- Page 1 SP170/210 INSTRUCTIONS FOR USE MANUEL D’UTILISATION MANUAL DE INSTRUCCIONES 20A9991401 OHC Gasoline Engines...
- Page 3 Subaru’s option, of any part or parts which upon examination is/are found, in Subaru’s judgment, to have been defective in material or work manship. It shall be a condition of Subaru’s obligation under this Limited Warranty that Subaru, directly or through one of its Distributors or Service Centers...
- Page 4 The customer is responsible for all transportation charges in connection with any warranty work. Subaru reserves the right to modify, alter or improve any engines or parts without incurring any oblig ation to modify or replace, any engine or parts previously sold without such modification, alternation or improvement.
- Page 5 WORLD WIDE SUPPORT Subaru Engines are supported through a network of dozens of wholesale distributors and thousands of service dealers worldwide. Please use the following contacts to find support nearest you. Global Distributor Locator: www.subaru-robin.jp/index_e.html North America: Subaru Robin America, Inc.
-
Page 6: Air Index
Notice : To the engines / generators exported to and used in the countries other than the U.S.A., warranty service shall be performed by the distributor in each country in accordance with the standard Subaru engine / generator warranty policy as applicable. - Page 7 FORWARD Thank you for choosing a Subaru. Your Subaru engine can supply the power to operate various sorts of ma- chines and equipment. Keep this owner’s manual at hand, so you can refer to it when needed. Due to constant efforts to improve our products, certain procedures and specifications are subject to change without notice.
-
Page 8: Table Of Contents
CONTENTS 1. Symbols ............................8 2. Safety Precautions ......................... 9 3. Components ..........................12 4. Pre-Operation Checks ......................... 13 5. Operating the Engine ........................14 6. Maintenance ..........................16 7. Preparations for Storage ......................20 8. Easy Troubleshooting ........................21 9. -
Page 9: Safety Precautions
1. SAFETY PRECAUTIONS Please make sure you review each precaution carefully. Pay special attention to statement preceded by the following words. ▲ “WARNING” indicates a strong possibility of severe personal injury or loss of life if WARNING instructions are not followed. ▲... - Page 10 ▲ OTHER SAFETY PRECAUTIONS WARNING • Do not touch the spark plug and ignition cable when starting and operating the engine. • Never make adjustments on the machinery while it is connected to the engine, without first removing the ignition cable from the spark plug. Turning the crankshaft by hand during adjusting or cleaning might start the engine, and cause serious injury to the operator.
-
Page 11: Components
SYMBOLS Shutt o fuel valve Read manual. when the engine is not in use. Check for leakage Stay clear of the hot surface. from hose and ttings. Exhaust gas is poisonous. Fire, open ame and smoking Do not operate in an unventilated prohibited. -
Page 12: Pre-Operation Checks
• Use 4-stroke automotive detergent oil of API service class SE or higher grade. • Select the viscosity based on the air temperature at the time of operation as shown in the table. Oil Capacity (Upper Level) SP170/210 0.6 L 2. CHECK FUEL ▲... -
Page 13: Operating Your Engine
4. OPERATING YOUR ENGINE 1. STARTING 1) Open the fuel valve 2) Turn the STOP SWITCH to the “ON” (I) position 3) Set the speed control lever 1/3 of the way towards the high speed position. 4) Close the choke lever. •... -
Page 14: Maintenance
3. STOPPING 1) Set the speed control lever at the low speed position and allow the engine to run at low speed for 1 or 2 minutes before stopping. 2) Turn the STOP SWITCH counterclockwise to the “OFF” (O) position. 3) Close the fuel valve 4) Pull the starter handle slowly and return the handle to it original position when resistance is felt. - Page 15 Periodic Maintenance Schedule Table Every 50 Every 200 Every 8 hours Every 500 Every 1000 Maintenance Items hours hours (Daily) hours hours (Weekly) (Monthly) Clean engine and check bolts and nuts • (Daily) • (Refill daily up to upper level) Check and refill engine oil •...
- Page 16 To prevent injury, pay attention to the hot oil 2. Re-install the drain plug before refilling oil. Oil Capacity (Upper Level) SP170/210 0.6 L 3. Refer to page 12 for the recommended oil. • Always use the best grade and clean oil. Contaminated oil, poor quality oil and shortage of oil cause damage to engine or shorten the engine life.
- Page 17 6. CLEANING AIR CLEANER A dirty air cleaner element will cause starting difficulty, power loss, engine malfunctions, and shorten engine life extremely. Always keep the air cleaner element clean. ▲ WARNING Flame Prohibited 1. Urethane Foam Element Type Remove the element and wash it in a solution of mild detergent and warm water. Then rinse the element thoroughly in clean water.
-
Page 18: Preparations For Storage
9. HIGH ALTITUDE ENGINE OPERATION • Please have an authorized Subaru Robin service dealer modify this engine if it is to be run continuously above 5000 feet (1500 meters). Failure to do so, may result in poor engine performance, spark plug fouling, hard starting, and increased emissions. -
Page 19: Operating The Engine
7. OIL SENSOR INSTRUCTIONS 1. FUNCTION OF OIL SENSOR The engine will stop automatically when the oil level falls below the safety limit. The engine cannot be started unless the level is raised above the prescribed limit. 2. RESTARTING 1. Fill the crankcase with oil up to the proper level. 2. -
Page 20: Easy Troubleshooting
9. EASY TROUBLESHOOTING WHEN ENGINE WILL NOT START: Perform the following checks before you take the engine to your Subaru Robin dealer. If you still have trouble after completing the checks, take the engine to your nearest Subaru Robin dealer. -
Page 21: Specifications
10. WIRING DIAGRAM Spark plug Black To LED Lamp Ignition coil Oil sensor control unit Flywheel Oil sensor 11. SPECIFICATIONS Model SP170 SP210 Type Air-cooled, 4-cycle, single cylinder, overhead camshaft, gasoline engine Displacement Maximum Torque ft•lb/rpm 8.34/2500 10.26/2500 Rated Output HP/rpm 5.7/4000... - Page 24 ISSUE EMD-EU6858 FUJI HEAVY INDUSTRIES, LTD. INDUSTRIAL PRODUCTS COMPANY 4-410 ASAHI, KITAMOTO-SHI, SAITAMA, 364-8511, JAPAN PRINTED IN CHINA T E L : + 8 1 - 4 8 - 5 9 3 - 7 7 9 8 , FA X : + 8 1 - 4 8 - 5 9 3 - 7 9 4 6 h t t p : / / w w w .
