1 Introduction

This manual provides installation and programming information for the PC9155 two-way wireless series of alarm panels. The PC9155 is a two-
way wireless alarm system that can interface with one-way and two-way RF devices. Three separate hardware platforms exist for the 433 MHz
and 868 MHz versions.

1.1 PC9155 Model Differences

Models with a 'G' in the suffix have a GS2065 module installed. The GS2065 mod-
ule is a GSM (Global System for Mobile communications) wireless cell communi-
cator that communicates with a GPRS (General Packet Radio Services) global
network that can be programmed as the primary or backup communicator.
Models with a 'D' in the suffix have a TL265GS module installed. The TL265GS
module combines the dual functionality of the GS2065 wireless cell communicator
and T-Link TCP/IP Ethernet/Internet communicator. Either function can be pro-
grammed as the primary or backup communicator.
All models can communicate via telephone (PSTN) in addition to cell and Internet
described above. Refer to the associated installation guide for programming of the
GS2065 and TL265GS modules.

1.2 Specifications

Table 1-2 Specifications
Specifications
Temperature Range......................0°C-49°C (32°F - 120°F)
Humidity .......................................93%RH Non Condensing
Power Supply..............................16.5Vac/20VA @50/60Hz
Current Draw (panel)
240 VAC Primary .................................... 57mA(AC)(Max)
120 VAC Primary ..................................114mA(AC)(Max)
16.5 VAC Secondary ............................855mA(AC)(Max)
Current Draw (panel) Battery Only
Standby............................................................90mA Max
Transmit (GPRS/Ethernet Module) ................330mA Max
Battery Capacity ............................................. 12V
Charging Rate..................................240mA. (12Hrs Max)
Backup Time (No Aux).............................................. 24Hr
Aux+
Voltage.......................................................... 9.6-13.8V
Current......................................................... 200 mA Max
PGM 1&2 Output Current .................................. 50mA (ea.)
Note: Aux and PGM outputs share the 200mA load.
Wireless Transceiver
Operating Frequency Panel ......433.92 MHz/868.35 MHZ
Dimensions:
PC9155.......................................H10.5 x W8.5 x D 2.3 in
WT5500 ..................................... H4.9 x W6.5 x D 1.25 in
with wall bracket
...................... H4.9 x W6.5 x D 1.5 in
Weight
PC9155 NA............................................ 4.1 lb. (1.830Kg)
PC9155 EU (Internal Transformer) ........ 5.1 lb. (2.275Kg)
WT5500 ................................................. 1.0 lb. (0.454Kg)
Out of the Box:
PC9155
RJ31-x Telephone (NA only)
Transformer: NA external, EU internal
Mounting Hardware Kit
Installation, Keypad & User manuals ...............Qty (1) ea.
One-way, Two-way Device Installation sheets...as required
Note: For SIA CP-01 compliant installations the minimum required components are: PC9155-433 Control Panel and WT5500-433 Keypad.
Optional components that can be used with the system are: TL265GS, GS2065, WT5500P-433, PT4, WT4989 and WT4901.
Table 1-3 Compatible Wireless Devices
Compatible Wireless Devices
WS, WLS, EV prefixes indicate one-way wireless device.
WT prefix indicates two-way wireless device.
Descriptions
Wireless Keypads
Proximity Tag
Door Contacts
2.3Ah
DC
Motion Detectors
Smoke Detector
DC
CO (Carbon Monoxide) Detector
Flood Detector
Glass Break Detectors
Shock Detector
Wireless Sirens
Wireless Keys
Panic Pendants
Hold-up
approved devices are to be used with listed systems.
UL
Only
**Not available in North America, South America and New Zealand
***Available in North America, South America and New Zealand only
1-1
Table 1-1 PC9155 Models
Operating
Model
Frequency
PC9155-433 433.92MHz
PC9155-868 868.35MHz
PC9155G-433 433.92MHz
PC9155G-868 868.35MHz
PC9155D-433 433.92MHz
PC9155D-868 868.35MHz
Note: Only Models PC9155-433, PC9155D-433 and
PC9155G-433 are UL/ULC listed
PC9155x-433
WT5500-433
UL
WT5500P-433
UL
PT4
UL
WS4945
UL
WS4965
UL
**WS4975
EV-DW4955
***EV-DW4975
WS4904
UL
WS4904P
UL
WLS914-433
UL
WS4916
UL
WS4926
UL
WS4913
WS4985
WLS912L-433
UL
EV-DW4927
Indoor WT4901
UL
Outdoor WT4911
UL
WS4939
UL
WS4949
WS4959
WS4969
WS4979
WT4989
UL
WS4938
UL
WS4938-2W
UL
WLS928-433
GS2065 TL265GS
✖ ✖
✖ ✖
✔ ✖
✔ ✖
✖ ✔
✖ ✔
PC9155x-868
WT5500-868
WT5500P-868
PT8
WS8945
WS8965
WS8975
WS8904
WS8904P
WS8916
WS8913
WS8985
WT8901
WT8911
WS8939
WT8989
WS8938
