Model APS-901E
Owner's Manual
Single Channel Remote Car Starter
FEATURES:
2 Programmable RF Transmitter
Single Channel Receiver (capable of accepting 4 transmitters)
External Receiver Antenna w/Push Button Switch & LED
On-Board Start Relay
On-Board Accessory Relay
On-Board Ignition 1 Relay
On-Board Ignition 2 Relay
Ignition 2 Relay Selectable On or Off During Cranking
On-Board Parking Light Relay
Ignition 3 / Shock By-Pass / GM VAT Output (relay required)
Tach Signal Learning Circuit
Two ( + ) and Two ( - ) Safety Shutdown Circuits
Alarm By-Pass Output
Accessory Outputs (Pulse Before & After Start, During Crank & After Shut Down)
Selectable Steady or Flashing Parking Lights for Run Indication
Selectable 5, 10, 15, 20, 45, and 60 Minute Run Time
Optional Door Unlock Feature For Vehicles Equipped With Power Doors
(Only operational while running under control of the remote start unit.)
PATENTED: www.voxxintl.com/company/patents
1
128-9299
1 of 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the APS-901E and is the answer not in the manual?

Questions and answers

Related Manuals for Prestige APS-901E

Summary of Contents for Prestige APS-901E

  • Page 1 Model APS-901E Owner’s Manual Single Channel Remote Car Starter FEATURES: 2 Programmable RF Transmitter Single Channel Receiver (capable of accepting 4 transmitters) External Receiver Antenna w/Push Button Switch & LED On-Board Start Relay On-Board Accessory Relay On-Board Ignition 1 Relay...
  • Page 2 As a visual indication, the parking lights will flash or remain on depending on the setting by PRESTIGE your installation center. 2) When you arrive at the vehicle, turn the ignition key to the ON position (not the spring loaded start position), then step on the brake pedal to disengage the remote starter.
  • Page 3 UNLOCKING THE VEHICLE: If you have electric door lock, and the Optional Unlock feature was added, with the vehicle running under command of the remote start unit, press and hold the transmitter button for 3 seconds until the doors unlock. CAR FINDER MODE: Anytime the vehicle is not running under control of the remote start unit, within operating range of the vehicle, press and hold the push-button of the hand held...
  • Page 4 Transmitter Battery Replacement 1) Locate and remove the "00" point Phillips head screw on the back of the transmitter case. 2) Carefully separate the front case from the rear. 3) Slide the CR2032 battery out from under the battery clip and dispose of properly. 4) Install the new battery with the (+) side facing up away from the circuit board.
