- Page 1 128-7765 1 of 19...
- Page 2 To program these selectable features; Action System Response Turn ignition on No response Press and release the valet switch 3 times 1 Chirp - LED 1 flash Within 3 seconds, turn ignition Off Then On Short chirp, then long chirp This Action Accesses Feature Bank 2 Alarm Selectable Features First Press and release the valet switch 1 time...
- Page 3 128-7765 3 of 19...
- Page 4 Action System Response Turn ignition on No response Press and release the valet switch 3 times 1 Chirp - LED 1 flash Within 3 seconds, turn ignition Off, On, Off, On Short chirp, then 2 long chirps This Action Accesses Feature Bank 3 Remote Start Selectable Features First Press the valet switch one time 1 chirp = defrost output pulsed...
-
Page 5: Installation Of The Major Components
This Remote Start System is designed for use with Automatic Transmission Vehicles Only! The unit provides wait to start input for glow plug pre-heat which will be used for all diesel applications. If this wire is not connected, then the unit will remain in the Gasoline mode setting, which will crank the car when the RF signal is received with no delay. -
Page 6: Wiring The 6 Pin Main Power Harness
I M P O R T A N T ! DO NOT PLUG THE SIX PIN MAIN POWER HARNESS OR THE MULTI PIN INPUT / OUTPUT HARNESS INTO THE CONTROL MODULE UNTIL ALL CONNECTIONS TO THE VEHICLE HAVE BEEN MADE. AFTER SELECTING YOUR TARGET WIRES AS DEFINED BELOW, DISCONNECT THE NEGATIVE BATTERY CABLE FROM THE VE- HICLE BATTERY PRIOR TO MAKING ANY CONNECTIONS. - Page 7 SEE NEUTRAL START SAFETY TEST FOR FURTHER DETAILS. BLUE WIRE: Ignition 1 Output Connect this wire to the ignition 1 wire from the ignition switch. This wire will show +12 volts when the ignition key is turned to the to the "ON" or "RUN" and the "START" or CRANK" positions and will have 0 volts when the key is turned to the "OFF"...
- Page 8 Connect this wire to the Accessory wire from the ignition switch. This wire will show + 12 volts when the ignition switch is turned to the "ACCESSORY" or "ON" and "RUN" positions and will show 0 volts when the key is turned to the "OFF"...
- Page 9 Brake Switch Positive Shutdown Detail YELLOW w/ BLACK Tracer Wire: + 12 Volt Alarm By - Pass Output NOTE: You must disconnect the ignition input of the alarm from any other wire that it is presently connected to in the vehicle. This wire provides a + 12 Volt output when the ignition key is turned to the “ON”...
- Page 10 the applications described below, a relay will be required. The Light Blue wire can be used to accommodate the following situations: A. Shock Sensor By Pass: If there is Shock Sensor used with an alarm system and it is not shunted during the Remote Start activation period, then vibration from the running vehicle can cause the alarm to trigger.
-
Page 11: Wiring The 4 Pin Auxiliary Output Harness
cases will operate properly from one multi coil pack regardless of the number of cylinders. If the vehicle has a single coil unit for each cylinder, it may be necessary to connect this wire to more than one cylinder for proper tach reference. - Page 12 2 Pin Transponder Control Output: (Yellow Connector) This output is intended to allow the control of a transponder bypass interface module or transponder bypass relay. The system also allows software selections to control the way in which this output oper- ates, see remote start feature # 10 for setting this output.
-
Page 13: Hood Pin Safety Shut Down
columns. The Green/Black wires should be connected to the negative (-) terminal of the respective cylinder number which appears in any of the circles. 2. For vehicles utilizing 2 cylinder firing per coil pack, connect Green/Black to the tach side of each coil pack. For 8 cylinder, four coil systems, connect to any of the three coils. -
Page 14: Mechanical Neutral Safety Switch Considerations
1. Set the vehicle parking brake. 2. Block the drive wheels to prevent vehicle movement. 3. Temporarily disconnect the Brown/Black positive shut down wire from the vehicle's brake switch. 4. Sitting in the vehicle, start the engine using the vehicle's ignition key. 5. - Page 15 AUDIOVOX ADVISES THAT YOU MAINTAIN THE FACTORY CIRCUIT WHENEVER POSSIBLE. The following two circuits may be used only if the above circuit is not available. NOTE: When completing an installation using either of the following key in sensor circuits, if the operator inserts the ignition key while the vehicle is running under the control of the Remote Start, the vehicle will shut down.
-
Page 16: Completing The Installation
C. Locate the key in sensor switch wire that connects the chime module to the ignition cylinder . D. Cut this wire and connect the ignition cylinder side to the Remote Start Negative Safety Shut down Wire Gray/ Black, using a 4002 series diode as shown above. NOTE: A second 4002 series diode may be required to maintain the integrity of the hood open, shut down circuit. - Page 17 128-7765 17 of 19...
- Page 18 THIS PAGE LEFT BLANK INTENTIONALLY 128-7765 18 of 19...
- Page 19 © 2006 Audiovox Electronics Corp., Hauppauge, NY 11788 128-7765 128-7765 19 of 19...
