Jøtul GF 300 DV
Allagash
Gas Heater
Installation
and
Operation
Instructions
IF THE INFORMATION IN THESE INSTRUC-
TIONS ARE NOT FOLLOWED EXACTLY, A FIRE
OR EXPLOSION MAY RESULT CAUSING PROP-
ERTY DAMAGE, PERSONAL INJURY OR LOSS
OF LIFE.
FOR YOUR SAFETY:
DO NOT STORE OR USE GASOLINE OR OTHER
FLAMMABLE VAPORS AND LIQUIDS IN THE
VICINITY OF THIS OR ANY OTHER APPLIANCE.
INSTALLATION:
INSTALLATION AND SERVICE MUST BE PER-
FORMED BY A QUALIFIED INSTALLER, SER-
VICE AGENCY OR LICENSED GAS SUPPLIER.
WHAT TO DO IF YOU SMELL GAS:
• DO NOT TRY TO LIGHT ANY APPLIANCE.
• DO NOT TOUCH ANY ELECTRICAL
SWITCHES.
• DO NOT USE THE PHONE IN YOUR
BUILDING. IMMEDIATELY CALL YOUR GAS
SUPPLIER FROM A NEIGHBOR'S PHONE.
• FOLLOW YOUR GAS SUPPLIER'S
INSTRUCTIONS.
• IF YOU CANNOT REACH YOUR GAS
SUPPLIER, CALL THE FIRE DEPARTMENT.
AVERTISSEMENT:
ASSUREZ-VOUS DE BIEN SUIVRE LES IN-
STRUCTIONS DANS CETTE NOTICE POUR
REDUIRE AU MINIMUM LE RISQUE D'INCENDIE
OU POUR EVITER TOUT DOMMAGE MATERIEL,
TOUTE BLESSURE OU MORTALIT'E.
NE PAS ENTREPOSER NI UTILISER D'ESSENCE
NI OU LIQUIDES INFLAMMABLES DANS LE
VOISINAGE DE CET APPAREIL OU DE TOUT
AUTRE APPAREIL.
L'INSTALLATION LE SERVICE DOIVENT
ETRE EXECUTES PAR UN INSTALLATEUR
QUALIFIE, AGENCE DE SERVICE OU LE
FOURNISSEUR DE GAZ.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ.
• NE PAS TENTER D'ALLUMER L'APPAREIL
• NE TOUCHEZ A AUCUM NTERRUPTEUR.
• NE PAS VOUS SERVIR DES TELEPHONES SE
TROUVANT DANS LE BATIMENT OU VOUS
VOUS TROUVEZ.
• APPELEZ IMMEDIATEMENT VOTRE
FOURNISSEUR DE GAZ CHEZ UN VOISIN. SUIVEZ
LES INSTRUCTIONS DU FOURNISSEUR.
• SI VOUS NE POUVEZ REJOINDRE LE
FOURNISSEUR DE GAZ, APPELEZ LE SERVICE
DES INCENDIES.
WARNING:
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GF 300 DV Allagash and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Jøtul GF 300 DV Allagash

Summary of Contents for Jøtul GF 300 DV Allagash

  • Page 1 Jøtul GF 300 DV Allagash Gas Heater Installation Operation Instructions WARNING: IF THE INFORMATION IN THESE INSTRUC- TIONS ARE NOT FOLLOWED EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROP- ERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. FOR YOUR SAFETY: DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS AND LIQUIDS IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE.
  • Page 2 1853. The GF 300 DV Allagash combines advanced gas technology with the warm, traditional elements of cast iron. With proper care and use, your Jøtul stove will provide you with many years of safe, dependable and satisfying service. The Jøtul GF 300 DV Allagash is a direct vented gas...

  • Page 3: Table Of Contents

    Table of Contents Service Tools ... 3 Specifications ... 4 General Information ... 5 Safety Information ... 6 Installation Requirements Location ... 6 Hearth Protection ... 6 Clearances ... 7 Mantel & Trim ... 7 Alcove ... 7 Vent Requirements ... 8 Adding Restriction ...

  • Page 4: Specifications

    GF 300 DV Specifications Input Rates Natural Gas 26,000 BTU/hr. maximum input 14,000 BTU/hr. minimum input Propane 26,000 BTU/hr. maximum input 14,000 BTU/hr. minimum input Inlet Pressure: Natural Gas: 5.0 WC (1.24 kPa) Propane: 12.0 WC (2.99 kPa) 14.9 WC (3.71 kPa) Manifold Pressure: Natural Gas: 1.2 WC (.30 kPa)

  • Page 5: General Information

    Only remove glass for routine service. Always handle glass carefully. Unpacking your stove 1. Remove the Top Plate of the stove by simply lifting it straight off of the stove body. 2. To open the firebox, disengage the two Glass Frame Latches located on top of the firebox.

  • Page 6: Safety Information

    Also, “fire-rated” sheet rock is considered combustible. Hearth Requirements The GF 300 DV gas stove CANNOT be installed directly on ® carpeting, vinyl, linoleum or Pergo If this appliance will be installed on any combustible...

  • Page 7: Clearances

    Stove and Vent Clearance Requirements Minimum Clearances from the Stove to Combustibles: See figs. 2-4. Rear: 2” (51 mm) Ceiling: 33” (838 mm) Corner: 2” (51 mm) Right Side: 3” (76 mm) Left Side: 10” (254 mm) - for access to Lighting Instruction plate...

  • Page 8: Venting Requirements

    Venting Requirements The Jøtul GF 300 DV gas stove may be installed with a vertical or horizontal termination and must conform to the configuration requirements described below. This appliance is approved for use with vent systems from the following manufacturers: •...

  • Page 9: Vertical Termination

    Elbows: Four 45°, or two 90° elbows may be used. Do not include the 45° elbow attached to the stove. Whenever possible use 45° elbows instead of 90° elbows as they are less restrictive to exhaust gas and intake air flow.
  • Page 10 • ALWAYS MAINTAIN THE PROPER CLEARANCES TO COMBUSTIBLES. The circled letter designations in the vent diagram correspond to the Exhaust Restrictor Setting on the stove. First, determine which vent termination zone is appropriate for your installation and fuel type, then adjust the restrictor to the corresponding position as shown in figure 7, page 9.
  • Page 11 Exhaust Restrictor Setting on the stove. First, determine which vent termination zone is appropriate for your installa- tion and fuel type, then adjust the stove restrictor plate to the corresponding position as shown in Figure 7, page 9.

  • Page 12: Co-Linear Termination

    Refer to the vent manufacturer’s instructions for specific installation requirements. WARNING: FAILURE TO POSITION THE PARTS AND STOVE IN ACCORDANCE WITH THESE DIAGRAMS OR FAILURE TO USE ONLY PARTS SPECIFICALLY APPROVED FOR USE WITH THIS APPLIANCE MAY RESULT IN PROP- ERTY DAMAGE OR PERSONAL INJURY.

  • Page 13: Coaxial Chimney Conversion

    Simpson Dura-Vent Chimney Conversion Kit #934. May also be used in listed prefabricated chimneys. Drawing is for illustrative purposes only - DO NOT VENT TWO APPLIANCES INTO A SINGLE CHIMNEY. Intake Air Use Standard Simpson Dura-Vent GS Pipe from stove to thimble...

  • Page 14: Horizontal Termination

    With a 14” Snorkel: The horizontal run made directly off the rear of the stove into a 14” snorkel cap should include no more than a single 12” straight section as shown in fig. 17. One 45° Elbow may be used for a corner installation as shown in fig.

  • Page 15: Vent Terminal Clearances

    Horizontal Termination Clearance Figure 20. Vent Terminal Clearances - National Fuel Gas Code. A = Clearance above grade, veranda, porch , deck, or balcony : *12 inches (30 cm) minimum. B = Clearance to window or door that may be opened: 9 inches (23 cm) min./U.S.

  • Page 16: Mobile Home Installation

    The GF 300 DV can be installed for use in a mobile home in the U.S. and Canada provided: 1. The stove is secured to the floor of the mobile home. Use Jøtul Floor Bracket Kit #154388. 2. Provision must be made to secure an electrical ground between the stove and the mobile home chassis.
  • Page 17 Burner to the floor of the firebox. Pull the Air Shutter forward and lift the burner together with shutter up and out of the stove as a unit. See fig. 23. 8. Change the Main Burner Orifice. See fig. 24. Using a ½”...

  • Page 18: Gas Supply Connection

    15. Install the new regulator: Be sure the new gasket is properly positioned and tighten screws securely. 16. Install the identification labels to the stove so that they can be seen by any person that may be servicing the stove.

  • Page 19: Gas Pressure

    Gas Pressure Correct gas pressure is essential for efficient and safe operation of the GF 300 DV gas stove. It is important that the correct pressure is established at the time of the installation. Proper gas pressure provides a consistent flow of gas to the appliance and is instru- mental in checking for gas leaks.

  • Page 20: Air Shutter Adjustment

    To adjust the air shutter: 1. Reach under the right side of the stove and loosen the wingnut located closest to you. See fig. 30. Slide the wingnut stud forward to open the air shutter and back to provide less air.

  • Page 21: Log Set Installation

    NOTE: You do not need to use all of the ember stones. With experimentation, you will find the arrangement and quantity of embers that works best with your stove. Depending upon the characteristics of your installation, it is possible that too many ember stones can pro- mote sooting on the logs.

  • Page 22: System Check

    See the inside back cover of this manual or the stove Rating Plate attached the bottom of the stove. Subsequent burner starts will not require purging the gas line unless the supply line is shut off.

  • Page 23: Operation

    If a vacuum is used during any service on the stove, ALWAYS be sure the stove is cold and there are NO hot embers. 5. Remember, this appliance has a continuous burning pilot flame.

  • Page 24: Maintenance

    3. Lift the glass frame all the way up and out of the top of the stove. Lay this assembly on a flat surface, protecting the frame from scratches using a blanket or towel.

  • Page 25: Optional Blower Installation

    M6 hex nuts and a 10 mm wrench. See fig. 43. 4. Attach the Blower Bracket to the stove using the two M6 flange head hex bolts as shown in fig. 43.

  • Page 26: Blower Operation

    Fan speed may be manually adjusted with the rheostat knob. If the burner turns off, the blower will be shut off automatically when the stove cools down. If automatic blower circulation is not desired, place the blower control switch in the MANUAL position.

  • Page 27: Optional Brick Kit Installation

    2. Remove the Glass Frame. Disengage the two com- pression latches located at the top of the firebox and lift the glass frame up and off of the stove. See fig. 48. 3. If installed, remove the Logset. These parts are not fastened.

  • Page 28: Illustrated Parts Breakdown

    GF 300 DV Illustrated Parts Breakdown Figure 52. Illustrated Parts Breakdown - GF 300 DV Allagash...

  • Page 29: Replacement Parts List

    GF 300 DV Allagash Parts List Cast Iron Parts Side Plate Base Plate Legs, (4) Front Panel Right Door Top Plate Left Door Side Clip ... 128401 Simpson DuraVent Collar ... 129126 Collar Gasket ... 129118 Rheostat ... 220700 Rating Plate ... 220612 Lanyard ...
  • Page 30 MODEL NAME: ________________________ SERIAL NUMBER: ______________________ DATE OF PURCHASE: ___________________ PURCHASED FROM: ____________________ NAME OF INSTALLER: ___________________ TYPE OF FUEL: ________________________ WAS STOVE CONVERTED? _______________ NOTES: RETAIN THIS MANUAL FOR REFERENCE AND MAKE IT AVAILABLE TO ANYONE USING OR SERVICING THE STOVE.

  • Page 31: Lighting Instructions

    1. STOP! Read the safety information above. 2. Access the lower controls. 3. Turn the stove ON/OFF switch to “OFF”, or set the thermostat to lowest setting (if used). 4. Confirm that the gas supply line shut-off valve is open.
  • Page 32 This appliance must be installed in conformance with local and national building regulations. It is important that the these instructions be carefully read and understood before beginning the installation. Jøtul pursues a policy of continual product development. Consequently, products may differ in specification, color or type of accessories from those illustrated or described in various publications.
