Subaru 2. 2 Li t er Engi n e
Engine Accessory Removal
sensors, switches, intake manifold, and intake
manifold gaskets.
one-time use only.
water pump and rubber coated metal gasket.
The gasket is one-time use only. Retain the dust
seals for later reassembly.
the dust seals. Retain the dust seals for later reassembly.
Cylinder Head Removal
remove all of the cylinder head bolts except #1. Lightly tap the cylinder head with a
rubber mallet to loosen the head from the gasket. Then remove #1 bolt and the cylin-
der head with the head gasket. Repeat the above steps for the other cylinder head.
gaskets are interchangeable from left to right on N/A engines only.
head unless servicing of the valve components is required.
Oil Pan Removal
Removing Cylinder Head
mallet to loosen the oil pan. Remove the oil pan. Notice the location of the oil seal
for the drain tube. Remove the oil pick-up tube and also note the o-ring. Remove
the oil pan baffle plate (windage tray).
Piston Pin Removal
to remove the piston pin. Insert the tool 3/4 of the
way into the pin and pull the tool with the pin
through the access hole. Repeat for the remaining
pistons. Finally, rotate the crankshaft to position the
pistons at the top of the cylinders. Repeat the proce-
dure for the other cylinders.
to prevent the connecting rod large ends from dam-
Removing Oil Pan
aging the lower cylinder bores.
Hidden Crankcase Bolts
crankcase bolts. Six of the bolts are hidden in the
water passages, four in the RH case (1-3 side) and
two in the LH case (2-4 side).
bolts have sealing washers. These bolts are not inter-
changeable with the other crankcase bolts. The sealing
washers are one-time use ONLY.
(three small, one large), in the mating surface of the
right (1-3 side ) crankcase. The black o-rings are for oil
passages, the orange o-ring is for a coolant passage.
Remove the hoses, electrical connections,
Note: The rubber coated metal gaskets are
Remove dipstick tube and then remove the
Remove the oil pump. Observe the condition and location of the o-ring seal and
Loosen all head bolts in the reverse order of the tightening sequence, and then
Note: The head gaskets are carbon composition with integrated o-rings. The
Note: It is not necessary to remove the valve cover while removing the cylinder
Remove the oil pan bolts. Use a thin gasket scraper/putty knife and a rubber
Use piston pin remover 499097300 or 499097500
Note: Use caution while rotating the crankshaft
To split the crankcase remove all 16 of the
Note: All six of the hidden shouldered crankcase
Carefully separate the crankcase halves.
Note: Identify the location of the four O-rings
10
Intake Manifold
Removing Wrist Pin
Hidden Crankcase Bolts And
Sealing Washers
Crankcase O-Ring Seals
