- Page 1 Tiller/Cultivator QUICK ASSEMBLY SHEET Model 7945 IMPORTANT NOTE: Read the Safety Rules & Warnings before you use your Mantis tiller P/N 430100, Rev A ©2014 Schiller Grounds Care, Inc.
-
Page 2: Tine Installation
QUICK ASSEMBLY SHEET Tools Needed: Two 7/16” wrenches Model: 7945 Upper Handles Carry Handle Hardware Lower Handles Step 1 Step 3 Attach the Upper Throttle Slide two (2) T11 Bolts through the holes Step 2 Handle onto the Right Lower of one Handle Clamp and then through Handle.
