Prestige APS901TWE Owner's Manual

Single channel remote car starter

Single Channel Remote Car Starter

FEATURES :

1 Programmable RF Transmitter, 1 Programmable RF Transceiver

Single Channel Receiver (capable of accepting 4 transmitters)

External Spread Spectrum Transceiver w/PushButton Switch & LED

On-Board Start Relay

On-Board Accessory Relay

On-Board Ignition 1 Relay

On-Board Ignition 2 Relay

Ignition 2 Relay Selectable On or Off During Cranking

On-Board Parking Light Relay

Ignition 3 / Shock By-Pass / GM VAT Output (relay required)

Tach Signal Learning Circuit

Two ( + ) and Two ( - ) Safety Shutdown Circuits

Alarm By-Pass Output

Accessory Outputs (Pulse Before & After Start, During Crank & After Shut Down)

Selectable Steady or Flashing Parking Lights for Run Indication

Selectable 5, 10, 15, 20, 45, and 60 Minute Run Time

Car Finder Mode

Optional Door Unlock Feature For Vehicles Equipped With Power Doors

(Only operational while running under control of the remote start unit.)

PATENTED: www.voxxintl.com/company/patents

Model APS901TWE

Owner's Manual

128-9473

1 of 4

Table of Contents

Need help?

Do you have a question about the APS901TWE and is the answer not in the manual?

Page 1 Model APS901TWE Owner’s Manual Single Channel Remote Car Starter FEATURES : 1 Programmable RF Transmitter, 1 Programmable RF Transceiver Single Channel Receiver (capable of accepting 4 transmitters) External Spread Spectrum Transceiver w/PushButton Switch & LED On-Board Start Relay On-Board Accessory Relay...
Page 2 2 seconds. The vehicle will start and remain running for the pre-programmed time of up to a 60 minute run PRESTIGE cycle. As a visual indication, the parking lights PRESTIGE will flash or remain on depending on the setting by your installation center.
Page 3 UNLOCKING THE VEHICLE: If you have an electric door lock, and the Optional Unlock feature was added, with the vehicle running under command of the remote start unit, press and hold the transmitter button for 3 seconds until the doors unlock. CAR FINDER MODE: Anytime the vehicle is not running under control of the remote start unit, within operating range of the vehicle, press and hold the push-button of the hand held...
Page 4 FUNCTION SETTING CHART To be completed by installer: Run Time 5 Min 10 Min 15 Min 20 Min 45 Min 60 Min While Running Unlock Yes  No  Lights Pulse  Steady  CAUTION! A running vehicle produces dangerous carbon monoxide gas which can be fatal if prolonged exposure occurs.
