Acer® AX3400-U2022 Desktop
Detailed Product Specifications
Processor
AMD Athlon™ II X4 Quad-Core Processor 635
(2.90GHz, 2MB L2 cache, 1333MHz FSB)
(2.90GHz, 2MB L2 cache, 1333MHz FSB)
Chipset
®
®
NVIDIA
GeForce
9200 Chipset
Memory
4096MB DDR3 Dual-Channel 1333MHz Memory
Used Slots: 2 x 2048MB, | 2 Slots (Available)
Used Slots: 2 x 2048MB, | 2 Slots (Available)
4 DDR3 Slots (Total) - Expandable to 8GB
Video
®
®
Integrated NVIDIA
GeForce
9200 Graphics
Audio
Audio
High Definition Audio with 5.1-Channel Audio Support
Hard Drive
1TB SATA Hard Drive (Green Product - variable RPM)
Optical Drive
16X DVD±R/RW SuperMulti Drive
16X DVD±R/RW SuperMulti Drive
Write Max: 16X DVD±R, 6X DVD-RW, 8X DVD+RW,
8X DVD±R DL, 5X DVD-RAM, 48X CD-R,
32X CD-RW
Read Max: 16X DVD-ROM, 40X CD-ROM
Digital Media Card Reader
Digital Media Card Reader
Multi-in-1 Digital Media Card Reader
®
CompactFlash
(Type I and II), CF+™ Microdrive,
MultiMediaCard (MMC), Reduced-Size MultiMediaCard (RS-
MMC), Secure Digital™ (SD) Card, xD-Picture Card™, Memory
®
Stick
, Memory Stick PRO™
Communications
Communications
10/100/1000 Gigabit Ethernet LAN (RJ-45 port)
802.11b/g/n Wireless
Input Devices
USB Keyboard and Optical Mouse
Case Design
Stylish and Classic Small-Form Factor Design
Page 3
Interfaces
9 - USB 2.0 Ports (5 Front, 4 Rear)
1
1 - HDMI™ Port
1 - HDMI™ Port
1 - VGA port
1 - eSATA port
1 - RJ-45 Ethernet Port
1 - High-Definition Headphone Jack
1 - Microphone Jack
2
2 - PS/2 Ports (Keyboard and Mouse)
5 - Audio Ports
5 - Audio Ports
Expansion Slots
Total
1 - PCI-E x1
1 - PCI-E x16
1 - PCI-E x16
Expansion Bays
Total
(3)
1 - 3.5" HDD
1 - 5.25" ODD
Power Supply
Power Supply
220W
Dimensions (System)
10.5 (H) x 4.0 (W) x 13.9 (D) inches
265 (H) x 100 (W) x 352 (D) mm
Dimensions (Box)
14 (H) x 7 (W) x 20 (L) inches
355.6 (L) x 177.8 (W) x 508 (D) mm
Weights
12 lbs. | 5.4 kg (system unit only)
Approximately 19 lbs. | 8.6 kg (box)
Approximately 19 lbs. | 8.6 kg (box)
Pallet Quantity
84 units per pallet
Limited Warranty
1 Year Parts and Labor Limited Warranty with Toll Free
4
Tech Support
Tech Support
UPC
884483168286
Part Number
PT.SE202.007
Software
Windows® 7 Home Premium 64-bit
Available
0 - PCI-E x1
1 - PCI-E x16
1 - PCI-E x16
Available
0 - 3.5" HDD
0 - 5.25" ODD
(1) Overall system performance is based on several PC attributes. GHZ, processor clock speed, is one of the
(1) Overall system performance is based on several PC attributes. GHZ, processor clock speed, is one of the
attributes.
attributes.
(2) Shared system memory may be allocated to support integrated graphics depending on system memory
size and other factors. Actual system memory available to the operating system will be reduced by the amount
of shard system memory utilized by the graphics solution and resources required by the operating
environment.
(3) 1 GB is 1 billion bytes. Actual formatted capacity is less and may vary depending on preloaded materials
(3) 1 GB is 1 billion bytes. Actual formatted capacity is less and may vary depending on preloaded materials
and operating environment. Acer eRecovery Management utilizes up to 8 GB (10 GB with Microsoft® Works
with Office Home and Student 2007 Trial) of the stated hard disk capacity as dedicated backup space.
(4) For a free copy of the standard limited warranty end‐users should see a reseller where Acer products are
sold or write to Acer America Corporation, Warranty Department, P.O. Box 6137, Temple, TX 76503. TFT
displays commonly exhibit a small number of discolored dots, so‐called "nonconforming pixels." This
phenomenon is a limitation of TFT LCD technology, not a product defect and, as such, is not covered by the
limited warranty or by the upgrade programs. For International travelers warranty Valid only in countries where
limited warranty or by the upgrade programs. For International travelers warranty Valid only in countries where
Acer has an authorized repair facility. For a list of those countries go to http://global.acer.com/support/itw.htm.
or call 800‐816‐2237. Services and response times may vary in countries outside the U.S. and Canada
(5) 60-days of complimentary subscription. Internet connection required to start trial.
© 2010 Acer Inc. All rights reserved. Acer, the Acer logo, and Aspire are registered trademarks of Acer Inc. Other trademarks, registered
trademarks, and/or service marks, indicated or otherwise, are the property of their respective owners.
Acer® Confidential
Acer eRecovery Management
Acer eRecovery Management
®
Adobe
Flash® Player
®
®
Adobe
Reader
Google Toolbar
®
5
McAfee
Internet Security Suite Trial
®
Microsoft
Works and Office Home and Student 2007 Trial
Nero® 9 Essentials
Acer Arcade Deluxe
Acer Arcade Deluxe
eSobi™
5
v1.0 - May 24, 2010
