Technical Specifications - T-Rex ToneBug User Manual

Technical Specifications

Input Impedance @ 1KHz
Output Impedance @ 1KHz
Power supply
Minimum Power supply Voltage
Maximum Power supply Voltage
Current Draw @ 9V DC
Maximum input signal Vp/p
Battery Type
Battery Life
External connectors
Controls
Depth
Width
Height
Weight (excl. battery)
Higher than 1 M Ohm
Lower than 1 K Ohm
9V DC
8V DC
12,5V DC
7 mA
3,2 Vp/p
9V battery 6F22 Alkaline
12 to 16 Hours
Input Jack. Output Jack, 9V DC Jack (center
pin negative)
On/Off, Level, Gain, Tone
120 mm
78 mm
60 mm
0,403 Kg
T-REX WARRANTY CONDITIONS
T-Rex offers a 2-year warranty on all our products. In the unlikely event of a malfunction,
please contact our technical support at info@t-rex-effects.com before sending us the product
for repair. When the product has been sent to us at sender's cost, we will repair or replace
your product and send it back to you - free of charge and usually within 3 weeks (shipping
not included). The product needs to be accompanied by a copy of your receipt, serial num-
ber, return address, phone number, e-mail address and a brief explanation of the problem.
Please note that we cannot replace a product until we have received it here in Denmark.
The warranty is lost if the product has been damaged by alteration, misuse, accident, or
neglect; or if the product has been repaired or serviced by persons not authorized by T-Rex.
Read more about warranty conditions at www.t-rex-effects.com.
ABOUT T-REX
Based in Vejle, Denmark, T-Rex Engineering makes classic and signature effects pedals for the
world's best musicians. Our approach blends hi-tech innovation with old-world craftsman-
ship – always in the service of killer tone.
EU REGULATIONS • ENVIRONMENT PROTECTION
T-Rex accepts and follows the regulations and directives issued by the EU. We find these
environment protecting regulations very good, and we are happy to follow them.
