Table Of Contents:
Features and Options
Arming Your System
Protection While Armed
Disarming Your System
Intrusion Signals and Tones
Valet Override, Programming & Safety Control Switch
Programming Custom Code Override
Eliminating the Normal Arm & Disarm Chirps
Remote Panic Operation
Remote Control Shock Sensor Selection
Vehicle Service/Remote Start override Mode
Remote Starting Your Vehicle
Automatic Start Timer Operation
Optional Device Channels
Turbo Timer Operation
Telematic Upgrade
Two Way Remote (Transceiver) Screen Icons & Indications
24 Hour Timed Start Setup, Operation, and Use
Temperature Start Mode Operation
Two Way Remote Function Program Chart
Functions At A Glance
Replacement or Additional Transmitters Programming
PATENTED: www.voxxintl.com/company/patents
Model APS-997EC
Owners Guide
2 Way LCD Long Range Vehicle
Security
& Remote Start System
Page 1
Page 2 - 4
Page 4
Page 5
Page 5 - 6
Page 6 - 7
Page 7
Page 7 - 9
Page 9
Page 9
Page 10 - 11
Page 11
Page 11 - 12
Page 12 - 13
Page 13 - 15
Page 15
Page 15
Page 15 - 21
Page 21
Page 21
Page 22
Page 23
Page 24
128-9309
1 of 24
Advertisement
Related Manuals for Prestige APS-997EC
Summary of Contents for Prestige APS-997EC
- Page 1 Model APS-997EC Owners Guide 2 Way LCD Long Range Vehicle Security & Remote Start System Table Of Contents: Features and Options Page 2 - 4 Arming Your System Page 4 Protection While Armed Page 5 Disarming Your System Page 5 - 6...
- Page 2 5 Button Remote Start Security System With Plug-In Shock Sensor & Starter Disable IMPORTANT! In order to provide you with the highest level of security to your vehi- cle, this system is equipped with selectable manual override circuitry. It is possible that you will need to override you security system if the transmitter becomes lost, or inoperative due to battery failure.
- Page 3 True Last Door Arming (Hardwire Only) Defective Zone By-Pass Defective Zone Chirp Confirmation (Unit Chirps To Report Zone Cleared) 6 Tone Mini Siren Car Horn Output For Additional Alarm Response (Improved Timing To Minimize RF Interference.) ...
- Page 4 theif to grab and rebroadcast your code. If your transmitter button is pressed more than fifty times while it is out of range of the vehicle (children playing with your keys), the transmitter will not operate when you return to the vehicle, and will need to be re-aligned to the receiver.
- Page 5 ARMING THE SYSTEM - PASSIVE (AUTOMATIC) (Must be activated during programming) 1. Turn off the engine, exit the vehicle and close and lock all doors, hood lid and trunk lid. The dash mounted LED begins to flash rapidly, indicating 30 second passive arming has begun.
- Page 6 transmitter button is activated, the drivers door only will unlock, pressing the unlock button a second time will cause all doors to unlock. NOTE: If your transmitter has been configured with single button Lock/Unlock, to activate the all door unlock feature operate the Lock/Unlock button a second time within 3 seconds of the first unlock command.
- Page 7 INTRUSION WARNING SIGNALS This system will inform you if an intrusion attempt has occurred while you were away from the vehicle. If an intrusion attempt has occurred, the siren will chirp 4 times and the parking lights will flash 3 times when disarming the system. Enter the vehicle and observe the red dash mounted LED to identify which zone was triggered.
- Page 8 PROGRAMMING YOUR CUSTOM OVERRIDE CODE Unlike override switches easily found, and defeated, this security system allows the consumer to program a personal override code, offering a higher level of security. To take advantage of this option, programmable feature # 9 must be selected for the Custom Code Option.
- Page 9 You will notice the LED flashing five times, pause, and then flash two times, pause. This pattern will be repeated three times indicating the new code (52) has been accepted and stored in memory. NOTE: If after step 7, the LED flashes a code other than what was just entered, this indicates that the code has not been changed.
- Page 10 REMOTE PANIC OPERATION The Lock or Unlock button on your keychain transmitter also functions as a panic switch for use in emergency situations. To use remote panic, 1. Press and hold the Lock or Unlock button on the keychain transmitter for 3 or more seconds.
- Page 11 keychain transmitter. 1. Within 2 seconds of arming, press and release the ARM button 1 time, to defeat the pre-detect stage of the shock sensor. (The lights will flash and the siren will chirp once.) 2. Within 2 seconds of step 1, press and release the ARM button 2 times, to defeat the pre and full detect stages of the shock sensor.
- Page 12 TO REMOTE START THE VEHICLE Press and release the programmed channel of your keychain transmitter two times within 2 seconds. The vehicle will start and remain running for the pre-programmed 5, 10, 15, or 20 minutes. As a visual indication, the parking lights will flash or turn on depending on the programming set up by your installation center.
- Page 13 second channel transmitter button 2 times. 2. Shut off the vehicle using the keychain transmitter by pressing and releasing the second channel transmitter button 2 times. 3. Within 10 seconds of step 2, activate the RF start command two times (Push the second channel button of your keychain transmitter 4 times).
- Page 14 Other Transmitter button configurations are also available. Consult your installation center for other configurations not listed above that may have been programmed to operate a specific feature of your system. This security system has an additional feature that can be connected to a number of different optional accessories.
- Page 15 Other Transmitter button configurations are also available. Consult your installation center for other configurations not listed above that may have been programmed to operate a specific feature of your system. This security system has an additional feature that can be connected to a number of different optional accessories.
- Page 16 When Disarmed, Press the Arm/Lock button to Lock and Arm the System. The Lock Icon is displayed on the LCD panel & the parking lights flash once. When Armed, Press the Disarm/Unlock button to Unlock and Disarm the System. The Unlock Icon is displayed on the LCD panel & the parking lights flash twice.
- Page 17 Triggered and entry attempt was made to the vehicles glass, or the vehicle has been hit or bumped hard enough to cause a response from the vibra- tion detector. ADDITIONAL ICONS THAT MAY BE DISPLAYED ARE: If the arm/disarm ch i r p to ne s h a ve b e e n tu rn e d o ff a t th e vehicle, when you arm, or disarm, the display will indicate this as shown and there will be no arm/disarm chirps at the transmitter.
- Page 18 ADDITIONAL REMOTE FEATURES: The two way remote control unit allows you to PRESTIGE access status information from the vehicle, check temperature, light the display, toggle the transmitter Trunk Release/ Remote Start from beep tones to vibrate mode, initiate daily start...
- Page 19 To activate this function, (a) Turn the ignition switch off. (b) Within 10 seconds of step (a), depress and hold the brake pedal, while press- ing the key icon transmitter button 2 times. (c) the unit will emit 2 chirps, the transmitter will beep and the 24 Hour start timer icon on the display will remain on.
- Page 20 PRESTIGE plicable. The option button and any button com- bination may be programmed to operate various options. Consult your installation center for button programming and options that may have been INHIBIT added to your vehicle.
- Page 21 24 HOUR START TIMER Standing at the vehicle at the time you want it to start, press the option + lock buttons simultaneously for 1 seconds. The transmitter will beep and display the 24 hr timer. This is the time the vehicle will start when you fol- low the exit procedure.
- Page 22 TRANSMITTER TRANSMITTER ICON TONE/VIBRATE FUNCTION BUTTON DISPLAYED SELECTION PRESS FOR 18:88 TIMING ADJUST 2 BEEP TONES 5 SECONDS MODE (HRS) TIMING ADJUST 18:88 USE KEY BUTTON OR OPTION PRESS 1X BUTTON TO SELECT MODE (MINS) ALARM CLOCK 18:88 USE KEY BUTTON OR OPTION PRESS 2X ADJUST MODE (HRS) BUTTON TO SELECT...
- Page 23 APS 997E SYSTEM FUNCTIONS AT A GLANCE DASH LED INDICATORS RAPID FLASHING PASSIVE ARMING/ACTIVE REARMING SLOW FLASHING ARMED DISARMED ON SOLID VALET MODE 3 FLASH...PAUSE INTRUSION ZONE 3 2 FLASH...PAUSE INTRUSION ZONE 2 1 FLASH...PAUSE INTRUSION ZONE 1 SIREN CHIRP INDICATORS 1 CHIRP * 2 CHIRPS * DISARM...
- Page 24 2 receiver channels at the same time. This unit's transmitters can control two vehicles with with Prestige Remote Systems. To toggle primary or secondary vehicle press trunk/key & option for 5 seconds.
