222: Suspending

    EO3-11070 MA-1650-4 SERIES SUSPENDING This is to be operated for the purpose of suspending an in-line service being executed, when any terminals remain unserviced, and of going on to a “RETRY”, “INCOMPLETE ENDING”, or “CANCEL” operation as the next step.

  • Page 223: Cancel

    EO3-11070 MA-1650-4 SERIES As part of the print out, the Store/Reg. No. of the terminal and its status will be printed. Status Print Format No nnnnnn ? Store/Register No. Status Symbol No response (power off, etc.) BUSY: The terminal is busy (during a sale, etc.)

  • Page 224: Terminal Open Check

    EO3-11070 MA-1650-4 SERIES TERMINAL OPEN CHECK This operation sends a dummy text to those terminals set in the TERMINAL CONNECTION TABLE (Submode 69), and prints out the Register Nos. of the disconnected terminals (i.e. terminals not responding). CONDITION Any time outside a sale (operable on Master Terminal)

  • Page 225: Terminal Condition Check

    EO3-11070 MA-1650-4 SERIES TERMINAL CONDITION CHECK This operation checks the condition of the designated terminals, and prints out the status responded from the terminals. CONDITION Any time outside a sale (operable on Master Terminal) OPERATION Mode Lock: X and IN-LINE Lamp illuminated...

  • Page 226: Enforced Clear Of Hold Condition

    EO3-11070 MA-1650-4 SERIES ENFORCED CLEAR OF HOLD CONDITION (on Individual Terminals) When a Master job execution is under way (DLL, Consolidated Read/Reset, etc.), the Master Terminal or the PC suddenly becomes down, accordingly the connected terminals turns into HOLD condition, and the HOLD condition cannot be cleared.

  • Page 227: Read Of Information Already Copied In Communication Buffer (Only For A System With The Cvs Spec. Selected)

    EO3-11070 MA-1650-4 SERIES READ OF INFORMATION ALREADY COPIED IN COMMUNICATION BUFFER This operation issues report names of which sales data have been already copied in the communication buffer. CONDITION Anytime outside a sale OPERATION Mode Lock: X 96 [AT/TL] NOTE: The following contents are printed.
  • Page 228 EO3-11070 MA-1650-4 SERIES Reference: MA-1650-4 Allocation Capacities Allocation items and the number of bytes per record are shown in the following. Item Number of bytes/record Cashier 2.683 (Local & Center Files) (Local & Center Files) Check Track (Local & Center Files)

Table of Contents
