Thank you for trusting Prestige products! If you are a consumer, please note:
Professional installation is strongly recommended.
This manual assumes the installer has adequate knowledge of the following expertise. Therefore, it does not
cover these topics in detail:
•
12-volt electronics
•
Testing and verifying circuits
•
Making safe and lasting wiring connections
•
Factory ignition, power, lighting, data bus and sensing systems
•
Factory systems and components to avoid
•
Safe wire routing, circuit protection and product placement
•
Access to vehicle-specific technical information
In addition, this manual assumes the installer has the proper tools, skill and facilities to perform a professional installation.
Performing an improper installation could result in damage to the vehicle or its components, improper system function,
unsafe vehicle operation or physical injury. Such instances would not be covered by the vehicle manufacturer's warranty,
nor by Voxx Electronics, Inc.
2
Wire Harness Colors and Functions
2
3
4
7
7
7
RF Antenna Kit
7
7
8
8
9
13
17
19
AUX Output Control
20
PIC Input Control
21
21
22
2022 Voxx Electronics Corporation. All rights reserved.
APS997ZLR
Vehicle Security / Remote Start System
Installation and Reference Guide
23
Setup Options
23
Programming Mode Entry / Exit
24
25
Programming & Diagnostics
25
25
25
26
2 / 4 Hour Timer
26
26
27
27
27
27
28
Alarm Override Procedures
29
Wiring Diagrams
29
32
Starter Kill Relay
33
Full System Connections
APS997ZLR_RevA_05/22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the APS997ZLR and is the answer not in the manual?

Questions and answers

Related Manuals for Prestige APS997ZLR

Summary of Contents for Prestige APS997ZLR

  • Page 1: Table Of Contents

    Vehicle Security / Remote Start System Installation and Reference Guide Thank you for trusting Prestige products! If you are a consumer, please note: Professional installation is strongly recommended. This manual assumes the installer has adequate knowledge of the following expertise. Therefore, it does not cover these topics in detail: •...

  • Page 2: Detailed Descriptions

    Detailed Descriptions: Wire Harness Colors and Functions Power Connector (8-pin High-Current Connector) See page 33 for the full system diagram. These wires are listed in order of their placement in the harness connector. 1. RED/BLACK – Ignition 3, Flex Relay Input (Internal Relay Pin 87) The RED/BLACK wire is used to supply the Pin 2 - PINK Flex Relay Output.

  • Page 3: Alarm / Notification Connector

    Detailed Descriptions: Wire Harness Colors and Functions Power Connector (8-pin High-Current Connector) (Cont) See page 33 for the full system diagram. These wires are listed in order of their placement in the harness connector. 7. PURPLE – Accessory Output (+) At its default setting, the Purple wire supplies 12-Volt (+) to the vehicle’s accessory wire to power vehicle accessories during remote start.

  • Page 4: Input / Output Connector

    Detailed Descriptions: Wire Harness Colors and Functions Input / Output Connector (22-pin connector) See page 33 for the full system diagram. These wires are listed in order of their placement in the harness connector. 1. ORANGE – Starter Kill Output (-) The ORANGE wire supplies Ground (-) when the alarm is armed and when the remote start is ON.
  • Page 5 Detailed Descriptions: Wire Harness Colors and Functions Input / Output Connector (22-pin connector) (Cont.) See page 33 for the full system diagram. These wires are listed in order of their placement in the harness connector. 10. ORANGE/BLACK – Parking Brake Input (-) (PIC4) The ORANGE/BLACK wire connects to the vehicle’s parking brake wire to supply parking brake status for remote start.
  • Page 6 Detailed Descriptions: Wire Harness Colors and Functions Input / Output Connector (22-pin connector) (Cont.) See page 30 for the full system diagram. These wires are listed in order of their placement in the harness connector. 20. RED – Door Lock (-) (NOC 10) The RED wire supplies Ground (-) when the Lock function is activated from the remote control or system.

  • Page 7: External Components

    Shock Sensor The shock sensor plugs into a 4-pin connector on the Prestige module. It should be securely attached to a vehicle surface or sturdy wire harness. Testing takes place after all connections are made and the system is powered up.

  • Page 8: Setup Options

    Detailed Descriptions: Setup Options Bank 1: Add / Remove Remote Controls Remote programming is located in Feature Bank 1. This system will Auto Program basic functions of the remote with one (1) button press. Basic functions are channels 1-3, Lock, Unlock, and Trunk / Start. Feature Bank 1 Descrip�on 1 Auto Program/Lock...

  • Page 9: Security Control

    Detailed Descriptions: Setup Options Security Control (Bank 2) See page 23 for Programming Instruction. Op�ons Feature Bank 2 1 Chirp 2 Chirp 3 Chirp 4 Chirp 5 Chirp 6 Chirp 500ms 1 Lock / Unlock Func�on 3.5sec 500ms L, DBL UL DBL L, 500ms UL DBL L, DBL UL 500ms L, 350ms UL...
  • Page 10 Detailed Descriptions: Setup Options Security Control (Bank 2) (cont.) See page 23 for Programming Instruction. Feature 5: Auto ReLock Setting Function: Set the doors to re-lock if the system has been accidentally disarmed. Setting Choices: • Option 1 - Auto ReLock is disabled. •...
  • Page 11 Detailed Descriptions: Setup Options Security Control (Bank 2) (Cont.) See page 23 for Programming Instruction. Feature 10: Driver Priority Unlock Function: Set the behavior of unlock outputs when arming and disarming the system. Setting Choices: • Option 1 - Unlock pulse will be on the Green wire unlock output only. •...
  • Page 12 Detailed Descriptions: Setup Options Security Control (Bank 2) (Cont.) See page 23 for Programming Instruction. Feature 16: Dome Light Delay Timer Function: Set the delay timer when using the vehicle's Dome Light as a door trigger. Setting Choices: • Option 1 - OFF / Delay Timer will be OFF or use the programmed time. See page ## for dome light delay programming procedure •...

  • Page 13: Remote Start Control

    Detailed Descriptions: Setup Options Remote Start Control (Bank 3) See page 23 for Programming Instruction. Op�ons Feature Bank 3 1 Chirp 2 Chirp 3 Chirp 4 chirp 5 Chirp 6 Chirp Pulsed 1 Defrost Output 10min RS Run�me 2 RS Start No�fica�on 3 RS Run�me 15min 20min...
  • Page 14 Detailed Descriptions: Setup Options Remote Start Control (Bank 3) (cont.) See page 23 for Programming Instruction. Feature 5: Engine Confirmation Mode Function: Determine how the system knows if remote start was successful. Setting Choices: • Option 1 - Determined by measurement from the Purple/White Tach Input wire. •...
  • Page 15 Detailed Descriptions: Setup Options Remote Start Control (Bank 3) (cont.) See page 23 for Programming Instruction. Feature 12: Diesel (Pre-Start) Delay Function: After remote start ignition is activated, set delay of crank to accommodate diesel engines. Setting Choices: • Option 1 - Vehicle starts immediately after remote start ignition. •...
  • Page 16 Detailed Descriptions: Setup Options Remote Start Control (Bank 3) (Cont.) See page 23 for Programming Instruction. Feature 17: Remote Start Activation Function: Set remote start to activate with one, two, or three presses from the remote control or pulses detected on the Dark Blue/Black External Activation Input.

  • Page 17: Negative Output Control (Noc)

    Detailed Descriptions: Setup Options Negative Output Control (NOC) Negative Output Control (NOC) allows the installer to program any NOC output for any NOC option. For example, if an installer is not using the GREEN/WHITE Dome Light output, but requires a second Remote Start Status Output, the system can be programmed to change the output type.
  • Page 18 Detailed Descriptions: Setup Options Negative Output Control (NOC) (CONT.) Pulse During Crank This option supplies a pulse to crank the engine's starter. This output will pulse for the timing option selected in Feature Bank 3, Feature 11. Pulse After Shutdown This option supplies a pulse after remote start shutdown only.
  • Page 19 Detailed Descriptions: Setup Options Auxiliary Output Control (AUX Control) Auxiliary (AUX) output control allows each AUX Channel output to be customized to the user or vehicle's need. See the list below for a detailed description of the available options. AUX Ch. Outputs can only be programmed using the FlashLogic Weblink or Weblink Mobile.
  • Page 20 Detailed Descriptions: Setup Options Programmable Input Control (PIC Control) Programmable Input Control (PIC) allows each PIC input to be customized to the user or vehicle's need. See the list below for a detailed description of the available options. PIC Inputs can only be programmed using the FlashLogic Weblink or Weblink Mobile.

  • Page 21: System Operation

    2. Release the vehicle's foot brake. 3. Activate the Prestige remote start by pressing the Start button on the remote control or Carlink App. The vehicle parking lights will illuminate to indicate the remote start is activated. If you are using a 2-Way remote, the remote will beep four (4) times.

  • Page 22: Remote Operation

    Detailed Descriptions: System Operation Remote Control Operation This system is compatible with multiple different remote configurations; one (1) button, five (5) button, and LCD remotes. The matrix below describes how each remote offering will control the basic system functions. See Owner's Guide for more detailed information Five Button Remotes (2-Way LED) Button...

  • Page 23: Quick Reference

    Quick Reference: System Programming Programming Mode Entry and Exit Procedure Once the system is installed and powered up, you will use the vehicle ignition, override button and a programmed remote control to set all system options. Feature options are divided into categories, or Banks, as described throughout this section.

  • Page 24: Feature Bank Options

    Quick Reference: Setup Options Bank 1: Transmitter Programming Options See page 8 for a detailed description. Feature Bank 1 Descrip�on 1 Auto Program/Lock Press Lock bu�on on remote 2 Unlock Press Unlock bu�on on remote 3 Trunk/Start Press Trunk/Start bu�on on remote 4 Ch.

  • Page 25: Data Port Protocol Selection

    Note: Programming tach signal via OEM or Telematics control is only available on Firmware v1.47 or Higher. Dome Light Delay To program the Prestige system to wait until the dome light turns off before arming: 1. Close all doors. 2. With the vehicle ignition off, press LOCK, UNLOCK, LOCK ,UNLOCK, LOCK, UNLOCK, LOCK on the remote control. The dash-mounted LED will turn on.

  • Page 26: Turbo Timer

    To prevent the Turbo Timer feature from engaging, press and hold the brake pedal while setting the vehicle's Ignition to the OFF position. Silent Arm and Disarm Program the Prestige system to arm and disarm without notification beeps. (The siren will sound if the system is triggered while armed.) 1. Turn the ignition ON then OFF.

  • Page 27: User Selectable Led

    2 Trunk / Hood 3 Door Troubleshooting Remote Start All Prestige remote start system will provide parking light feedback to display remote start errors or shutdowns. The vehicle parking lights will flash to display error or shutdown code. 1 Run�me Expired...
  • Page 28 Quick Reference: Alarm Override Procedures Valet Alarm Override The Valet Override procedure will disable the alarm when the remote control is not available or has become inoperative. If the vehicle door is opened without disarming, the alarm will sound and the vehicle will not start when attempting to start with the key.

  • Page 29: Door Lock Connections

    Quick Reference: Wiring Diagrams Door Lock Connections Negative-Trigger Door Locks Verification: The vehicle wires register Ground when the Lock and Unlock switches are activated. RED ( - ) Lock Output Lock Vehicle Door Lock Control Relays Unlock GREEN ( - ) Unlock Output Positive-Trigger Door Locks Verification: The vehicle wires register 12V+ when the Lock and Unlock switches are activated.
  • Page 30 Quick Reference: Wiring Diagrams Door Lock Connections Single-Wire Negative Multiplex Door Locks (Relays required) Verification: The vehicle wire registers variable Ground values when the Lock and Unlock switches are activated. Please consult the vehicle-specific wire and location chart for resistor values. Ground Fused +12 Volt RED ( - ) Lock Output...
  • Page 31 Quick Reference: Wiring Diagrams Door Lock Connections Reverse-Polarity Door Locks (Relays required) Verification: The vehicle wires rest at Ground and register 12V+ when the Lock and Unlock switches are activated. Fused +12 Volt Battery Souce RED ( - ) Lock Output Lock To Door Lock Motor Unlock...
  • Page 32 Quick Reference: Wiring Diagrams Starter Kill / Anti-Grind Relay Connections Starter Kill / Anti-Grind Relay (Optional) To ORANGE - Starter Kill / To Vehicle Ignition Anti-Grind Output (-) From Alarm APS997ZLR_RevA_05/22...
  • Page 33 Quick Reference: Wiring Diagrams VOXX APS997ZLR_RevA_05/22...
